Spare Parts For Commercial Vehicles

Spare Parts Catalogue for Commercial Vehicles Version 01/2021 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI BPW Page 1 DAF Page 11 Fruehauf Page 13 Iveco Page 14 Mack Page 16 MAN Page 19 Mercedes-Benz Page 25 Neoplan Page 36 Renault Page 37 ROR Page 39 SAF Holland Page 41 Scania Page 42 Setra Page 44 Trailer Page 46 Universal Page 47 Volvo Page 51 Index I (Tigril No - OE No) Page 54 Index II (OE No - Tigril No) Page 59

BPW HS../HZ.. Series Tigril No. BP09.0020 OE No. 03.272.48.46.0 Description Wheel hub 10-12 T Remarks Rear HS../HZ.. Series Tigril No. BP09.0021 OE No. 03.272.62.27.0 Description Wheel hub 13-14 T Remarks Rear HS…/ HZ... Tigril No. BP09.0022 OE No. 03.272.80.14.0 Description Wheel hub 16-18 T 10 hole Remarks Rear Tigril No. BP09.0032 OE No. 03.272.80.86.0 Description Wheel hub 16 T HD Remarks Rear HS../HZ.. SH../SKHS.. ECO-MAXX Tigril No. BP09.0043 OE No. 03.272.30.97.0 Description Wheel hub 6.5-9 T Remarks Rear EHZ Series Tigril No. BP09.0044 OE No. 03.272.48.32.0 Description Wheel hub Remarks Rear H.. 16-18 T Tigril No. BP09.0027 OE No. 03.212.26.01.0 Description Hub cap, outer thread Remarks M155x3 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1

BPW H ( SN 42.. ), K ( SN 36.. ), SH ( SB 4345 ), SKH ( SB 3745 ), H..LL ( SN 42.. ) Tigril No. BP09.0048 OE No. 03.212.25.31.0 Description Hub cap, 8-9-10-12 T, inner thread Remarks M136x2,5 SW110/800Nm W Tigril No. BP09.0049 OE No. 03.212.27.01.0 Description Hub cap, 14-20 T, outer thread Remarks M230x3 SW120 H../K.., NR.. Tigril No. BP09.0050 OE No. 03.212.25.02.0 Description Hub cap, 13-14 T, outer thread Remarks M135x3 SW120/700Nm H ( SN 42.. ), (M)..L ( SN 42.. ) Series Tigril No. BP09.0051 OE No. 03.212.26.14.0 Description Hub cap, 13-14 T, inner thread Remarks M150x2 SW120/800Nm H../R.., KH../KR.., NH../NR.. Tigril No. BP09.0052 OE No. 03.212.24.07.0 Description Hub cap, 10-12 T, outer thread Remarks M125x2 SW110/500Nm H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX Tigril No. BP09.0053 OE No. 03.212.25.08.0 Description Hub cap, 10-12 T, inner thread Remarks M135x2 SW110/800Nm H.. Tigril No. BP09.0024 OE No. 05.370.07.04.0 Description Wear ring, wheel hub, 16-18 T Remarks Ø110 x Ø213 x 35 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2

BPW H../R.., KH../KR.. Tigril No. BP09.0055 OE No. 05.370.07.43.0 Description Wear ring, wheel hub, 10-12 T Remarks Ø96 x Ø136 x 22 H../K.. Tigril No. BP09.0056 OE No. 05.370.07.20.0 Description Wear ring, wheel hub, 13-14 T Remarks Ø96 x Ø136 / Ø187 x 34 H.. 16-18 T Tigril No. BP09.0025 OE No. 03.310.99.02.0 Description Seal ring for wheel hub Remarks Rear axle H.. 16-18 T Tigril No. BP09.0026 OE No. 03.310.99.01.0 Description Seal ring for wheel hub Remarks Rear axle HZ… 24" Tigril No. BP24.0012 OE No. 03.328.86.05.0 Description Wheel spider 16T Remarks 604.202.224 Rear BPW Tigril No. BP24.0015 OE No. 03.328.76.47.0 Description Wheel spider 12 T Remarks 604.202.158 Rear BPW Tigril No. BP24.0016 OE No. 03.328.83.04.0 Description Wheel spider 14 T Remarks 604.202.198 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3

BPW VB-HDE 14-20 ton Tigril No. BP09.0001 OE No. 05.291.01.14.0 Description Equalizing beam bearing, bronze bushes 70 mm Remarks Rear VB-HD 14-20 ton Tigril No. BP09.0002 OE No. 05.291.01.11.0 Description Equalizing beam bearing, rubber steel bush 60 mm Remarks Rear Trailer Tigril No. BP09.0003 OE No. Description Equalizing beam bearing, bronze bushes doll type 70 mm Remarks Rear VB suspension Tigril No. BP09.0018 OE No. Description Equalizing beam bearing, rubber steel bush doll type 60 mm Remarks Rear Tigril No. BP09.0057 OE No. Description Equalizing Beam Bearing, bronze bushes 60mm 2 bolt Remarks Rear Tigril No. BP09.0058 OE No. Description Equalizing Beam Bearing, bronze bushes 60mm 4 bolt Remarks Rear VB-HDE 14-20 ton Tigril No. BP09.0011 OE No. 03.112.76.13.0 Description Brass bush, equalizing beam 70 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4

BPW VB-HDE 14-20 ton Tigril No. BP09.0012 OE No. 03.112.76.14.0 Description Brass bush, equalizing beam 60 mm Remarks VB suspension Tigril No. BP09.0010 OE No. 05.113.97.10.0 Description Bush, leaf spring (suspension) rubber 60mm Remarks Rear EL-VB Tigril No. BP09.0037 OE No. 03.177.17.04.0 Description Equalizer bolt kit 70x313 mm Remarks Rear EL-VB Tigril No. BP09.0038 OE No. 03.177.16.17.0 Description Equalizer bolt kit 70x281 mm Remarks Rear EL-VB Tigril No. BP09.0039 OE No. 03.177.16.20.0 Description Equalizer bolt kit 60x285 mm Remarks Rear EL-VB Tigril No. BP09.0040 OE No. 13.177.17.05.0 Description Equalizer bolt kit 60x313 mm Remarks Rear VB suspension Tigril No. BP09.0004 OE No. 05.443.71.55.0 Description Connecting rod, adjustable short (36 mm) Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5

BPW VB suspension Tigril No. BP09.0005 OE No. 05.443.70.77.0 Description Connecting rod, adjustable (30 mm) Remarks Rear VB suspension Tigril No. BP09.0006 OE No. 05.443.48.35.0 Description Connecting rod, fixed long (36 mm) Remarks Rear VB suspension Tigril No. BP09.0007 OE No. 05.443.46.03.0 Description Connecting rod, fixed short (36 mm) Remarks Rear VB suspension Tigril No. BP09.0031 OE No. 05.443.71.02.0 Description Connecting Rod, adjustable (36mm) long Remarks Rear VB suspension Tigril No. BP09.0009 OE No. 05.113.93.03.0 Description Bush, connecting rod (36 mm) Remarks Rear Tigril No. BP09.0028 OE No. 05.113.93.03.0PU Description Bush (PU) , Connecting Rod 36 mm Remarks Rear axle VB suspension Tigril No. BP09.0047 OE No. 05.113.93.03.0 Description Bush (PU), connecting rod 36 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6

