Spare Parts For Commercial Vehicles

Spare Parts Catalogue for Commercial Vehicles Version 01/2022 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI BPW Page 1 DAF Page 27 Fendt Page 86 Fruehauf Page 88 Iveco Page 95 Mack Page 123 MAN Page 129 Mercedes-Benz Page 182 Neoplan Page 292 Renault Page 303 ROR Page 341 SAF Holland Page 348 Scania Page 355 Setra Page 391 Trailer Page 402 Universal Page 405 Volvo Page 422 Index I (Tigril No - OE No) Page 472 Index II (OE No - Tigril No) Page 574

BPW Tigril No. DB14.0066 OE No. 02.431.12.80.0 Description 3/2 Directional control valve Remarks 463.036.000.0 3XL Tigril No. BP09.0029 OE No. 02.101.40.62.5 Description Leaf spring Remarks 100 x 15 x 1250 Rear 3XL Tigril No. BP09.0030 OE No. 02.101.40.62.5 Description Leaf spring Remarks 100 x 14 x 1250 Rear 3XL Tigril No. BP09.0033 OE No. 02.101.40.62.6 Description Leaf spring Remarks 100 x 14 x 1250 Rear BPW 3 AXL Tigril No. BP09.0041 OE No. 02.101.40.62.5 Description Leaf spring Remarks 100x12x1245 Rear VB, VBT Tigril No. BP09.0045 OE No. 05.082.06.01.0 Description Leaf spring 16 T Remarks Thickness:12mm, Weight:102.6KG (14 leaves) VB, VBT Tigril No. BP09.0046 OE No. 05.082.06.01.0 Description Leaf spring 16 T Remarks Thickness:14mm;Weight:120KG (14 leaves) OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1

BPW W/BW/GW suspension Tigril No. BP09.0017 OE No. 03.140.16.01.0 Description Spring cushion for leaf spring 12-20 T axle Remarks Rear W Series Tandem axle suspension Tigril No. BP09.0054 OE No. 03.140.14.01.0 Description Spring cushion for leaf spring 8-12 ton axle Remarks H : 151 W/BW/GW suspension Tigril No. BP09.0013 OE No. 03.112.99.04.0 Description Bush, leaf spring (suspension) brass 12-20 T Remarks Rear W 8-12 T Tigril No. BP09.0019 OE No. 03.112.99.02.0 Description Bush, leaf spring (suspension) brass 8-12 T Remarks Rear BPW Tigril No. BP09.0059 OE No. 03.224.19.03.1 Description Mounting, leaf spring Remarks HIZW 2/16000 Tigril No. BP09.0035 OE No. 03.138.42.02.4 Description Spring clamp with nut Remarks M24/192 x 413 Rear HIZW 2/16000 Tigril No. BP09.0036 OE No. 03.138.61.17.0 Description Spring clamp with nut Remarks M36/289 x 640 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2

BPW Tigril No. BP09.0042 OE No. 03.221.89.02.0 Description Bracket Remarks Rear O/SL/AL Tigril No. BP10.0001 OE No. 05.429.41.36.1 Description Air spring with metal piston Remarks 3881-01C Front & Rear 30 K Tigril No. BP10.0003 OE No. 05.429.40.93.1 Description Air spring with metal piston Remarks Front & Rear 1 DK 21 K-1, 3940 C O/SL/AL Tigril No. BP10.0005 OE No. 05.429.40.28.1 Description Air spring with metal piston Remarks Front & Rear 3941 C O/SL/AL Tigril No. BP10.0002 OE No. 05.429.40.01.0 Description Air spring without piston with plate Remarks Front & Rear 881 MB, 3881 P 30 K O/SL/AL Tigril No. BP10.0004 OE No. 05.429.40.91.0 Description Air spring without piston with plate Remarks Front & Rear 940 MB, 3940 P O/SL/AL Tigril No. BP10.0006 OE No. 05.429.40.03.0 Description Air spring without piston with plate Remarks Front & Rear 941 MB, 3941-P OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3

BPW Tigril No. DB10.0002 OE No. 02.200.24.10.0 Description Air bellow Remarks 720 N, 3720 Front & Rear Tigril No. VO10.0001 OE No. 02.200.24.40.0 Description Air bellow Remarks 644 N, 3644 Front & Rear Tigril No. DB14.0055 OE No. 02.431.12.80.0 Description Level valve Remarks 463.032.020.0 Tigril No. MA14.0013 OE No. 02.431.09.02.0 Description Level valve Remarks 464.006.002.0 HS../HZ.. Series Tigril No. BP09.0020 OE No. 03.272.48.46.0 Description Wheel hub 10-12 T Remarks Rear HS../HZ.. Series Tigril No. BP09.0021 OE No. 03.272.62.27.0 Description Wheel hub 13-14 T Remarks Rear HS…/ HZ... Tigril No. BP09.0022 OE No. 03.272.80.14.0 Description Wheel hub 16-18 T 10 hole Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4

BPW Tigril No. BP09.0032 OE No. 03.272.80.86.0 Description Wheel hub 16 T HD Remarks Rear HS../HZ.. SH../SKHS.. ECO-MAXX Tigril No. BP09.0043 OE No. 03.272.30.97.0 Description Wheel hub 6.5-9 T Remarks Rear EHZ Series Tigril No. BP09.0044 OE No. 03.272.48.32.0 Description Wheel hub Remarks Rear H.. 16-18 T Tigril No. BP09.0027 OE No. 03.212.26.01.0 Description Hub cap, outer thread Remarks M155x3 H ( SN 42.. ), K ( SN 36.. ), SH ( SB 4345 ), SKH ( SB 3745 ), H..LL ( SN 42.. ) Tigril No. BP09.0048 OE No. 03.212.25.31.0 Description Hub cap, 8-9-10-12 T, inner thread Remarks M136x2,5 SW110/800Nm W Tigril No. BP09.0049 OE No. 03.212.27.01.0 Description Hub cap, 14-20 T, outer thread Remarks M230x3 SW120 H../K.., NR.. Tigril No. BP09.0050 OE No. 03.212.25.02.0 Description Hub cap, 13-14 T, outer thread Remarks M135x3 SW120/700Nm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5

BPW H ( SN 42.. ), (M)..L ( SN 42.. ) Series Tigril No. BP09.0051 OE No. 03.212.26.14.0 Description Hub cap, 13-14 T, inner thread Remarks M150x2 SW120/800Nm H../R.., KH../KR.., NH../NR.. Tigril No. BP09.0052 OE No. 03.212.24.07.0 Description Hub cap, 10-12 T, outer thread Remarks M125x2 SW110/500Nm H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX Tigril No. BP09.0053 OE No. 03.212.25.08.0 Description Hub cap, 10-12 T, inner thread Remarks M135x2 SW110/800Nm H.. Tigril No. BP09.0024 OE No. 05.370.07.04.0 Description Wear ring, wheel hub, 16-18 T Remarks Ø110 x Ø213 x 35 H../R.., KH../KR.. Tigril No. BP09.0055 OE No. 05.370.07.43.0 Description Wear ring, wheel hub, 10-12 T Remarks Ø96 x Ø136 x 22 H../K.. Tigril No. BP09.0056 OE No. 05.370.07.20.0 Description Wear ring, wheel hub, 13-14 T Remarks Ø96 x Ø136 / Ø187 x 34 H.. 16-18 T Tigril No. BP09.0025 OE No. 03.310.99.02.0 Description Seal ring for wheel hub Remarks Rear axle OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6

