Spare Parts Catalogue for Commercial Vehicles Version 01/2024-25 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI Trailer Page 1 Index I (Tigril No - OE No) Page 5 Index II (OE No - Tigril No) Page 6
TRAILER Tigril No. TR10.0002 OE No. Description Air suspension with lifting Remarks Rear Trailer Tigril No. TR24.0001 OE No. Description Spacing rings Remarks Rear Trailer Tigril No. TR09.0001 OE No. 6115000X Description Rubber bush, leaf spring Remarks Rear Trailer Tigril No. TR10.0001 OE No. Description Polyamide bush Remarks Rear Tigril No. TR14.0001 OE No. KW4648/1 Description Check valve Remarks M22, M22 X 1.5 Tigril No. TR15.0005 OE No. JSK 37C Description Fifth wheel 2" casting type Remarks Rear Height - 185mm Tigril No. TR15.0006 OE No. JSK 38C-1 Description Fifth wheel 3.5" casting type Remarks Rear Height - 190mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1
TRAILER Trailer Tigril No. TR15.0008 OE No. Description Fifth wheel 2" fabricated type Remarks Rear-Height 173mm Trailer Tigril No. TR15.0009 OE No. Description Fifth wheel 3.5" fabricated type Remarks Rear-Height 185mm Tigril No. TR15.0014 OE No. TR15.0014 Description Fifth wheel 3.5", height 185 mm fabricated type Remarks Height - 185mm Tigril No. TR15.0015 OE No. TR15.0015 Description Fifth wheel 3.5", height 185 mm (heavy duty) 20 mm thickness fabric Remarks Height - 185mm Tigril No. TR15.0010 OE No. SK2421-56 Description Fifth wheel kit Remarks Tigril No. TR15.0011 OE No. SK2421-78 Description Fifth wheel kit Remarks Tigril No. TR15.0012 OE No. SK2421-76Z Description Fifth wheel kit Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2
TRAILER Tigril No. TR15.0013 OE No. SK2405-14 Description Fifth wheel kit Remarks Tigril No. TR15.0002 OE No. Description King pin 2" Remarks KZ 1012-01 Tigril No. TR15.0004 OE No. Description King pin 3.5" Remarks KZ 1412-01 Tigril No. TR15.0001 OE No. Description King pin 2" complete assy Remarks KZ 1012 Tigril No. TR15.0003 OE No. Description King pin 3.5" complete assy Remarks KZ 1412 Trailer Tigril No. TR99.0004 OE No. Description Landing gear set Remarks Inner Trailer Tigril No. TR99.0005 OE No. Description Landing gear set Remarks Outer OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3
TRAILER Trailer Tigril No. TR99.0006 OE No. Description Landing gear set in board 11 holes Remarks In board 11 holes Tigril No. TR99.0007 OE No. Description Landing gear set out board 11 holes Remarks Out board 11 holes Tigril No. TR15.0007 OE No. Description Hanger suspension Remarks Rear (Includes Front, Middle, Rear) Trailer Tigril No. TR99.0001 OE No. Description Container twist lock (light version) Remarks Rear Trailer Tigril No. TR99.0002 OE No. Description Container twist lock (heavy version) Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4
Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5 TR09.0001 6115000X 1 TR10.0001 1 TR10.0002 1 TR14.0001 KW4648/1 1 TR15.0001 3 TR15.0002 3 TR15.0003 3 TR15.0004 3 TR15.0005 JSK 37C 1 TR15.0006 JSK 38C-1 1 TR15.0007 4 TR15.0008 2 TR15.0009 2 TR15.0010 SK2421-56 2 TR15.0011 SK2421-78 2 TR15.0012 SK2421-76Z 2 TR15.0013 SK2405-14 3 TR15.0014 TR15.0014 2 TR15.0015 TR15.0015 2 TR24.0001 1 TR99.0001 4 TR99.0002 4 TR99.0004 3 TR99.0005 3 TR99.0006 4 TR99.0007 4
Index II (OE No - Tigril No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6 6115000X TR09.0001 1 JSK 37C TR15.0005 1 JSK 38C-1 TR15.0006 1 KW4648/1 TR14.0001 1 SK2405-14 TR15.0013 3 SK2421-56 TR15.0010 2 SK2421-76Z TR15.0012 2 SK2421-78 TR15.0011 2 TR15.0014 TR15.0014 2 TR15.0015 TR15.0015 2