BPW H../K.., NR.. Tigril No. BP09.0014 OE No. 03.262.17.11.0 Description Axle nut 13-18 T Remarks Rear EH suspension Tigril No. BP09.0015 OE No. 03.262.17.08.0 Description Axle nut 14 T Remarks Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP09.0016 OE No. 03.262.17.12.0 Description Axle nut 10-12 T Remarks Rear Tigril No. BP24.0001 OE No. 03.296.23.17.0 Description Wheel bolt Remarks M 22 x 2, M 22 x 1.5 112-61/48 mm, 10.9 Tigril No. BP24.0005 OE No. 02.507.03.20.0 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. BP24.0010 OE No. 02.507.08.70.0 Description Wheel bolt Remarks M 20 x 2 x 132/130 mm, 10.9 659112613 Tigril No. BP24.0014 OE No. 03.296.33.11.1 Description Wheel bolt Remarks 22 x 1.5 x 90 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 7

BPW Tigril No. DB24.0030 OE No. 02.507.08.90.0 Description Wheel bolt Remarks M 20 x 2 x 57/55 mm, 10.9 Tigril No. BP24.0004 OE No. 02.507.03.20.0Set Description Wheel bolt set Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. BP24.0009 OE No. 02.507.08.70.0Set Description Wheel bolt set Remarks M 20 x 2 x 132/130 mm, 10.9 659112613 Tigril No. BP24.0013 OE No. 05.806.23.22.0 Description Wheel bolt set Remarks M 22 x 2, M 22 x1.5 112-61/48 mm, 10.9 Tigril No. DB24.0029 OE No. 02.507.08.90.0Set Description Wheel bolt set Remarks M 20 x 2 x 57/55, 10.9 mm, 10.9 Tigril No. BP24.0002 OE No. 03.260.04.01.0 Description Wheel nut Remarks M22 x 2 H-25 wrench size-32 mm EH, EHZ Tigril No. BP24.0003 OE No. 03.260.04.06.0 Description Wheel nut Remarks M22 x 2 H-17 wrench size-32 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 8

BPW Tigril No. BP24.0006 OE No. 02.527.00.40.0 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm Tigril No. DB24.0016 OE No. 03.260.54.03.0 Description Wheel nut Remarks M22 x 1.5 H-22 wrench size-30 mm H/KH/NH/NR/R, RBH Tigril No. DB24.0017 OE No. 05.260.54.09.0 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm Tigril No. DB24.0018 OE No. 02.5213.14.62 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm Tigril No. DB24.0019 OE No. 02.5213.12.10 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm H Series Tigril No. IV24.0001 OE No. 02.521.92.01.0 Description Wheel nut Remarks M20 x 1.5 H-26.25 wrench size-30 mm Tigril No. BP24.0007 OE No. 02.545.02.20.0 Description Washer Remarks 36.9 x 21.2 x 2.75 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 9

BPW Tigril No. DB24.0021 OE No. 02.5615.20.90 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 Tigril No. DB24.0022 OE No. 03.310.10.02.0 Description Washer (centering ring, wheel rim) Remarks 32 x 20.2 x 6 mm DIN - ISO: 74361 Tigril No. DB24.0023 OE No. 02.5615.18.90 Description Washer (retaining ring, wheel rim) Remarks 29 x 18.5 x 7 mm DIN - ISO: 74361 Tigril No. DB24.0025 OE No. 02.561.51.49.0 Description Washer (retaining ring, wheel rim) Remarks 23 x 14.5 x 5 mm DIN - ISO: 74361 Tigril No. DB24.0027 OE No. 02.56152.22.90 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 Tigril No. BP24.0008 OE No. 02.181.81.00.0 Description Safety pin Remarks 41/30 x 2 mm Tigril No. BP24.0011 OE No. 02.181.61.40.0 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 10

DAF 75/85 CF, XF 95, CF 65/75/85, L 55 Tigril No. DA08.0001 OE No. 683.499 Description King pin kit single Remarks Front Tigril No. RO09.0006 OE No. 1.488.353 Description Bolt equalizer 41 mm Remarks Rear 75/85 CF, 95 XF, F 1700/1900/2100/2300/2500/2700/2800 Tigril No. BP24.0002 OE No. 144.922 Description Wheel nut Remarks M22 x 2 H-25 wrench size-32 mm 95 XF, 85 CF Tigril No. BP24.0006 OE No. 678.250 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm XF 95/105, CF 65/75/85/95, LF 55, 75/85 CF, 95 XF, F 2800/2900/3200/3300/3600, N 2800 Tigril No. DB24.0017 OE No. 0.620.652 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm Tigril No. DB24.0019 OE No. 188.055 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm F 1600/2100/2200/2300/2800 Tigril No. DB24.0027 OE No. 325.235 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 11

DAF 65/75/85 CF, 95 XF, F 1900/2100/2300/2500/2700/2800/3200/3300/3600 Tigril No. DB24.0028 OE No. 0.260.261 Description Washer (retaining ring, wheel rim) Remarks 32 x 22.2 x 5.5 mm DIN - ISO: 74361 CF 85, F 2300/2500/2700/2800/2900/3200/3300/75/85/95, TB 2100 Tigril No. BP24.0008 OE No. 506.666 Description Safety pin Remarks 41/30 x 2 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 12

FRUEHAUF Trailer Tigril No. FH09.0001 OE No. 0030.001 Description Conical rubber bush, equalizer Remarks Rear Trailer Tigril No. FH09.0002 OE No. 0033.001 Description Conical rubber bush, connecting rod Remarks Rear Tigril No. RO09.0006 OE No. CF150580 Description Bolt equalizer 41 mm Remarks Rear Tigril No. RO09.0004 OE No. M021546 Description Torque arm rigid long Remarks Rear Fruehauf Tigril No. RV24.0003 OE No. AJA0495001 Description Wheel nut Remarks M22 x 1.5 H-31, wrench size 32mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 13

IVECO Eurotrakker Tigril No. BP24.0006 OE No. 0247.8508 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm Tigril No. DB24.0016 OE No. 4180.0483 Description Wheel nut Remarks M22 x 1.5 H-22 wrench size-30 mm Eurocargo, EuroTech, EuroStar, Stralis, AD/AT/AS Stralis, EuroTrakker, AD/AT Trakker Tigril No. DB24.0017 OE No. 4103.1725 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm Tigril No. DB24.0018 OE No. 0.0112.1798 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm Tigril No. DB24.0019 OE No. 0112.1795 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm Zeta, MK, Eurocargo, M Tigril No. IV24.0001 OE No. 5.0407.1276 Description Wheel nut Remarks M20 x 1.5 H-26.25 wrench size-30 mm Citelis, Crealis, GX 127/327/427, Urbanway, Arway, Crossway, Evadys, Magelys Tigril No. RV24.0003 OE No. 50.1055.6130 Description Wheel nut Remarks M22 x 1.5 H-31, wrench size 32mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 14

IVECO Tigril No. DB24.0021 OE No. 0112.1810 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 Tigril No. DB24.0022 OE No. 0341.4228 Description Washer (centering ring, wheel rim) Remarks 32 x 20.2 x 6 mm DIN - ISO: 74361 Tigril No. DB24.0023 OE No. 0112.1808 Description Washer (retaining ring, wheel rim) Remarks 29 x 18.5 x 7 mm DIN - ISO: 74361 Tigril No. DB24.0024 OE No. 0247.8940 Description Washer (centering ring, wheel rim) Remarks 26 x 18.2 x 3 mm DIN - ISO: 74361 EuroTrakker, AD/AT Trakker Tigril No. DB24.0027 OE No. 0112.1811 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 PA, M, TurboTech, TurboStar, P Tigril No. DB24.0028 OE No. 0342.0371 Description Washer (retaining ring, wheel rim) Remarks 32 x 22.2 x 5.5 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 15