BPW H.. 16-18 T Tigril No. BP09.0026 OE No. 03.310.99.01.0 Description Seal ring for wheel hub Remarks Rear axle HZ… 24" Tigril No. BP24.0012 OE No. 03.328.86.05.0 Description Wheel spider 16T Remarks 604.202.224 Rear BPW Tigril No. BP24.0015 OE No. 03.328.76.47.0 Description Wheel spider 12 T Remarks 604.202.158 Rear BPW Tigril No. BP24.0016 OE No. 03.328.83.04.0 Description Wheel spider 14 T Remarks 604.202.198 Rear VB-HDE 14-20 ton Tigril No. BP09.0001 OE No. 05.291.01.14.0 Description Equalizing beam bearing, bronze bushes 70 mm Remarks Rear VB-HD 14-20 ton Tigril No. BP09.0002 OE No. 05.291.01.11.0 Description Equalizing beam bearing, rubber steel bush 60 mm Remarks Rear Trailer Tigril No. BP09.0003 OE No. Description Equalizing beam bearing, bronze bushes doll type 70 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 7

BPW VB suspension Tigril No. BP09.0018 OE No. Description Equalizing beam bearing, rubber steel bush doll type 60 mm Remarks Rear Tigril No. BP09.0057 OE No. Description Equalizing Beam Bearing, bronze bushes 60mm 2 bolt Remarks Rear Tigril No. BP09.0058 OE No. Description Equalizing Beam Bearing, bronze bushes 60mm 4 bolt Remarks Rear VB-HDE 14-20 ton Tigril No. BP09.0011 OE No. 03.112.76.13.0 Description Brass bush, equalizing beam 70 mm Remarks Rear VB-HDE 14-20 ton Tigril No. BP09.0012 OE No. 03.112.76.14.0 Description Brass bush, equalizing beam 60 mm Remarks VB suspension Tigril No. BP09.0010 OE No. 05.113.97.10.0 Description Bush, leaf spring (suspension) rubber 60mm Remarks Rear EL-VB Tigril No. BP09.0037 OE No. 03.177.17.04.0 Description Equalizer bolt kit 70x313 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 8

BPW EL-VB Tigril No. BP09.0038 OE No. 03.177.16.17.0 Description Equalizer bolt kit 70x281 mm Remarks Rear EL-VB Tigril No. BP09.0039 OE No. 03.177.16.20.0 Description Equalizer bolt kit 60x285 mm Remarks Rear EL-VB Tigril No. BP09.0040 OE No. 13.177.17.05.0 Description Equalizer bolt kit 60x313 mm Remarks Rear VB suspension Tigril No. BP09.0004 OE No. 05.443.71.55.0 Description Connecting rod, adjustable short (36 mm) Remarks Rear VB suspension Tigril No. BP09.0005 OE No. 05.443.70.77.0 Description Connecting rod, adjustable (30 mm) Remarks Rear VB suspension Tigril No. BP09.0006 OE No. 05.443.48.35.0 Description Connecting rod, fixed long (36 mm) Remarks Rear VB suspension Tigril No. BP09.0007 OE No. 05.443.46.03.0 Description Connecting rod, fixed short (36 mm) Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 9

BPW VB suspension Tigril No. BP09.0031 OE No. 05.443.71.02.0 Description Connecting Rod, adjustable (36mm) long Remarks Rear VB suspension Tigril No. BP09.0009 OE No. 05.113.93.03.0 Description Bush, connecting rod (36 mm) Remarks Rear Tigril No. BP09.0028 OE No. 05.113.93.03.0PU Description Bush (PU) , Connecting Rod 36 mm Remarks Rear axle VB suspension Tigril No. BP09.0047 OE No. 05.113.93.03.0 Description Bush (PU), connecting rod 36 mm Remarks H../K.., NR.. Tigril No. BP09.0014 OE No. 03.262.17.11.0 Description Axle nut 13-18 T Remarks Rear EH suspension Tigril No. BP09.0015 OE No. 03.262.17.08.0 Description Axle nut 14 T Remarks Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP09.0016 OE No. 03.262.17.12.0 Description Axle nut 10-12 T Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 10

BPW Tigril No. BP24.0001 OE No. 03.296.23.17.0 Description Wheel bolt Remarks M 22 x 2, M 22 x 1.5 112-61/48 mm, 10.9 Tigril No. BP24.0005 OE No. 02.507.03.20.0 Description Wheel bolt Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. BP24.0010 OE No. 02.507.08.70.0 Description Wheel bolt Remarks M 20 x 2 x 132/130 mm, 10.9 659112613 Tigril No. BP24.0014 OE No. 03.296.33.11.1 Description Wheel bolt Remarks 22 x 1.5 x 90 Tigril No. DB24.0030 OE No. 02.507.08.90.0 Description Wheel bolt Remarks M 20 x 2 x 57/55 mm, 10.9 Tigril No. BP24.0004 OE No. 02.507.03.20.0Set Description Wheel bolt set Remarks M 20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. BP24.0009 OE No. 02.507.08.70.0Set Description Wheel bolt set Remarks M 20 x 2 x 132/130 mm, 10.9 659112613 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 11

BPW Tigril No. BP24.0013 OE No. 05.806.23.22.0 Description Wheel bolt set Remarks M 22 x 2, M 22 x1.5 112-61/48 mm, 10.9 Tigril No. DB24.0029 OE No. 02.507.08.90.0Set Description Wheel bolt set Remarks M 20 x 2 x 57/55, 10.9 mm, 10.9 Tigril No. BP24.0002 OE No. 03.260.04.01.0 Description Wheel nut Remarks M22 x 2 H-25 wrench size-32 mm EH, EHZ Tigril No. BP24.0003 OE No. 03.260.04.06.0 Description Wheel nut Remarks M22 x 2 H-17 wrench size-32 mm Tigril No. BP24.0006 OE No. 02.527.00.40.0 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm Tigril No. DB24.0016 OE No. 03.260.54.03.0 Description Wheel nut Remarks M22 x 1.5 H-22 wrench size-30 mm H/KH/NH/NR/R, RBH Tigril No. DB24.0017 OE No. 05.260.54.09.0 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 12

BPW Tigril No. DB24.0018 OE No. 02.5213.14.62 Description Wheel nut Remarks M20 x 1.5 H-21 wrench size-27 mm Tigril No. DB24.0019 OE No. 02.5213.12.10 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm H Series Tigril No. IV24.0001 OE No. 02.521.92.01.0 Description Wheel nut Remarks M20 x 1.5 H-26.25 wrench size-30 mm Tigril No. BP24.0007 OE No. 02.545.02.20.0 Description Washer Remarks 36.9 x 21.2 x 2.75 mm Tigril No. DB24.0021 OE No. 02.5615.20.90 Description Washer (retaining ring, wheel rim) Remarks 24 x 20.5 x 8 mm DIN - ISO: 74361 Tigril No. DB24.0022 OE No. 03.310.10.02.0 Description Washer (centering ring, wheel rim) Remarks 32 x 20.2 x 6 mm DIN - ISO: 74361 Tigril No. DB24.0023 OE No. 02.5615.18.90 Description Washer (retaining ring, wheel rim) Remarks 29 x 18.5 x 7 mm DIN - ISO: 74361 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 13