MACK SS34/SS38/ST Series Tigril No. MK09.0023 OE No. 39QK433A Description Trunnion upper half Remarks Rear SS34/SS38/ST Series Tigril No. MK09.0024 OE No. 39QK431 Description Trunnion lower half Remarks Rear SS44 Series Tigril No. MK09.0025 OE No. 39QK326 Description Trunnion and bushing assembly Remarks Rear AL 40 Series Tigril No. MK09.0026 OE No. 57256-000 Description Torque rod bushing Remarks Rear Tigril No. MK09.0027 OE No. 1688-227710 Description Torque rod bushing Remarks 20-832 Tigril No. MK09.0028 OE No. 1688-227720 Description Torque rod bushing Remarks 20-833 Tigril No. MK09.0029 OE No. 47691 Description Torque rod bushing Remarks 20-836 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 16

MACK SS44 Series Tigril No. MK09.0019 OE No. 10QK157 Description Brass bush, trunnion (ID 3 1/2", OD 3 3/4"- L- 3 7/16") Remarks Rear SS65C-W Series Tigril No. MK09.0020 OE No. 80AX560 Description Brass bush, trunnion (OD- 5 1/4", ID- 5") Remarks Rear SS50C, SS58C Series Tigril No. MK09.0021 OE No. 10QK158A Description Brass bush, trunnion (OD - 4 1/4", ID - 4") Remarks Rear SS44 Series Tigril No. MK09.0022 OE No. 43QK116 Description Bronze thrust washer Remarks Rear SS34, SS38 Series Tigril No. MK09.0017 OE No. 23QJ112B Description Lock washer, trunnion shaft Remarks Rear SS34, SS38 Series Tigril No. MK09.0018 OE No. 43QK117 Description Spacer washer, trunnion Remarks Rear SS44 Series Tigril No. MK09.0010 OE No. 21AX786 Description Nut, trunnion collar lock (3/4"-16 TPI , 21/32" HT) Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 17

MACK SS Series Tigril No. MK09.0001 OE No. 1AX127 Description Bolt , trunnion collar (3/4" - 16TPI, L-5") Remarks Rear Tigril No. MK09.0032 OE No. 10QK219P2 Description Center trunnion bushing Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 18

MAN EL, F 2000, F 90, M 2000 L/M, M 90, NG/NL/NM/SD/SG/SU/SL Tigril No. MA08.0001 OE No. 81.44205.6013 Description King pin kit single Remarks Front L/R EL, F 2000, F 90, M 2000 L/M, M 90, NG/NL/NM/SD/SG/SU/SL Tigril No. MA08.0002 OE No. 81.44205.6013 Description King pin kit double Remarks Front L/R F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA08.0004 OE No. 81.44205.6023 Description King pin kit single Remarks Front F 2000, TGA, TGL, TGM, TGS, TGX Tigril No. MA08.0005 OE No. 81.44205.6030 Description King pin kit single Remarks Front EL/NL, F 2000, F/M 90, NG/ND Tigril No. DB09.0001 OE No. 81.35710.0044 Description Wear ring, wheel hub 115x145x32 Remarks Rear F 2000, F/M 90, SG/SL/SR Tigril No. DB09.0019 OE No. 81.35710.0045 Description Wear ring, wheel hub 110x145x32 Remarks Rear TGL, TGM, TGA, TGS, TGX, F 7/8/9, G/M/F 90, L/M/F 2000, CLA Tigril No. BP24.0005 OE No. 81.45422.0060 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 19

MAN E/F 2000, M 2000 L/M, TGA, TGM, TGS Tigril No. DB24.0002 OE No. 81.45501.0083 Description Wheel bolt Remarks M 22 x 1.5 x 125.5/115 mm, 10.9 E/F/L 2000, E/F 90, Lions/City classic, M 2000 M, NL/SG/SL, TGA, TGS, TGX Tigril No. DB24.0003 OE No. 81.45501.0067 Description Wheel bolt Remarks M 22 x 1.5 x 120.5/110 mm, 10.9 F 7/8/9, F/M 90, NG/SG/SL Tigril No. DB24.0004 OE No. 81.45501.0081 Description Wheel bolt Remarks M 22 x 1.5 x 115.5/105 mm, 10.9 F 7/8/9, M/F 90, L/M/F 2000, TGM, TGA/TGS Tigril No. DB24.0005 OE No. 81.45501.0059 Description Wheel bolt Remarks M 22 x 1.5 x 108.5/98.5 mm, 10.9 M/F 90, L 2000, M/F 2000 Tigril No. DB24.0007 OE No. 81.45501.0076 Description Wheel bolt Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 F/M 90, M 2000 M Tigril No. MA24.0001 OE No. 81.45501.0137 Description Wheel bolt Remarks M 22 x 1.5 x 99/89 mm, 10.9 E/F 90, E/F 2000, SG/SL, TGA, 3/4 Series, P,G,R,T Series Tigril No. BP24.0004 OE No. 81.45422.0060Set Description Wheel bolt set Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 20

MAN Tigril No. DB24.0037 OE No. 81.45501.0143S1 Description Wheel bolt set Remarks M 22 x 1.5 x 130.5/120 mm, 10.9 E/F 2000, M 2000 L/M, M2000M, TGA, TGM, TGS Tigril No. DB24.0038 OE No. 81.45501.0083S1 Description Wheel bolt set Remarks M 22 x 1.5 x 125.5/115 mm, 10.9 E/F/L 2000, E/F 90, Lions City, Lions Classic, M 2000M, NL/SG/SL, TGA, TGS, TGX Tigril No. DB24.0039 OE No. 81.45501.0067S1 Description Wheel bolt set Remarks M 22 x 1.5 x 120.5/110 mm, 10.9 E/F/L 2000, E/F 90, Lions City, Lions Classic, M 2000M, NL/ SG/SL, TGA, TGS, TGX Tigril No. DB24.0040 OE No. 81.45501.0067S2 Description Wheel bolt set Remarks M 22 x 1.5 x 120.5/110 mm, 10.9 F 7/8/9, F/M 90, NG/SG/SL Tigril No. DB24.0041 OE No. 81.45501.0081S1 Description Wheel bolt set Remarks M 22 x 1.5 x 115.5/105 mm, 10.9 F 7/8/9, F/M 90, NG/SG/SL Tigril No. DB24.0042 OE No. 81.45501.0081S2 Description Wheel bolt set Remarks M 22 x 1.5 x 115.5/105 mm, 10.9 F 7/8/9, M/F 90, L/M/F 2000, TGM, TGA, TGS Tigril No. DB24.0043 OE No. 81.45501.0059S1 Description Wheel bolt set Remarks M 22 x 1.5 x 108.5/98.5 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 21

MAN M/F 90, L 2000, M/F 2000 Tigril No. DB24.0046 OE No. 81.45501.0076S1 Description Wheel bolt set Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 M/F 90, L 2000, M/F 2000 Tigril No. DB24.0047 OE No. 81.45501.0076S2 Description Wheel bolt set Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 Tigril No. BP24.0002 OE No. 81.44050.0068 Description Wheel nut Remarks M22 x 2 H-25 wrench size-32 mm Tigril No. BP24.0006 OE No. 81.45423.0007 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm F/M 90, SG/SL/SR Tigril No. DB24.0016 OE No. 06.11222.0218 Description Wheel nut Remarks M22 x 1.5 H-22 wrench size-30 mm TGM, TGA/TGS/TGX, F/M 90, SG/SL/SR/SU Tigril No. DB24.0017 OE No. 81.45503.0026 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm TGA, EL/EM/NG/NL/NM/NU/R/SD/SG/SL/UL/G, F/L 2000, M 2000 L/M, F/M 90, LION Tigril No. DB24.0018 OE No. 06.11222.0215 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 22

MAN TGA, EL/EM/NG/NL/NM/NU/R/SD/SG/SL/UL Tigril No. DB24.0019 OE No. 06.11222.0213 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm Tigril No. DB24.0020 OE No. 06.11222.6309 Description Wheel nut Remarks M 14 x 1.5 H-16 wrench size-19 mm TGM, TGA/TGS/TGX, F 9, G/M/F 90, L/M/F 2000, SR, NL/NM Tigril No. IV24.0001 OE No. 81.45503.0030 Description Wheel nut Remarks M20 x 1.5 H-26.25 wrench size-30 mm TGA, EL/EM/NG/NL/NM/NU/R/SD/SG/SL/UL/G, F/L 2000, M 2000 L/M, F/M 90, LION Tigril No. DB24.0021 OE No. 81.45502.0000 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 TGA, F 2000, F/M 90, SL Tigril No. DB24.0027 OE No. 81.45502.0001 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 TGA/TGS, F 8/9, M/F 90, L/M/F 2000 Tigril No. DB24.0028 OE No. 81.45504.0008 Description Washer (retaining ring, wheel rim) Remarks 32 x 22.2 x 5.5 mm DIN - ISO: 74361 E 90/2000, F 90/2000, M 2000 L, TGA, SD/SG/SL/SUE Tigril No. BP24.0008 OE No. 81.91320.0048 Description Safety pin Remarks 41/30 x 2 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 23

MAN TGL, TGM, TGA, TGS, TGX, F 7/8/9, G/M/F 90, L/M/F 2000, CLA Tigril No. BP24.0011 OE No. 81.45421.0033 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 24

MERCEDES-BENZ MK/NG/SK Series Tigril No. DB08.0001 OE No. 343.330.02.19 Description King pin kit single Remarks Front Lower MK/NG/SK Series Tigril No. DB08.0002 OE No. 343.330.02.19S Description King pin kit double Remarks Front Lower O 307, O 404, T2/L MK/NG/SK Series Tigril No. DB08.0003 OE No. 391.330.00.19 Description King pin kit single Remarks Front L/R O 307, O 404, T2/L MK/NG/SK Series Tigril No. DB08.0004 OE No. 391.330.00.19S Description King pin kit double Remarks Front L/R Actros, Actros MP 2/3, Antos, Atego, Axor, Axor 2, Econic, MK/NG/SK/T2L Series Tigril No. DB09.0001 OE No. 346.356.14.15 Description Wear ring, wheel hub 115x145x32 Remarks Rear Actros, Actros MP 2/3, Atego, Axor 2, Econic, O 305/7, 405/7/8, MK/NG/SK Series Tigril No. DB09.0019 OE No. 355.356.12.15 Description Wear ring, wheel hub 110x145x32 Remarks Rear Actors MP 2/3/4, Atego 1, Axor, Axor 2, Integro, Travego, Tourismo Tigril No. DB09.0061 OE No. 946.356.00.15 Description Wear ring, wheel hub 119x145x26 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 25

MERCEDES-BENZ Tigril No. DB24.0050 OE No. 620.402.03.04 Description Wheel spider Remarks Rear 604.260.232 Actros 1/2/3, Atego, Axor, MK/NG/SK Series Tigril No. BP24.0005 OE No. 620.401.01.70 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 81.45501.0143 Tigril No. DB24.0001 OE No. 81.45501.0084 Description Wheel bolt Remarks M 22 x 1.5 x 130.5/120 mm, 10.9 Tigril No. DB24.0001 OE No. 381.401.09.71 Description Wheel bolt Remarks M 22 x 1.5 x 130.5/120 mm, 10.9 Atego, Axor, LK/MK/NG Series, O 500 Tigril No. DB24.0002 OE No. 381.401.08.71 Description Wheel bolt Remarks M 22 x 1.5 x 125.5/115 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, O 371/400/500, Zetros Tigril No. DB24.0003 OE No. 381.401.07.71 Description Wheel bolt Remarks M 22 x 1.5 x 120.5/110 mm, 10.9 Actros, Atego up to 18 t, Axor, Citaro, Conecto, Evobus, Integro, Intouro, MK/SK Series Tigril No. DB24.0004 OE No. 381.401.06.71 Description Wheel bolt Remarks M 22 x 1.5 x 115.5/105 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 26

MERCEDES-BENZ Actros, Atego, Atego up to 18 t, Axor, NG/SK, Tourismo, Zetros Tigril No. DB24.0005 OE No. 381.401.05.71 Description Wheel bolt Remarks M 22 x 1.5 x 108.5/98.5 mm, 10.9 NG Series O 120/140/170/302/330/355/362/364/365/370/371 Tigril No. DB24.0006 OE No. 381.401.03.71 Description Wheel bolt Remarks M 22 x 1.5 x 99/88.5 mm, 10.9 Tigril No. DB24.0006 OE No. 81.45501.0137 Description Wheel bolt Remarks M 22 x 1.5 x 99/88.5 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, Conecto,O 301/302/303/304/305/307/317/330/340 Tigril No. DB24.0007 OE No. 389.401.00.71 Description Wheel bolt Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 Actros 1/2/3, Atego 1, Arocs, Axor, MK/NG Series Tigril No. DB24.0008 OE No. 338.401.50.71 Description Wheel bolt Remarks M 22 x 1.5 x 71/63 mm, 10.9 Atego 1/2, LK/LN Series O 170/301/402/814/817, Vario Tigril No. DB24.0009 OE No. 327.402.0371 Description Wheel bolt Remarks M 20 x 1.5 x 97/89 mm, 10.9 Atego 1/2, LK/LN Series O 814/817 Tigril No. DB24.0010 OE No. 327.402.0271 Description Wheel bolt Remarks M 20 x 1.5 x 92/84 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 27

MERCEDES-BENZ LK/LN/LP Series O 120/140/170/302/303/330/355/362/364/365/814/817 Tigril No. DB24.0011 OE No. 312.402.10.71 Description Wheel bolt Remarks M 20 x 1.5 x 80/72 mm, 10.9 Atego 1/2, LP Series O 301/402/814/817 Tigril No. DB24.0012 OE No. 327.401.00.71 Description Wheel bolt Remarks M 22 x 1.5 x 70/62 mm, 10.9 Atego, LK/LP/T2 Series O 301/309/402/814/817, Vario Tigril No. DB24.0013 OE No. 324.402.00.71 Description Wheel bolt Remarks M 18 x 1.5 x 68/60 mm, 10.9 Atego, LK/LN/LP/T2 Series O 301/402/814/817, Vario Tigril No. DB24.0014 OE No. 318.402.00.71 Description Wheel bolt Remarks M 18 x 1.5 x 73/65 mm, 10.9 LK/T2 Series O 301/309/402/814, Sprinter, Vario Tigril No. DB24.0015 OE No. 319.402.04.71 Description Wheel bolt Remarks M 14 x 1.5 x 67/60 mm, 10.9 Actros MP2/3, Axor 2 Tigril No. DB24.0030 OE No. 620.401.00.70 Description Wheel bolt Remarks M 20 x 2 x 57/55 mm, 10.9 Tigril No. DB24.0051 OE No. 942.401.02.71 Description Wheel bolt Remarks M22 x 1,5 x 78.5/68 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 28