BPW Tigril No. DB24.0025 OE No. 02.561.51.49.0 Description Washer (retaining ring, wheel rim) Remarks 23 x 14.5 x 5 mm DIN - ISO: 74361 Tigril No. DB24.0027 OE No. 02.56152.22.90 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 Tigril No. BP24.0008 OE No. 02.181.81.00.0 Description Safety pin Remarks 41/30 x 2 mm Tigril No. BP24.0011 OE No. 02.181.61.40.0 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated SKH Tigril No. BP13.0010 OE No. 03.088.34.02.0 Description Brake disc Remarks Rear SHSF, SDSF, SHSM, SHSMA, SHZF, SHZM, SHZMA, SHBF Tigril No. BP13.0011 OE No. 03.088.35.03.0 Description Brake disc Remarks Rear SHSF, SHSFA, SHSM, SHZ, SHZF, SHZM, SHZMA Tigril No. BP14.0002 OE No. 03.088.34.08.0 Description Brake disc Remarks Front & Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 14

BPW SH Series Tigril No. DB12.0004 OE No. 09.801.02.57.0 Description Brake pad set with accessories Remarks 29059 29061 29087 29108 29109 29163 29179 29201 29202 29278 F & R Tigril No. DB14.0002 OE No. 02.031.21.60.0 Description Brake pad set with accessories Remarks 29093 29094 29095 29184 29197 29287 29320 29145 Front & Rear Tigril No. DB14.0003 OE No. 09.801.07.07.0 Description Brake pad set with accessories Remarks 29115 29148 29183 Front & Rear SH Series Tigril No. DB14.0006 OE No. 09.801.02.57.0 Description Brake pad set with accessories Remarks 29087 29108 29059 29061 29202 29278 F & R Trailer Tigril No. BP13.0001 OE No. 03.106.67.29.0 Description Brake drum Remarks 420 x 200 Rear EHZ Series Tigril No. BP13.0012 OE No. 03.106.77.04.0 Description Brake drum Remarks 420 x 200 Rear HZ.. 14010-1 Tigril No. BP13.0013 OE No. 03.106.77.59.0 Description Brake drum Remarks 420 x 217 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 15

BPW HS.. / HZ.. Tigril No. BP13.0018 OE No. 03.109.77.72.0 Description Brake drum Remarks 420 x 217 Rear HS.. ECO MAXX / MAXX / ECO plus Tigril No. BP13.0019 OE No. 03.109.67.19.0 Description Brake drum Remarks 420 x 180 Rear HS.. Tigril No. BP13.0027 OE No. 03.106.77.57.0 Description Brake drum Remarks 420 x 200 Rear H series Tigril No. BP13.0028 OE No. 03.106.77.56.0 Description Brake drum Remarks 420 x 200 Rear N.. ECO-MAXX, N.. MAXX Tigril No. BP13.0029 OE No. 03.109.46.06.0 Description Brake drum Remarks 300 x 200 Rear Tigril No. BP13.0044 OE No. 03.106.77.63.0 Description Brake drum Remarks Rear HS.., ECO MAXX / MAXX / ECO plus Tigril No. BP13.0045 OE No. 03.109.67.19.0 Description Brake drum lock type Remarks 420 X 180 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 16

BPW HS.. Tigril No. BP13.0046 OE No. 03.109.67.13.0 Description Brake drum Remarks 420 X 180 Rear Tigril No. BP13.0047 OE No. 03.106.67.29.0 Description Brake drum (Heavy duty) Remarks 420 x 200 Rear H Series 10/12T SN 4220 2XL/3XL Tigril No. BP14.0006 OE No. 99.000.00.12.6 Description Cover plate with repair kit, brake drum Remarks H Series 8/9 T, SN 4218-2 Tigril No. BP14.0007 OE No. 99.000.00.07.1 Description Cover plate with repair kit, brake drum Remarks SN.4218-2 H Series 10/12T SN 4220-2 Tigril No. BP14.0008 OE No. 99.000.00.07.3 Description Cover plate with repair kit, brake drum Remarks SN.4220-2 H Series 8/9 T, SN 4218-2 Tigril No. BP14.0009 OE No. 99.000.00.08.8 Description Cover plate with repair kit, brake drum Remarks SN.4218-2 H Series 8/9 T, SN 4218, SN 4220 Tigril No. BP14.0010 OE No. 99.000.00.09.8 Description Cover plate with repair kit, brake drum Remarks SN.4218 / SN.4220 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 17

BPW EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0002 OE No. 03.092.27.77.0 Description Brake lining with rivets Remarks 19094 EH EHF/E/EHI/EHIZ/EHIZVB/EHS/EHXZ/EHZ/EHZDO, H, HZMD/HZMDH/HZMDHOM/HZMDHOT/HZMDO/HXZH Tigril No. BP13.0003 OE No. 03.092.26.01.0 Description Brake lining with rivets Remarks 19032 Rear EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0048 OE No. 03.092.27.77.0 Description Brake lining with rivets, 18 mm Remarks EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0049 OE No. 03.092.27.77.0 Description Brake lining with rivets, 19 mm Remarks EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0050 OE No. 03.092.27.77.0 Description Brake lining with rivets, 20 mm Remarks EH, H Tigril No. BP13.0014 OE No. 05.091.27.54.2 Description Brake shoe with steel roller, 200 mm Remarks 420 x 200 Rear H../R.. Tigril No. BP13.0015 OE No. 05.091.27.83.0 Description Brake shoe with steel roller, 200 mm Remarks 420 x 200 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 18

BPW EH, H Tigril No. BP13.0016 OE No. 05.091.26.64.2 Description Brake shoe with steel roller, 180 mm Remarks 420 x 180 Rear H../R.. Tigril No. BP13.0017 OE No. 05.091.46.17.0 Description Brake shoe with steel roller, 180 mm Remarks 420 x 180 Rear H../R.. Tigril No. BP13.0021 OE No. 05.397.58.03.0 Description Brake shoe spring Remarks Rear EH.., H.., M.., R.. Tigril No. BP13.0022 OE No. 03.397.34.11.0 Description Brake shoe spring Remarks Rear H.., R.. Tigril No. BP13.0023 OE No. 03.397.33.07.0 Description Brake shoe spring Remarks Rear H../R.. Tigril No. BP13.0024 OE No. 03.397.33.06.0 Description Brake shoe spring Remarks Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP13.0030 OE No. 03.397.44.06.0 Description Brake shoe spring Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 19

BPW H../R.. Tigril No. BP13.0031 OE No. 05.397.46.06.0 Description Brake shoe spring Remarks Tigril No. BP14.0011 OE No. 03.084.46.23.0 Description Brake shoe pin Remarks Tigril No. BP14.0012 OE No. 03.084.46.23.0S Description Brake shoe pin plate Remarks H../R.., KH../KR.. Tigril No. BP13.0008 OE No. 05.174.52.61.0 Description Slack adjuster manual 5 holes Remarks 100.001.721 Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP13.0009 OE No. 05.174.65.13.0 Description Slack adjuster manual 7 holes Remarks 100.001.760 Rear H../R.., KH../KR.., NH../NR.., ECO-Master Tigril No. BP14.0004 OE No. 05.574.82.87.3 Description Slack adjuster AT with sensor hole Remarks 80019 Front & Rear Tigril No. DB12.0006 OE No. 05.174.90.20.0 Description Slack adjuster automatic Remarks 80009 Front OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 20

BPW Tigril No. DB12.0014 OE No. 05.174.90.20.0S Description Slack adjuster AT with sensor hole Remarks 80009 Front right Tigril No. DB13.0006 OE No. 05.174.54.69.0 Description Slack adjuster manual Remarks 433.506.514.0 Rear left Tigril No. DB13.0007 OE No. 05.174.54.70.0 Description Slack adjuster manual Remarks 433.506.515.0 Rear right H../R.., KH../KR.., NH../NR.., ECO-Master Tigril No. BP13.0025 OE No. 05.397.26.03.0 Description Return spring for slack adjuster Remarks Rear H../R.., NH../NR.. Tigril No. BP13.0032 OE No. 05.397.26.02.0 Description Return spring for slack adjuster Remarks 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0033 OE No. 05.097.05.37.4 Description Brake camshaft, left Remarks 755,0 / 634.5mm, Ø 42 mm, 10 teeth 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0034 OE No. 05.097.05.38.4 Description Brake camshaft, right Remarks 755,0 / 634.5mm, Ø 42 mm, 10 teeth OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 21

BPW 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0035 OE No. 05.097.05.23.4 Description Brake camshaft, left Remarks 643,0 / 522.5mm, Ø 42 mm, 10 teeth 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0036 OE No. 05.097.05.24.4 Description Brake camshaft, right Remarks 643,0 / 522.5mm, Ø 42 mm, 10 teeth H../R.., KH../KR.. Tigril No. BP13.0037 OE No. 05.097.05.21.4 Description Brake camshaft, left Remarks 630,0 / 509.5mm, Ø 42 mm, 10 teeth H../R.., KH../KR.. Tigril No. BP13.0038 OE No. 05.097.05.22.4 Description Brake camshaft, right Remarks 630,0 / 509.5mm, Ø 42 mm, 10 teeth H.., KH.., KM.., KR.., NH.., NM..,NR..,NRD.. Tigril No. BP13.0026 OE No. 09.801.02.22.0 Description Repair kit, brake cam shaft Remarks Rear H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP13.0039 OE No. 09.801.00.14.1 Description Repair kit, brake camshaft Remarks H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP13.0040 OE No. 03.112.44.30.0S1 Description Repair kit, brake camshaft Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 22

BPW H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP13.0041 OE No. 03.112.44.30.0S2 Description Repair kit, brake camshaft Remarks H../K../N.. Series Tigril No. BP13.0042 OE No. 03.229.02.18.0 Description Retainer, brake cam shaft Remarks 50 x 110 / 4 x Ø10 H../K../N.. Series Tigril No. BP13.0043 OE No. 03.229.02.19.0 Description Retainer, brake cam shaft Remarks 50 x 110 / 6 x Ø10 H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP14.0001 OE No. 03.112.44.34.0 Description Bush, brake camshaft Remarks Front & Rear SH../SKH…, S../LL Tigril No. BP12.0001 OE No. 02.032.77.80.0 Description Brake cylinder 24 Remarks 423.506.001.0 H.. /R.., KH../KR.., NH../NR.. Tigril No. BP12.0002 OE No. 05.444.15.01.0 Description Brake cylinder 24 Remarks 423.106.900.0 423.106.091.0 295555 Front SH../SKH…, S../LL Tigril No. BP12.0003 OE No. 02.032.77.80.0 Description Brake cylinder 24 Remarks 423.506.001.0 M22 x 1.5 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 23

BPW Tigril No. BP13.0020 OE No. 05.444.16.01.0 Description Brake cylinder 30 Remarks 423.107.900.0 Tigril No. DB13.0042 OE No. 02.032.78.80.0 Description Spring brake cylinder 16/24 Remarks 925.464.500.0 Rear Tigril No. MA14.0022 OE No. 02.431.00.90.0 Description 2-way valve Remarks 434.208.000.0 I40405 Tigril No. DB14.0093 OE No. 02.102.41.00.0 Description Air line filter Remarks 432.500.020.0 Tigril No. BP14.0005 OE No. 02.033.21.30.0 Description Automatic load sensing valve Remarks 475.714.500.0 Tigril No. BP14.0003 OE No. 02.431.13.50.0 Description Level valve Remarks 464.006.100.0, I98289 Tigril No. SC14.0014 OE No. 02.431.14.10.0 Description Lift axle control valve Remarks 463.084.000.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 24

BPW Tigril No. MA14.0031 OE No. 02.431.15.00.0 Description Pressure limiting valve Remarks 975.001.000.0 I50402 Tigril No. MA14.0032 OE No. 02.431.09.60.0 Description Pressure limiting valve Remarks 475.010.307.0 Universal Tigril No. DB14.0101 OE No. 02.431.07.20.0 Description Quick release valve Remarks 973.500.000.0 Tigril No. MA14.0014 OE No. 02.431.07.70.0 Description Trailer control valve Remarks 971.002.150.0 Tigril No. MA14.0026 OE No. 02.431.03.00.0 Description Water drain valve Remarks 934.300.003.0 I94095 H Series Tigril No. DA14.0019 OE No. 02.331.70.50.0 Description ABS sensor with bush and grease, 410mm Remarks 441.032.807.0 441.032.921.2 441.032.960.2 SH../SKH.. 8-12 t Tigril No. SC14.0007 OE No. 02.031.65.90.0 Description Clamping bushing, wheel speed sensor Remarks 899.759.815.4 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 25

BPW Tigril No. SC14.0009 OE No. 02.181.91.50.0 Description Cable with connector plug/socket ABS Remarks 449.712.018.0 Cable Length: 1800 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 26

DAF Tigril No. DB16.0031 OE No. 0.231.127 Description Sensor, oil pressure Remarks 0.5 bar / M 10 x 1 360.081.029.001K 75 CF/F/FAG/FAR/FAT/FAV/FT, 85 CF/FA/FAD/FAG/GAT/FT/FTG/FTT, 95 FA/FAC/FAD/FAG, 95 XF Tigril No. DA01.0001 OE No. 1.339.048 Description Fuel feed pump Remarks 0.440.008.089 Tigril No. DB01.0051 OE No. 0.511.756 Description Fuel feed pump Remarks 0.440.008.007 F 45/55, F 65/75/85/95, 65/75/85 CF, 95 XF Tigril No. DB01.0053 OE No. 1.246.869 Description Fuel feed pump Remarks 0.440.008.999 Tigril No. DB01.0057 OE No. 1.519.533S Description Fuel feed pump with plug Remarks 0.440.011.007 Tigril No. DB01.0058 OE No. 1.519.532 Description Fuel feed pump Remarks 0.440.008.173 F 2800 Tigril No. DB01.0061 OE No. 608.932 Description Fuel hand pump Remarks 2.447.222.000 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 27