MERCEDES-BENZ Actros MP 2/3, Actros, Atego 1, Axor, Econic 1/2 Tigril No. DB24.0052 OE No. 942.401.03.71 Description Wheel bolt Remarks M22 x 1,5 x 101.5/91 mm, 10.9 NG Series Tigril No. MA24.0001 OE No. 389.401.01.71 Description Wheel bolt Remarks M 22 x 1.5 x 99/89 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, MK/NG/SK Series Tigril No. BP24.0004 OE No. 620.401.01.70Set Description Wheel bolt set Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Actros MP2/3, Axor 2 Tigril No. DB24.0029 OE No. 620.401.00.70Set Description Wheel bolt set Remarks M 20 x 2 x 57/55, 10.9 mm, 10.9 LK/LN/LP Series O 120/140/170/302/303/330/355/362/364/365/814/817 Tigril No. DB24.0031 OE No. 352.402.01.71S1 Description Wheel bolt set Remarks M 20 x 1.5 x 80/72 mm, 10.9 Atego, LK/LN Series O 170/301/402/814/817, Vario Tigril No. DB24.0032 OE No. 327.402.03.71S1 Description Wheel bolt set Remarks M 20 x 1.5 x 97/89 mm, 10.9 Atego, LK/LN Series O 814/817 Tigril No. DB24.0033 OE No. 327.402.02.71S1 Description Wheel bolt set Remarks M 20 x 1.5 x 92/84 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 29

MERCEDES-BENZ Atego 1/2, LP Series O 301/ 402/814/817 Tigril No. DB24.0034 OE No. 318.402.02.71S1 Description Wheel bolt set Remarks M 20 x 1.5 x 70/62 mm, 10.9 Atego, LK/LP Series O 301/309/402/814/817, T2, Vario Tigril No. DB24.0035 OE No. 324.402.00.71S1 Description Wheel bolt set Remarks M 18 x 1.5 x 68/60 mm, 10.9 Atego, LK/LN/LP Series O 301/402/814/817, T2, Vario Tigril No. DB24.0036 OE No. 318.402.00.71S1 Description Wheel bolt set Remarks M 18 x 1.5 x 73/65 mm, 10.9 Tigril No. DB24.0037 OE No. 381.401.09.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 130.5/120 mm, 10.9 Atego, Axor, LK/MK/NG Series O 500 Tigril No. DB24.0038 OE No. 381.401.08.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 125.5/115 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, O 371/400/500, Zetros Tigril No. DB24.0039 OE No. 381.401.07.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 120.5/110 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, O 371/400/ 500, Zetros Tigril No. DB24.0040 OE No. 381.401.07.71S2 Description Wheel bolt set Remarks M 22 x 1.5 x 120.5/110 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 30

MERCEDES-BENZ Actros, Atego up to 18 t, Axor, Citaro, Conecto, Evobus, Integro, Intouro, MK/SK Series Tigril No. DB24.0041 OE No. 381.401.0671S1 Description Wheel bolt set Remarks M 22 x 1.5 x 115.5/105 mm, 10.9 Actros, Atego up to 18 t, Axor, Citaro, Conecto, Evobus, Integro, Intouro, MK/SK Series Tigril No. DB24.0042 OE No. 381.401.0671S2 Description Wheel bolt set Remarks M 22 x 1.5 x 115.5/105 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, NG/SK Series, Tourismo, Zetros Tigril No. DB24.0043 OE No. 381.401.05.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 108.5/98.5 mm, 10.9 NG, O 120/140/170/302/330/355/362/364/365/370/371 Tigril No. DB24.0044 OE No. 381.401.03.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 99/88.5 mm, 10.9 NG Series, O 120/140/170/302/330/355/362/364/365/370/371 Tigril No. DB24.0045 OE No. 381.401.03.71S2 Description Wheel bolt set Remarks M 22 x 1.5 x 99/88.5 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, Conecto, O 301/302/303/304/305/307/317/330/340 Tigril No. DB24.0046 OE No. 389.401.00.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 Actros, Atego, Atego up to 18 t, Axor, Conecto, O 301/302/303/304/305/307/317/330/340 Tigril No. DB24.0047 OE No. 389.401.00.71S2 Description Wheel bolt set Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 31

MERCEDES-BENZ Actros, Arocs, Axor, MK/NG Series Tigril No. DB24.0048 OE No. 338.401.50.71S1 Description Wheel bolt set Remarks M 22 x 1.5 x 71/63 mm, 10.9 LK, O 301/ 309/402/814, Sprinter, T2, Vario Tigril No. DB24.0049 OE No. 319.402.04.71S1 Description Wheel bolt set Remarks M 14 x 1.5 x 67/60 mm, 10.9 Actros MP 2/3, Actros, Atego, Axor 2, SK/MK/NG Series Tigril No. DB24.0053 OE No. 942.401.02.71S1 Description Wheel bolt set Remarks M22 x 1,5 x 78.5/68 mm, 10.9 Actros MP 2/3, Actros, Atego, Axor 2, Econic Tigril No. DB24.0054 OE No. 942.401.03.71S1 Description Wheel bolt set Remarks M22 x 1,5 x 101.5/91 mm, 10.9 Actros, Atego, Axor, MK/NG/SK Series Tigril No. BP24.0006 OE No. 346.401.50.72 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm Actros 1/2/3 , Atego, Axor, LK/LN/MK/NG Series, O 302/303/304/305 Tigril No. DB24.0016 OE No. 074361.022205 Description Wheel nut Remarks M22 x 1.5 H-22 wrench size-30 mm Atego, Atego up to 18 t, Axor, Citaro, NG Series O 371/374/400/404/500, S 411/415/416 Tigril No. DB24.0017 OE No. 385.400.01.24 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 32

MERCEDES-BENZ Atego, LK/LN/LP Series O/140/170/301/302/402/814/817 Tigril No. DB24.0018 OE No. 074361.020204 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm Atego, LK/LP/T2 Series O 309/814/817, Vario Tigril No. DB24.0019 OE No. 074361.018205 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm Atego up to 18 t, Axor, Conecto, Econic, O 309/404/405/407/408, Sprinter, T2, Tourismo Tigril No. DB24.0020 OE No. 074361.014205 Description Wheel nut Remarks M 14 x 1.5 H-16 wrench size-19 mm Tigril No. IV24.0001 OE No. 000.990.61.53 Description Wheel nut Remarks M20 x 1.5 H-26.25 wrench size-30 mm Actros 1/2/3, Axor Tigril No. BP24.0007 OE No. 620.990.02.40 Description Washer Remarks 36.9 x 21.2 x 2.75 mm Atego, LK/LN/LP/NG Series O 120/140/170/301/302/402/ 814/817, Tourino Tigril No. DB24.0021 OE No. 074361.020352 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 Atego 1/2, LK/LN/LP Series Tigril No. DB24.0022 OE No. 066.402.00.75 Description Washer (centering ring, wheel rim) Remarks 32 x 20.2 x 6 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 33

MERCEDES-BENZ Actros, Actros MP 2/3Atego, Axor, LK/LN 2/NG/MK/SK/LP/T2 Series Tigril No. DB24.0023 OE No. 074361.018352 Description Washer (retaining ring, wheel rim) Remarks 29 x 18.5 x 7 mm DIN - ISO: 74361 Actros, Actros MP 2/3, Atego, Axor, LK/LN 2/NG/MK/SK Series Tigril No. DB24.0024 OE No. 324.997.00.26 Description Washer (centering ring, wheel rim) Remarks 26 x 18.2 x 3 mm DIN - ISO: 74361 Actros, Actros MP 2/3, Atego, Axor, LK/LN 2/LP/MK/NG/SK Series Tigril No. DB24.0025 OE No. 074361.014351 Description Washer (retaining ring, wheel rim) Remarks 23 x 14.5 x 5 mm DIN - ISO: 74361 Actros, Actros MP 2/3, Atego, Axor, LK/LN 2/LP/MK/NG/SK Series Tigril No. DB24.0026 OE No. 319.402.00.75 Description Washer (retaining ring, wheel rim) Remarks 24 x 14.1 x 3 mm DIN - ISO: 74361 Actros 1/2/3, Arocs, Atego, Axor, Citaro, Conecto, Tourismo, LK/LN/MK/NG/SK Series Tigril No. DB24.0027 OE No. 074361.022351 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 Actros 1, Arocs, Atego, Axor, Citaro, Conecto, LK/LN/MK/NG/SK Series Tigril No. DB24.0028 OE No. 317.402.01.75 Description Washer (retaining ring, wheel rim) Remarks 32 x 22.2 x 5.5 mm DIN - ISO: 74361 Tigril No. BP24.0008 OE No. 000.994.22.60 Description Safety pin Remarks 41/30 x 2 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 34

MERCEDES-BENZ Actros MP2/3, Axor 2 Tigril No. BP24.0011 OE No. 620.402.00.68 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 35

NEOPLAN SG/SÜ, ÜL/RH, Lion's Classic Tigril No. DB24.0005 OE No. 0821.210.19 Description Wheel bolt Remarks M 22 x 1.5 x 108.5/98.5 mm, 10.9 SL/SG/SÜ, NL/NG/ND/NM, EL/ÜL, Lion's Classic Tigril No. DB24.0007 OE No. 0801.116.26 Description Wheel bolt Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 SG/SÜ, ÜL/RH, Lion's Classic Tigril No. DB24.0043 OE No. 0821.210.19 Description Wheel bolt set Remarks M 22 x 1.5 x 108.5/98.5 mm, 10.9 SL/SG/SÜ, NL/NG/ND/NM, EL/ÜL, Lion's Classic Tigril No. DB24.0046 OE No. 0801.116.26S1 Description Wheel bolt set Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 SL/SG/SÜ, NL/NG/ND/NM, EL/ÜL, Lion's Classic Tigril No. DB24.0047 OE No. 0801.116.26S2 Description Wheel bolt set Remarks M 22 x 1.5 x 91/80.5 mm, 10.9 Citelis, CityClass, Arway, Crossway, EuroClass, Urbanway Tigril No. DB24.0027 OE No. 5290.022.00 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 36

RENAULT CHB/CLM, G, Manager, R, Major, Kerax, K Tigril No. BP24.0005 OE No. 74.01.608.293 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. DB24.0030 OE No. 74.01.588.406 Description Wheel bolt Remarks M 20 x 2 x 57/55 mm, 10.9 Tigril No. DB24.0029 OE No. 74.01.588.406Set Description Wheel bolt set Remarks M 20 x 2 x 57/55, 10.9 mm, 10.9 Premium II TR/PR/ DXi 7, Kerax /DXi 11/13, Magnum DXi 12/13 Tigril No. RV24.0001 OE No. 74.20.515.519 Description Wheel bolt with nut Remarks M22 x 1.5x 105/75 mm, 10.9 Midlum II DXi 5/7, Premium II TR/PR/ DXi 7, Magnum DXi 12/13, K/T Tigril No. VO24.0004 OE No. 74.20.515.516 Description Wheel bolt set Remarks M 22 x1.5 101 mm, 10.9 Tigril No. BP24.0006 OE No. 74.00.362.166 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm Manager, Maxter, R, Major, Midlum, Premium /TR/PR, Premium II DXi 7, Kerax, AE, AE Mag Tigril No. RV24.0002 OE No. 74.21.402.076 Description Wheel nut Remarks M22 x 1.5 x H-30, wrench size 33 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 37

RENAULT Manager, Maxter, R, Major, Midlum, Premium /TR/PR, Premium II DXi 7, Kerax, AE, AE Mag Tigril No. RV24.0003 OE No. 50.00.653.117 Description Wheel nut Remarks M22 x 1.5 H-31, wrench size 32mm Tigril No. BP24.0008 OE No. 74.01.581.380 Description Safety pin Remarks 41/30 x 2 mm C/CBH/CLM, G, Manager, R, Major, Kerax, K Tigril No. BP24.0011 OE No. 74.01.581.193 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 38

ROR TM Axles Tigril No. RO09.0008 OE No. 212.045.62 Description Wheel hub Remarks Rear Tigril No. RO09.0001 OE No. 190.16.378A Description Equalizer w/o bush straight bore Remarks Rear Tigril No. RO09.0002 OE No. 212.03.141 Description Equalizer w/o bush conical bore Remarks Rear SMT Axles Tigril No. RO09.0006 OE No. 212.06.000 Description Bolt equalizer 41 mm Remarks Rear SMT Axles Tigril No. RO09.0007 OE No. 212.02.094 Description Bolt equalizer 31.70 mm Remarks Rear M Series suspension Tigril No. RO09.0004 OE No. 212.04.055 Description Torque arm rigid long Remarks Rear M Series suspension Tigril No. RO09.0005 OE No. 212.06.140 Description Torque arm rigid short Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 39

ROR TA/TC, TM Tigril No. RO24.0001 OE No. 210.20.997 Description Wheel bolt Remarks M 22 x 1.5 x 107/98 mm, 10.9 LM, TA, TE, TM Tigril No. DB24.0017 OE No. 212.03.099 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm Tigril No. DB24.0027 OE No. 210.06.512 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 40

SAF HOLLAND Tigril No. BP09.0047 OE No. 4.177.3016.00 Description Bush (PU), connecting rod 36 mm Remarks Tigril No. BP24.0002 OE No. 4.342.0015.00 Description Wheel nut Remarks M22 x 2 H-25 wrench size-32 mm Tigril No. BP24.0003 OE No. 4.342.0009.11 Description Wheel nut Remarks M22 x 2 H-17 wrench size-32 mm KRS/KRZ/KRZM/SK/SKRS/SKRLS/WRLZM Tigril No. DB24.0017 OE No. 4.247.3012.00 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm RLSM, RZM Tigril No. RV24.0003 OE No. 2.247.3010.01 Description Wheel nut Remarks M22 x 1.5 H-31, wrench size 32mm Tigril No. DB24.0021 OE No. 4.141.1002.00 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 Tigril No. DB24.0027 OE No. 4.141.1003. 00 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 41

SCANIA 2/3/4 Series, P,G,R,T Series Tigril No. BP24.0005 OE No. 289.535 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. DB24.0030 OE No. 338.883 Description Wheel bolt Remarks M 20 x 2 x 57/55 mm, 10.9 Tigril No. BP24.0004 OE No. 289.535Set Description Wheel bolt set Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. DB24.0029 OE No. 338.883Set Description Wheel bolt set Remarks M 20 x 2 x 57/55, 10.9 mm, 10.9 P, G, R, T, 2/3/4 Series Tigril No. BP24.0006 OE No. 279.574 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm 2/3/4 Series, 4-/F-/K-/N-Series DSC-DC 9, DSC-OSC-DC 11, DSC-DC-DT 12, DSC 14, DC 16 Tigril No. DB24.0018 OE No. 1.315.273 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm P, G, R, T, 2/3/4 Series Tigril No. BP24.0007 OE No. 290.405 Description Washer Remarks 36.9 x 21.2 x 2.75 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 42