DAF F 2800 Tigril No. DB01.0060 OE No. 194.194 Description Fuel hand pump Remarks 95 XF, 75/85 CF, 75/95 Tigril No. DB01.0063 OE No. 1.311.608 Description Fuel hand pump, with gasket Remarks 2.447.010.033 0.440.011.007 Tigril No. DB01.0045 OE No. 1.519.488 Description Feed pump, repair kit Remarks 2.447.010.021 Tigril No. DB01.0066 OE No. 697.480 Description Feed pump repair kit Remarks 2.447.010.011 65/75/85/95, 65/75/85 CF, 95 XF, F 45/55,F 3300/3600, N 2800 Tigril No. DB01.0067 OE No. 1.315.514 Description Feed pump repair kit Remarks 2.447.010.017 Tigril No. DB01.0056 OE No. 1.519.533 Description Fuel feed pump Remarks 0.440.011.002 95 XF Tigril No. DB01.0068 OE No. 1.438.836 Description Filter repair kit, without filter housing Remarks E11S04 D65 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 28

DAF F 65/85/95 Tigril No. DB01.0041 OE No. 1.228.128 Description Overflow valve Remarks 1.417.413.047 M 14 F 800/1000/1100/1300/1700/1800/1900/2100/2300/2500/2700, Bus Tigril No. DA12.0002 OE No. 537.746 Description Air compressor Remarks 911.505.051.0 95 Tigril No. DA12.0003 OE No. 0.762.788 Description Air compressor Remarks 911.504.052.0 F 75/95, 75/85 CF, 95 XF, CF 75/85, XF 95 Tigril No. DA12.0004 OE No. 1.621.322 Description Air compressor Remarks 911.504.506.0 F 95 Tigril No. DA12.0005 OE No. 1.243.571 Description Air compressor Remarks 911.504.056.0 Tigril No. DB12.0017 OE No. 1.517.931 Description Air compressor Remarks 411.034.501.0 Tigril No. DB12.0030 OE No. 1.517.937 Description Air compressor Remarks 411.151.009.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 29

DAF Tigril No. VO12.0008 OE No. 1.506.365 Description Air compressor Remarks 911.505.150.0 Tigril No. MA12.0006 OE No. 1.518.589 Description Cylinder head with gasket, compressor Remarks ZB4275 Tigril No. DB01.0033 OE No. 1.516.687R Description Starter 24V 4.0kW Remarks 0.001.368.309 Tigril No. DB01.0034 OE No. 1.516.658R Description Starter 24V 6.2kW Remarks 0.001.372.001 Tigril No. DB01.0035 OE No. 1.519.391R Description Starter 24V 6.2kW Remarks 0.001.372.006 Tigril No. DB01.0036 OE No. 1.516.707R Description Starter 24V 5.4kW Remarks 0.001.416.002 Tigril No. DB01.0037 OE No. 1.516.711R Description Starter 24V 6.6kW Remarks 0.001.417.001 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 30

DAF Tigril No. IV01.0003 OE No. 1.516.767R Description Starter 24V 6.6kW Remarks 0.001.417.005 Tigril No. IV01.0004 OE No. 1.516.672R Description Starter 24V 6.6kW Remarks Tigril No. SC01.0008 OE No. 1.516.677R Description Starter 24V 6.7kw Remarks 0.001.371.004 Tigril No. SC01.0009 OE No. 1.516.656R Description Starter 24V 6.5kw Remarks 0.001.371.006 Tigril No. VO01.0008 OE No. 1.516.670R Description Starter 24V 6.6kw Remarks 0.001.417.075 Tigril No. VO01.0027 OE No. 1.516.770 Description Starter 24V 5,4kW Remarks 0.001.416.005 0.004.417.041 F 75/85/95, 95 XF, XF 95 Tigril No. DB16.0046 OE No. 607.080 Description Solenoid switch Remarks 0.331.101.006 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 31

DAF F 75/85/95, 95 XF, XF 95 Tigril No. DB16.0047 OE No. 252.121 Description Solenoid switch Remarks 0.331.450.001 F 2800/2900/3200, F 3300/3600, N 2800, Bus Tigril No. VO01.0029 OE No. 258.276 Description Starter clutch Remarks 2.006.401.527 F 65/75/85/95, 65/75/85 CF, 95 XF Tigril No. DB01.0070 OE No. 1.357.591 Description Alternator 28V 55AH without pulley Remarks 0.120.469.982 Tigril No. MA01.0009 OE No. 1.516.514R Description Alternator 28V 80AH with out pulley Remarks 0.123.525.501 Tigril No. SC01.0006 OE No. 1.516.533R Description Alternator 28V 55AH with out pulley Remarks 0.120.469.643 Tigril No. SC01.0007 OE No. 1.516.589R Description Alternator 28V 55AH with out pulley Remarks 0.120.469.920 Tigril No. VO01.0022 OE No. 1.516.583R Description Alternator 28V 55A without pulley Remarks 0.120.469.014 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 32

DAF Tigril No. VO01.0023 OE No. 0.910.378 Description Alternator 24V 110A with pulley Remarks 0.124.655.008 F 2800/2900/3200, F 3300/3600, N 2800, F 65/75/85/95, 65/75/85 CF, 95 XF, Bus Tigril No. VO01.0024 OE No. 1.676.162 Description Regulator 28.5 V Remarks 1.197.311.304 F 65/75/95, 65/75/85 CF, 95 XF Tigril No. VO01.0026 OE No. 1.311.304 Description Rectifier Remarks 1.127.320.989 Tigril No. VO01.0028 OE No. 697.886 Description Carbon brush set Remarks 2.007.014.070 Tigril No. SC14.0011 OE No. 1.506.009 Description Pressure sensor Remarks 441.044.101.0 F 2800/2900/3200/3300/3600, N 2800 Tigril No. DA01.0002 OE No. 682.262 Description Water pump Remarks F 95, 85 CF, 95 XF, XF 95 Tigril No. DA01.0003 OE No. 683.225 Description Water pump Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 33

DAF 95 Tigril No. VO01.0020 OE No. 1.293.885 Description Thermostat 75 °C Remarks 4619.75 CF 75/85, 75/85 CF Tigril No. VO01.0031 OE No. 1.439.844 Description Thermostat 82 °C Remarks 4619.82 Tigril No. DB03.0016 OE No. 1.278.342 Description Clutch master cylinder Remarks KG22019.1.1 Tigril No. DB03.0001 OE No. 1.506.469 Description Repair kit, clutch cylinder Remarks 970.051.903.2 Tigril No. DB03.0003 OE No. 1.506.468 Description Clutch servo, complete with sensor Remarks 970.051.431.0 625375AM F 2100/2300/2500 Tigril No. DA03.0001 OE No. 0.659.807 Description Clutch servo Remarks 970.051.114.0 F 75/85/95, 85 CF Tigril No. DA03.0002 OE No. 1.443.530 Description Clutch servo Remarks 628275AM OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 34