SCANIA P, G, R, T, 3/4 Series, SB 3000, TB 2175 Tigril No. BP24.0008 OE No. 265.446 Description Safety pin Remarks 41/30 x 2 mm P-/G-/R-/T-Series Tigril No. BP24.0011 OE No. 278.874 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 43

SETRA Tigril No. BP09.0050 OE No. 8.241.030.286 Description Hub cap, 13-14 T, outer thread Remarks M135x3 SW120/700Nm Tigril No. BP09.0052 OE No. 8.241.999.464 Description Hub cap, 10-12 T, outer thread Remarks M125x2 SW110/500Nm Tigril No. BP24.0003 OE No. 8.241.000.483 Description Wheel nut Remarks M22 x 2 H-17 wrench size-32 mm Tigril No. DB24.0017 OE No. 8.241.999.726 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm Tigril No. DB24.0018 OE No. 0.174.361.056 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm Tigril No. DB24.0019 OE No. 0.174.361.058 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm Tigril No. DB24.0021 OE No. 0.174.361.105 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 44

SETRA Tigril No. DB24.0027 OE No. 0.274.361.104 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 45

TRAILER Trailer Tigril No. TR24.0001 OE No. Description Spacing rings Remarks Rear Trailer Tigril No. TR09.0001 OE No. 6115000X Description Bush, leaf spring Remarks Rear Trailer Tigril No. TR10.0001 OE No. Description Polyamide bush Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 46

UNIVERSAL Tigril No. DI24.0011 OE No. Description Wheel rim 9 x 22.50 HD 14 thk 10H 175 offset Remarks Front & Rear Tigril No. DI24.0012 OE No. Description Wheel rim 8.5 x 24 HD 16 thk Remarks Front & Rear Tigril No. DI24.0013 OE No. Description Wheel rim 11.75 x 22.50 HD 14 thk 10H 0 offset Remarks Rear Tigril No. DI24.0014 OE No. Description Wheel rim 8.5 x 24 HD 14 thk Remarks Front & Rear Tigril No. DI24.0015 OE No. Description Wheel rim 8.5 x 24 HD 16 thk 2H Remarks Front & Rear Tigril No. DI24.0016 OE No. 387.401.05.05 Description Wheel rim 8.5 x 24 3 pcs Remarks 650.410.357 Rear Tigril No. DI24.0017 OE No. Description Wheel rim 8.5 x 24 HD 14 thk 5H Remarks Front & Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 47

UNIVERSAL Tigril No. DI24.0018 OE No. Description Wheel rim 9 x 22.50 HD 13 thk 10H 175 offset Remarks Front & Rear Tigril No. DI24.0019 OE No. Description Wheel rim 11.75 x 22.50 HD 14 thk 10H 120 offset Remarks Front Tigril No. DI24.0020 OE No. Description Wheel rim 7.5 x 19.50 HD 12 thk 8H 152 offset Remarks Tigril No. DI24.0021 OE No. Description Wheel rim 6 x 17.50 HD 12 thk 6H 118 offset Remarks Tigril No. DI24.0022 OE No. Description Wheel rim 9.75 x 22.50 14 thk 10H Remarks Front & Rear Tigril No. DI24.0023 OE No. Description Hex bolt with nut Remarks Tigril No. DI24.0024 OE No. Description Hex bolt with nut Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 48

UNIVERSAL Tigril No. DI24.0025 OE No. Description Wheel bolt set Remarks Tigril No. DI24.0000 OE No. Description Wheel spanner 27 x 32 Remarks Universal application (heavy duty) Tigril No. DI24.0001 OE No. Description Wheel spanner 30 x 32 Remarks Universal application (heavy duty) Tigril No. DI24.0002 OE No. Description Wheel spanner 32 x 33 Remarks Universal application (heavy duty) Tigril No. DI24.0003 OE No. Description Wheel spanner 27 x 32 Remarks Universal application (heavy duty) Tigril No. DI24.0004 OE No. Description Wheel spanner 30 x 32 Remarks Universal application (heavy duty) Tigril No. DI24.0005 OE No. Description Wheel spanner 27 x 32 with bar Remarks Universal application (heavy duty) OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 49

UNIVERSAL Tigril No. DI24.0006 OE No. Description Wheel spanner 30 x 32 with bar Remarks Universal application (heavy duty) Tigril No. DI24.0007 OE No. Description Wheel spanner 32 x 33 with bar Remarks Universal application (heavy duty) Tigril No. DI24.0009 OE No. Description Wheel spanner 20 x 38 with tommy bar Remarks Universal application (heavy duty) Tigril No. DI24.0010 OE No. Description Wheel spanner 21 x 41 with tommy bar Remarks Universal application (heavy duty) Tigril No. DI24.0008 OE No. Description Tommy bar Remarks Universal application (heavy duty) OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 50

VOLVO B 12, F 10/12/16/7, FH 16, FM 10/12/7, FL 10/6/7/12, FS 7, N 10/7, NH12 Tigril No. VO08.0001 OE No. 3.090.267S Description King pin kit with bearing Remarks Front L/R B 12, F 10/12/16/7, FL 10/6/7/12, FS 7, N 10/8 Tigril No. VO08.0002 OE No. 3.090.266S Description King pin kit with bearing Remarks Front L/R FL 10, FM 7/10/12 Tigril No. VO08.0003 OE No. 1.699.357 Description King pin kit single Remarks Front L/R FM 7 Tigril No. VO08.0004 OE No. 3.092.467 Description King pin kit single Remarks Front L/R F/FL 6, F/FE/FL/FM 7, FH/FM/FMX/NH 9/10/11/12/13/16 Tigril No. VO08.0005 OE No. 20.751.021 Description King pin kit with bearing Remarks Front & Rear L/R FH 12/16, FH/FM, FMX, NH 12, F 10/12/16, FL 7/10/12, FM 7/9/10/12, N 10/12 Tigril No. BP24.0005 OE No. 1.608.293 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 FM 7/9/10/12, F 10/12/16, FL 6/7/10/12, N 10/12, FH 12/16, FH/FM, FMX, NH 12 /BR Tigril No. DB24.0030 OE No. 1.588.406 Description Wheel bolt Remarks M 20 x 2 x 57/55 mm, 10.9 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 51

VOLVO B 10 B/M/R, B 12, B 12M, B 58, B 7/7F/7R, F 10/12/16, FH 12/16, FL 10/12/6/7, FM 10/12 Tigril No. VO24.0001 OE No. 1.573.081 Description Wheel bolt Remarks 7/8" - 14UNF x 94/84 mm, 10.9 B 10M, B 12 B/M, B 7R, B 9R, F 10/12/16, FH, FH 12/16, FL 10/12/7, FM 10/12/7/9, N 10 Tigril No. VO24.0002 OE No. 1.589.009 Description Wheel bolt Remarks 7/8" - 14UNF x 121/111 mm, 10.9 B 10M, B 58, F 10/12/16, FH, FH 12/16, FL 10/12/7, FM, FM 10/12/7/9, N 10/12, NH 12 Tigril No. BP24.0004 OE No. 1.608.293Set Description Wheel bolt set Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 FM 7/9/10/12, F 10/12/16, FL 6/7/10/12, N 10/12, FH 12/16, FH/FM, FMX, NH 12 /BR Tigril No. DB24.0029 OE No. 1.588.406Set Description Wheel bolt set Remarks M 20 x 2 x 57/55, 10.9 mm, 10.9 FL 6, FE, FH 12/16, FM 9/12, FH/FM, FMX, NH 12 Tigril No. RV24.0001 OE No. 20.515.519 Description Wheel bolt with nut Remarks M22 x 1.5x 105/75 mm, 10.9 FM, FMX, FL Tigril No. VO24.0004 OE No. 20.515.516 Description Wheel bolt set Remarks M 22 x1.5 101 mm, 10.9 Tigril No. BP24.0006 OE No. 362.166 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 52