DAF Tigril No. DB03.0002 OE No. 1.518.250 Description Clutch servo Remarks 970.051.151.0 970.051.162.0 F 2900 Tigril No. DB03.0004 OE No. 1.518.252 Description Clutch servo Remarks 970.051.159.0 Tigril No. DB03.0005 OE No. 1.505.139 Description Clutch servo Remarks 970.051.131.0 Tigril No. DB03.0008 OE No. 1.506.456 Description Clutch servo Remarks 970.051.158.0 Tigril No. DB03.0009 OE No. 1.518.249 Description Clutch servo Remarks 970.051.137.0 Tigril No. MA03.0001 OE No. 1.506.465 Description Clutch servo Remarks 970.051.412.0 Tigril No. MA03.0003 OE No. 1.518.255 Description Clutch servo Remarks 970.051.414.0 II31733 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 35

DAF Tigril No. MA03.0004 OE No. 1.518.243 Description Clutch servo Remarks 970.051.111.0 Tigril No. MA03.0006 OE No. 1.518.251 Description Clutch servo Remarks 970.051.157.0 625586AM F 1000 Tigril No. RV03.0001 OE No. 1.518.244 Description Clutch servo Remarks 970.051.124.0 Tigril No. RV03.0002 OE No. 1.518.254 Description Clutch servo Remarks 970.051.209.0 Tigril No. SC03.0001 OE No. 1.504.842 Description Clutch servo Remarks 622199AM Tigril No. VO03.0002 OE No. 1.504.843 Description Clutch servo Remarks 970.051.192.0 626639AM Tigril No. DA03.0003 OE No. 832.865 Description Repair kit, clutch servo Remarks 971.002.003.2 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 36

DAF Tigril No. DA03.0004 OE No. 1.347.695 Description Repair kit, clutch servo Remarks 475.010.00.22 Tigril No. DB03.0011 OE No. 1.519.290 Description Repair kit, clutch servo Remarks 970.051.916.2 Tigril No. DB03.0012 OE No. 1.519.292 Description Repair kit, clutch servo Remarks 970.051.949.2 F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DB04.0009 OE No. 1.517.945 Description Shifting cylinder Remarks 422.010.012.0 F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700 Tigril No. DB04.0017 OE No. 609.715 Description Switch, splitter gearbox Remarks SV3302 65/75/85 CF, XF 105, 95 XF, F 1300/1600/1700/1800/1900/2100/2300/2500/2800/3300/3600 Tigril No. DB04.0004 OE No. 386.930 Description Ball joint, gear shift linkage Remarks Front 75/85/95, 75/85 CF, 95 F Tigril No. DB04.0005 OE No. 1.249.088 Description Ball joint, gear shift linkage, upper Remarks Front OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 37

DAF 75/85/95, 75/85 CF, 95 XF Tigril No. DB04.0006 OE No. 1.249.129 Description Ball joint, gear shift linkage, lower Remarks Rear F 75, 65/75/85 CF, CF 75 /IV, CF 85 /IV Tigril No. DB04.0013 OE No. 1.330.985 Description Ball head, gearshift linkage Remarks Right hand thread F 75, 65/75/85 CF, CF 75, CF 85 /IV Tigril No. DB04.0014 OE No. 1.330.986 Description Ball head, gearshift linkage Remarks Left hand thread F 75/85/95, F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700 Tigril No. DB04.0022 OE No. 692.183 Description Solenoid valve, shift cylinder Remarks 6038.202.003 Tigril No. DB14.0066 OE No. 1.508.080 Description 3/2 Directional control valve Remarks 463.036.000.0 F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900 Tigril No. DB14.0018 OE No. 0.262.233 Description 4/2-way valve Remarks 571.003.104.0 0501.303.270 Tigril No. DB04.0018 OE No. 1.518.090 Description 5/2-way valve Remarks 0750.132.032 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 38

DAF F 2800/2900/3200, F 3300/3600, N 2800, F 65/75/85/95, 65/75/85 CF, 95 XF, LF 45/55 Tigril No. VO14.0024 OE No. 642.909 Description 3/2 directional control valve Remarks 463.022.020.0 Tigril No. MA14.0029 OE No. 1.154.219S Description Shut-off valve Remarks 6038.202.043 Tigril No. DB14.0040 OE No. 1.505.077 Description Trailer control valve Remarks 463.013.200.0 Tigril No. SF10.0009 OE No. 1.384.274 Description Air spring with metal piston Remarks 813MB, 3813 K Rear Tigril No. DB09.0033 OE No. 1.527.109 Description Air spring without piston with plate Remarks 4390 N2, 34390-02 P Rear SB 2300/3000 Tigril No. MA10.0001 OE No. 0.659.561 Description Air bellow Remarks Lifting axle 715 N, 3715 Tigril No. VO09.0014 OE No. 0.627.584 Description Air bellow Remarks 673 N, 3673 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 39

DAF F 2700 Tigril No. VO10.0001 OE No. 696.229 Description Air bellow Remarks 644 N, 3644 Front & Rear 65 CF, 75/85 CF, 95 XF, CF 65/75/85 85, LF 55, XF 95/105 Tigril No. DA09.0001 OE No. 1.368.270 Description Triangular control arm Remarks Rear 75/85 CF, 95 XF, CF 75/85, XF 95, F 2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DA09.0002 OE No. 1.620.437 Description Triangular control arm Remarks Rear F 2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DB09.0016 OE No. 691.703 Description Torsion link repair kit 85 mm Remarks Ø85 x 24 / Ø21 x 152 Rear F 2800/2900/3200, F 3300/3600, N 2800, F 95, 95 XF, CF 85 /IV, XF 95/105 Tigril No. DB09.0056 OE No. 693.778 Description Repair Kit, link Remarks Ø65x24 / Ø21x152 Rear DAF 95 Tigril No. MA09.0001 OE No. 689.749 Description Torsion link repar kit 85 mm Remarks Ø85 x 30 / Ø19 x 130 Rear F 2100/2300/2500/2700/2800/2900/3200/3300/3600, F 75/85/95, 65/75/85 CF, 95 XF Tigril No. VO09.0003 OE No. 696.321 Description Torsion link repair kit 95 mm Remarks Ø95 x 35 / Ø23 x 152 Front OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 40

DAF F 2800/2900/3200, F 3300/3600, N 2800, F 95, Bus Tigril No. DB16.0007 OE No. 1.247.631 Description Distance sensor, ECAS Remarks 441.050.008.0 Tigril No. DB16.0038 OE No. 1.524.843 Description Distance sensor, ECAS Remarks 441.050.120.0 F 2800/2900/3200, F 3300/3600, N 2800, F 65/75/85/95, 75/85 CF, 95 XF, LF 55, CF 75 /I Tigril No. DB16.0048 OE No. 1.505.287 Description Distance sensor, ECAS Remarks 441.050.011.0 F 2800/3300/3600 Tigril No. DB14.0055 OE No. 1.506.100 Description Level valve Remarks 463.032.020.0 Tigril No. DB14.0057 OE No. 1.518.095 Description Air suspension valve Remarks 464.007.011.0 Tigril No. MA14.0013 OE No. 1.325.337 Description Level valve Remarks 464.006.002.0 XF 95, 95 XF, CF 65/75/85, 75/85 CF, F 1600/1800 Tigril No. MA14.0028 OE No. 1.505.081 Description Levelling valve Remarks 464.007.001.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 41

DAF Tigril No. SC14.0017 OE No. 1.504.925 Description Levelling valve Remarks 464.007.010.0 95 XF, 75/85 CF, CF 75/85, F 1600/1800 Tigril No. VO14.0028 OE No. 1.518.094 Description Levelling valve Remarks 464.007.003.0 Tigril No. DB14.0037 OE No. 1.506.134 Description Solenoid Valve Remarks 472.070.639.0 F 2800/2900/3200, F 3300/3600, N 2800, F 95, Bus Tigril No. DB14.0052 OE No. 1.506.152 Description Solenoid valve Remarks 472.900.001.0 Tigril No. SC14.0016 OE No. 1.257.361 Description Solenoid valve, ABS Remarks 472.250.000.0 75/85 CF, XF 95, CF 65/75/85, L 55 Tigril No. DA08.0001 OE No. 683.499 Description King pin kit single Remarks Front Tigril No. RO09.0006 OE No. 1.488.353 Description Bolt equalizer 41 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 42

DAF 75/85 CF, 95 XF, F 1700/1900/2100/2300/2500/2700/2800 Tigril No. BP24.0002 OE No. 144.922 Description Wheel nut Remarks M22 x 2 H-25 wrench size-32 mm 95 XF, 85 CF Tigril No. BP24.0006 OE No. 678.250 Description Wheel nut Remarks M20 x 2 H-20 wrench size-27 mm XF 95/105, CF 65/75/85/95, LF 55, 75/85 CF, 95 XF, F 2800/2900/3200/3300/3600, N 2800 Tigril No. DB24.0017 OE No. 0.620.652 Description Wheel nut Remarks M22 x 1.5 H-27 wrench size-32 mm Tigril No. DB24.0019 OE No. 188.055 Description Wheel nut Remarks M18 x 1.5 H-18 wrench size-24 mm F 1600/2100/2200/2300/2800 Tigril No. DB24.0027 OE No. 325.235 Description Washer (retaining ring, wheel rim) Remarks 34 x 22.5 x 8 mm DIN - ISO: 74361 65/75/85 CF, 95 XF, F 1900/2100/2300/2500/2700/2800/3200/3300/3600 Tigril No. DB24.0028 OE No. 0.260.261 Description Washer (retaining ring, wheel rim) Remarks 32 x 22.2 x 5.5 mm DIN - ISO: 74361 CF 85, F 2300/2500/2700/2800/2900/3200/3300/75/85/95, TB 2100 Tigril No. BP24.0008 OE No. 506.666 Description Safety pin Remarks 41/30 x 2 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 43

DAF F 2800/2900/3200/3300/3600, N 2800 Tigril No. DA11.0001 OE No. 609.866 Description Universal joint 48x116.50 mm Remarks Rear F 2300/2800/3300/3600 Tigril No. DA11.0002 OE No. 1.252.350 Description Universal joint 57x144 mm Remarks Rear F 2800/2900/3200, F 3300/3600, N 2800, F 75/85/95, Bus Tigril No. DB11.0005 OE No. 0.264.354 Description Universal joint 52x133 mm Remarks Rear 75/85/95, 95 XF, F 1900/3200/3300/3600 Tigril No. DB11.0007 OE No. 1.288.229 Description Universal joint 57x152 mm Remarks Rear F 65, 65/75/85 CF, 95 XF, CF 65/75/85, XF 95 Tigril No. DA11.0003 OE No. 1.435.557 Description Propellor shaft mounting, bearing 65 mm Remarks Rear F 85/95, 85 CF, 95 XF, F 2800/2900/3200, F 3300/3600, N 2800 Tigril No. DA11.0004 OE No. 1.235.569 Description Propellor shaft mounting, bearing 70 mm Remarks Rear F 65/75/85/95, 65/75/85 CF, 95 XF, CF 75, F 2800/2900/3200, F 3300/3600, N 2800 Tigril No. DA11.0005 OE No. 1.298.157 Description Propellor shaft mounting, bearing 55 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 44

DAF 45/55, LF 45/55 Tigril No. DA11.0006 OE No. 1.404.560 Description Propellor shaft mounting, bearing 45 mm Remarks CF 65, LF 45/55 Tigril No. DA11.0007 OE No. 1.408.525 Description Propellor shaft mounting, bearing 55 mm Remarks CF 65, LF 45/55 Tigril No. DA11.0008 OE No. 1.782.199 Description Propellor shaft mounting, bearing 60 mm Remarks 65 CF, 65/75 Tigril No. RV11.0001 OE No. 1.291.808 Description Propellor shaft mounting, bearing 55 mm Remarks Tigril No. RV11.0003 OE No. 1.700.326 Description Propellor shaft mounting, bearing 50mm Remarks Tigril No. BP13.0011 OE No. 1.962.289 Description Brake disc Remarks Rear Tigril No. BP14.0002 OE No. 1.962.286 Description Brake disc Remarks Front & Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 45

DAF 85 CF, 95 XF, CF 65/75/85, LF 45/55, XF 95/105 Tigril No. DA14.0001 OE No. 1.726.138 Description Brake disc with kit Remarks Front & Rear Tigril No. DB12.0035 OE No. 1.962.314 Description Brake disc Remarks Front Tigril No. DB12.0039 OE No. 1.962.312 Description Brake disc Remarks Front Tigril No. DB13.0049 OE No. 1.962.313 Description Brake disc Remarks Rear Tigril No. DB13.0050 OE No. 1.962.315 Description Brake disc Remarks Rear Tigril No. DB13.0051 OE No. 1.962.316 Description Brake disc Remarks Rear Tigril No. DB14.0001 OE No. 1.962.322 Description Brake disc Remarks Front & Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 46

DAF Tigril No. DB14.0004 OE No. 1.962.318 Description Brake disc Remarks Front & Rear Tigril No. IV14.0001 OE No. 1.962.300 Description Brake disc with ABS sensor Remarks Front & Rear Tigril No. MA12.0002 OE No. 1.962.305 Description Brake disc Remarks Front Tigril No. MA12.0004 OE No. 1.962.303 Description Brake disc Remarks Front Bova futura FHD/FLD Tigril No. SC13.0010 OE No. 1.525.365 Description Brake disc Remarks Rear Tigril No. SC14.0001 OE No. 1.962.327 Description Brake disc Remarks Front & Rear Tigril No. SF13.0001 OE No. 1.962.330 Description Brake disc Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 47

DAF Tigril No. SF13.0002 OE No. 1.962.332 Description Brake disc Remarks Rear Tigril No. SF13.0003 OE No. 1.962.331 Description Brake disc Remarks Rear Tigril No. SF13.0005 OE No. 1.962.334 Description Brake disc Remarks Rear 1.962.334 Tigril No. SF13.0007 OE No. Description Brake disc with kit Remarks Rear Tigril No. DA14.0020 OE No. 1.393.560 Description Repair kit,brakedisc Remarks Tigril No. VO14.0037 OE No. 1.962.341 Description Repair kit, brake disc Remarks 65/75/85 CF, LF 55, CF 65 /II /IV, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB12.0004 OE No. 1.617.343 Description Brake pad set with accessories Remarks 29059 29061 29087 29108 29109 29163 29179 29201 29202 29278 F & R OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 48