VOLVO FL 6, FS 7 Tigril No. DB24.0017 OE No. 947.972 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm FL, FM 7/9/11/12, F 10/12/16, FL 6/7/10/12, FH 12/16 Tigril No. DB24.0018 OE No. 1.697.091 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm FL, FL 6 Tigril No. IV24.0001 OE No. 947.971 Description Wheel nut Remarks M20 x 1.5 H-26.25 wrench size-30 mm F 10/12/16, FL 6/7/10/12, FM 7/9/10/12, FL/FE/FH/FM, FH 12/16, FMX, NH 12 /BR Tigril No. RV24.0002 OE No. 21.402.076 Description Wheel nut Remarks M22 x 1.5 x H-30, wrench size 33 mm B 10 B/L/M/R, B 12, B 12 B/M, B 58, B 7, B 7 F/L/R, B 9R Tigril No. VO24.0003 OE No. 1.083.894 Description Wheel nut Remarks 7/8" - 14UNF - 1B H-34 wrench size-33 mm FH 12/16, FH/FM, FMX, NH 12, FM 7/9/10/12, FL 7/10/12, F 10/12/16 Tigril No. BP24.0007 OE No. 1.581.381 Description Washer Remarks 36.9 x 21.2 x 2.75 mm Tigril No. BP24.0008 OE No. 1.581.380 Description Safety pin Remarks 41/30 x 2 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 53

VOLVO FH 12/16, FM 9/10/12, FH/FM, FMX, NH 12 /BR, F 10/12/16, FL 7/10/12, N 10/12 Tigril No. BP24.0011 OE No. 1.581.193 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 54

Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 54 BP09.0001 05.291.01.14.0 4 BP09.0002 05.291.01.11.0 4 BP09.0003 4 BP09.0004 05.443.71.55.0 5 BP09.0005 05.443.70.77.0 6 BP09.0005 05.443.70.11.0 6 BP09.0005 05.443.70.15.1 6 BP09.0005 05.443.70.16.1 6 BP09.0005 05.443.70.26.0 6 BP09.0005 05.443.70.31.0 6 BP09.0005 05.443.70.61.0 6 BP09.0005 05.443.70.66.0 6 BP09.0005 05.443.70.70.0 6 BP09.0005 05.443.70.79.0 6 BP09.0006 05.443.48.35.0 6 BP09.0007 05.443.46.03.0 6 BP09.0009 05.113.93.03.0 6 BP09.0009 02.031.33.05.0 6 BP09.0010 05.113.97.10.0 5 BP09.0011 03.112.76.13.0 4 BP09.0012 03.112.76.14.0 5 BP09.0014 03.262.17.11.0 7 BP09.0014 03.26217.03.0 7 BP09.0015 03.262.17.08.0 7 BP09.0016 03.262.17.12.0 7 BP09.0018 4 BP09.0020 03.272.48.46.0 1 BP09.0020 03.272.48.40.0 1 BP09.0021 03.272.62.27.0 1 BP09.0021 03.272.62.06.0 1 BP09.0021 03.272.62.19.0 1 BP09.0021 03.272.62.20.0 1 BP09.0022 03.272.80.14.0 1 BP09.0022 03.272.80.07.0 1 BP09.0022 03.272.80.10.0 1 BP09.0022 03.272.80.18.0 1 BP09.0022 03.272.80.19.0 1 BP09.0024 05.370.07.04.0 2 BP09.0025 03.310.99.02.0 3 BP09.0025 03.310.99.15.0 3 BP09.0026 03.310.99.01.0 3 BP09.0026 03.310.99.16.0 3 BP09.0027 03.212.26.01.0 1 BP09.0028 05.113.93.03.0PU 6 BP09.0031 05.443.71.02.0 6 BP09.0032 03.272.80.86.0 1 BP09.0032 03.272.80.18.0 1 BP09.0032 03.272.80.06.0 1 BP09.0032 03.272.80.07.0 1 BP09.0032 03.272.86.10.0 1 BP09.0037 03.177.17.04.0 5 BP09.0038 03.177.16.17.0 5 BP09.0039 03.177.16.20.0 5 BP09.0040 13.177.17.05.0 5 BP09.0043 03.272.30.97.0 1 BP09.0043 03.272.30.95.0 1 BP09.0044 03.272.48.32.0 1 BP09.0044 03.272.48.07.0 1 BP09.0044 03.272.48.10.0 1 BP09.0044 03.272.48.12.0 1 BP09.0044 -03.272.48.35.0 1 BP09.0047 05.113.93.03.0 6 BP09.0047 02.031.33.50.0 6 BP09.0047 4.177.3016.00 41 BP09.0048 03.212.25.31.0 2 BP09.0048 03.212.25.33.0 2 BP09.0048 05.212.25.31.0 2 BP09.0049 03.212.27.01.0 2 BP09.0049 -03.212.07.01.0 2 BP09.0050 03.212.25.02.0 2 BP09.0050 03.212.05.01.0 2 BP09.0050 8.241.030.286 44 BP09.0051 03.212.26.14.0 2 BP09.0051 03.212.26.20.0 2 BP09.0052 03.212.24.07.0 2 BP09.0052 8.241.999.464 44 BP09.0053 03.212.25.08.0 2 BP09.0053 -03.212.25.23.0 2 BP09.0055 05.370.07.43.0 3 BP09.0056 05.370.07.20.0 3 BP09.0057 4 BP09.0058 4 BP24.0001 03.296.23.17.0 7 BP24.0002 03.260.04.01.0 8 BP24.0002 144.922 11 BP24.0002 0.144.922 11 BP24.0002 81.44050.0068 22 BP24.0002 4.342.0015.00 41 BP24.0002 4.342.0015.10 41 BP24.0003 03.260.04.06.0 8 BP24.0003 61.437.11.51.7 8 BP24.0003 4.342.0009.11 41 BP24.0003 8.241.000.483 44 BP24.0004 02.507.03.20.0Set 8 BP24.0004 02.507.03.70.0Set 8 BP24.0004 81.45422.0060Set 20 BP24.0004 620.401.01.70Set 29 BP24.0004 289.535Set 42 BP24.0004 1.608.293Set 52 BP24.0004 1.581.604Set 52 BP24.0005 02.507.03.20.0 7 BP24.0005 02.507.03.70.0 7 BP24.0005 81.45422.0060 19 BP24.0005 81.4522.0060 19 BP24.0005 620.401.01.70 26 BP24.0005 74.01.608.293 37 BP24.0005 289.535 42 BP24.0005 1.608.293 51 BP24.0005 1.581.604 51 BP24.0006 02.527.00.40.0 9 BP24.0006 678.250 11 BP24.0006 0247.8508 14 BP24.0006 6013.6381 14 BP24.0006 81.45423.0007 22