DAF Tigril No. DB12.0012 OE No. 1.962.434 Description Brake pad set Remarks 29246 29247 Front Tigril No. DB12.0037 OE No. 1.501.994 Description Brake pad set with accessories Remarks 29835 Front Tigril No. DB13.0016 OE No. 1.962.433 Description Brake pad set Remarks 29244 29245 Rear Tigril No. DB14.0002 OE No. 1.529.337 Description Brake pad set with accessories Remarks 29093 29094 29095 29184 29197 29287 29320 29145 Front & Rear Tigril No. DB14.0003 OE No. 1.962.595 Description Brake pad set with accessories Remarks 29115 29148 29183 Front & Rear 65/75/85 CF, LF 55, CF 65 /II /IV, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB14.0006 OE No. 1.617.343 Description Brake pad set with accessories Remarks 29087 29108 29059 29061 29202 29278 F & R Tigril No. MA14.0037 OE No. 1962.594 Description Brake pad set without accessories Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 49

DAF F 65/75/85/95, 65/75/85 CF, 95 XF, XF 95 Tigril No. DA12.0001 OE No. 284.620 Description Brake drum Remarks 420 x 160 Front F 75/85/95, 75/85 CF, 95 XF Tigril No. DA13.0001 OE No. 365.579 Description Brake drum Remarks 420 x 200 Rear Tigril No. BP13.0002 OE No. 702.971 Description Brake lining with rivets Remarks 19094 Tigril No. BP13.0003 OE No. 303.910 Description Brake lining with rivets Remarks 19032 Rear Tigril No. BP13.0048 OE No. 702.971 Description Brake lining with rivets, 18 mm Remarks Tigril No. BP13.0049 OE No. 702.971 Description Brake lining with rivets, 19 mm Remarks Tigril No. BP13.0050 OE No. 702.971 Description Brake lining with rivets, 20 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 50

DAF 65/75/85/95, 65/75/85 CF, 85/95 CF, 95 XF, F 2300/2700/2900 Tigril No. DA13.0002 OE No. 683.278 Description Brake lining with rivets Remarks 19063 & 19064 Rear Tigril No. DB12.0006 OE No. 4.731.303 Description Slack adjuster automatic Remarks 80009 Front Tigril No. DB12.0014 OE No. 4.731.303S Description Slack adjuster AT with sensor hole Remarks 80009 Front right Tigril No. DB13.0008 OE No. 4.731.113 Description Slack adjuster automatic Remarks 80000 Rear left Tigril No. DB13.0009 OE No. 4731.121 Description Slack adjuster automatic Remarks 80001 Rear right XF 95/105, 95 XF, CF 85, 85 CF Tigril No. BP14.0001 OE No. 1.602.394 Description Bush, brake camshaft Remarks Front & Rear Tigril No. BP12.0001 OE No. 1.517.956 Description Brake cylinder 24 Remarks 423.506.001.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 51

DAF F2500, LF 45/55 Tigril No. BP12.0002 OE No. 834.483 Description Brake cylinder 24 Remarks 423.106.900.0 423.106.091.0 295555 Front Tigril No. BP12.0003 OE No. 1.517.956 Description Brake cylinder 24 Remarks 423.506.001.0 M22 x 1.5 LF 45/55 Tigril No. BP13.0020 OE No. 705.707 Description Brake cylinder 30 Remarks 423.107.900.0 Tigril No. DB12.0031 OE No. 1 505 026 Description Brake cylinder 20 Remarks 423.105.111.0 Front Tigril No. DA13.0003 OE No. 1.519.443 Description Spring brake cylinder 20/24 Remarks 925.420.005.0 925.490.925.0 Rear Tigril No. DB12.0018 OE No. 1.518.146 Description Spring brake cylinder 24/24 Remarks 925.321.202.0 Tigril No. DB12.0019 OE No. 1.518.145 Description Spring brake cylinder 24/24 Remarks 925.321.160.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 52

DAF Tigril No. DB12.0020 OE No. 1.518.144 Description Spring brake cylinder 20/30 Remarks 925.320.400.0 Tigril No. DB12.0021 OE No. 1.518.148 Description Spring brake cylinder 24X24 Remarks 925.321.292.0 Tigril No. DB12.0022 OE No. 1.519.131 Description Spring brake cylinder 16/24 Remarks 925.324.000.0 Tigril No. DB12.0023 OE No. 1.506.681 Description Spring brake cylinder 20/24 IBV Remarks 925.480.005.0 Tigril No. DB12.0027 OE No. 1.519.165 Description Spring brake cylinder 30/30 Remarks 925.422.209.0 Front Tigril No. DB12.0028 OE No. 1.519.378 Description Spring brake cylinder 24/24 Remarks 925.461.010.0 Tigril No. DB12.0029 OE No. 1.518.146 Description Spring brake cylinder 24/24, full thread push rod Remarks 925.321.202.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 53

DAF Tigril No. DB13.0040 OE No. 1.519.442 Description Spring brake cylinder 20/24 right Remarks 925.480.004.0 Rear Tigril No. DB13.0042 OE No. 1.505.448 Description Spring brake cylinder 16/24 Remarks 925.464.500.0 Rear Tigril No. DB13.0043 OE No. 1.518.153 Description Spring brake cylinder 16/24 Remarks 925.424.100.0 Rear 95, LF 45/55, F 2100/2300/2500/2900/3200/3300/3600 Tigril No. MA13.0011 OE No. 1.506.372 Description Spring brake cylinder 24X24 Remarks 925.321.300.0 Tigril No. MA13.0012 OE No. 1519158 Description Spring brake cylinder, left 24/24 (push rod-full thread) Remarks 925.421.751.0 925.491.755.0 Tigril No. DB14.0071 OE No. 1.506.410 Description Air dryer, with heating unit Remarks 932.400.024.0 932.400.002.0 CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0005 OE No. 1.681.570 Description Air dryer Remarks ZB4706 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 54

DAF CF 75 /IV, CF 85 /IV, XF 95/106 Tigril No. DA14.0006 OE No. 1.681.571 Description Air dryer Remarks ZB4708 95 XF, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0017 OE No. 1.443.153 Description Air dryer complete, with safety valve Remarks ZB4578 95 XF, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0018 OE No. 1.607.424 Description Air dryer, complete with valve Remarks K000390 / LA8130 Tigril No. DB14.0075 OE No. 1.517.978 Description Air dryer Remarks 432.421.008.0 Tigril No. DB14.0076 OE No. 1.517.975 Description Air dryer Remarks 432.421.002.0 Tigril No. DB14.0078 OE No. 1.517.973 Description Air dryer Remarks 432.420.002.0 Tigril No. DB14.0079 OE No. 1.505.230 Description Air dryer Remarks 932.500.007.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 55
