Spare Parts For Commercial Vehicles

Spare Parts Catalogue for Commercial Vehicles Version 01/2024-25 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI MAN Page 1 Index I (Tigril No - OE No) Page 65 Index II (OE No - Tigril No) Page 86

MAN D 0826/2565, D 2566/2840, D 2842/2865, D 2866/2876 Tigril No. DB01.0025 OE No. 51.01804.7021 Description Oil separator Remarks D 2566, D 2840, D 2842, D 2866 Tigril No. DB01.0026 OE No. 51.01804.7026 Description Oil separator Remarks TGA, E/F 2000, HOCL Tigril No. MA01.0008 OE No. 51.01804.7034 Description Oil separator Remarks Tigril No. DB16.0039 OE No. 51.27421.0088 Description Oil pressure sensor Remarks Tigril No. DB01.0051 OE No. 81.12101.6012 Description Fuel feed pump Remarks D 2566 Tigril No. DB01.0052 OE No. 51.12101.7007 Description Fuel feed pump Remarks D 2566 Tigril No. DB01.0053 OE No. 81.12101.6022 Description Fuel feed pump Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1

MAN Tigril No. DB01.0055 OE No. 51.12101.7043 Description Fuel feed pump Remarks E/EM/F 2000, HOCL, LC, LION, M 2000, M 90, NG/NL, TGA, TGL, TGM Tigril No. DB01.0057 OE No. 81.12150.6010S Description Fuel feed pump with plug Remarks D 2865, D 2866, D 2876 Tigril No. DB01.0058 OE No. 51.12101.70.97 Description Fuel feed pump Remarks D 0826, D 2865, D 2866 Tigril No. MA01.0010 OE No. 51.12101.7082 Description Fuel feed pump Remarks 0.440.008.174 F 90 Tigril No. MA01.0011 OE No. 51.12101.7106 Description Fuel feed pump Remarks 0.440.008.084 D 2566, D 2840, D 2866 Tigril No. DB01.0061 OE No. 51.12150.7003 Description Fuel hand pump Remarks D 2566, D 2840, D 2866 Tigril No. DB01.0060 OE No. 81.12150.6003 Description Fuel hand pump Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2

MAN TGA,TGL,TGM, E/F 2000, M 2000 L/M, L 2000, F 90 Tigril No. DB01.0063 OE No. 81.12150.6013 Description Fuel hand pump, with gasket Remarks F90, HOCL, M90 Tigril No. DB01.0067 OE No. 81.12102.0002 Description Feed pump repair kit Remarks E/EM/F 2000, HOCL, LC, LION, M 2000, M 90, NG/NL, TGA, TGL, TGM Tigril No. DB01.0056 OE No. 81.12150.6010 Description Fuel feed pump Remarks HOCL, Lion S, M 2000 L, NG/NL/NM/ NU/SL/SU, TGA, TGL, TGM, TGS, TGX Tigril No. DB01.0068 OE No. 51.12503.0043 Description Filter repair kit, without filter housing Remarks Tigril No. DB01.0039 OE No. 90.81692.9667 Description Overflow valve Remarks Cityliner, Jetliner, Megaliner, Skyliner, Transliner Tigril No. DB01.0041 OE No. 51.11167.0024 Description Overflow valve Remarks Tigril No. DB01.0042 OE No. 51.11107.0014 Description Overflow valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3

MAN TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0026 OE No. 51.12505.0027 Description Control valve, injection pump Remarks 0.928.400.627 TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0027 OE No. 51.12505.0033 Description Control valve, injection pump Remarks 0.928.400.746 F/M/L 2000, F/M/G 90, F 7/8/9, TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0028 OE No. 51.12505.0037 Description Control valve, injection pump Remarks 0.928.400.744 TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0029 OE No. 51.10304.0050 Description Pressure limiting valve Remarks 1.110.010.020 F/M/L 2000, F/M/G 90, F 7/8/9, TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0030 OE No. 51.10304.0278 Description Pressure limiting valve Remarks 1.110.010.022 TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0031 OE No. 51.10304.0120 Description Pressure limiting valve Remarks 1.110.010.008 TGA/TGL/TGM/TGS/TGX Tigril No. MA01.0032 OE No. 51.12505.0042 Description Control valve, injection pump Remarks 0.928.400.757 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4

MAN E/F/L 2000, EL/EM, F 2000, F/M 90, HOCL, M 2000 L/M, TGA D 2866, D 2876 Tigril No. MA01.0012 OE No. 51.12501.7228 Description Prefilter Remarks 2.457.434.010 F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGL, TGM, TGS, D 0824/0826, D 0834/0836 Tigril No. MA01.0024 OE No. 81.12503.0086 Description Fuel filter insert Remarks F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGL, TGM, TGS, TGX, D 0824/0826, D 0834/0836 Tigril No. MA01.0025 OE No. 85.12501.0002 Description Fuel filter insert Remarks F 2000, F 90 D2866LF03 Tigril No. MA01.0014 OE No. 51.09100.9330 Description Turbo charger Remarks 420 HP F/M/L 2000, F/M/G 90, F 7/8/9 D 2866 , TGA/TGL/TGM/TGS/TGX D 2066, D 2866 Tigril No. MA01.0015 OE No. 51.09100.7538 Description Turbo charger Remarks 228/310 (KW/HP) F 9 D2866KF Tigril No. MA01.0016 OE No. 51.09100.7186 Description Turbo charger Remarks 265/360 (KW/HP) TGA/TGL/TGM/TGS/TGX D2876LF12 Euro 3 Tigril No. MA01.0017 OE No. 51.09100.9787 Description Turbo charger Remarks 353/480 (KW/HP) OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5

MAN TGA, TGS, TGX, E 2000, F/M 90 D 2565/2566/2865/2866 Tigril No. MA12.0005 OE No. 51.54000.7058 Description Air compressor Remarks Tigril No. MA12.0008 OE No. 51.54100.7121 Description Air Compressor Remarks LP3997 M 2000 M/L, L 2000, M/G 90, HOCL, TGA D 2566/2840/2842/2865/2866/2876, E 2866 Tigril No. DB01.0094 OE No. 51.54105.6008 Description Cylinder sleeve, air compressor Remarks M 2000 M/L, L 2000, M/G 90, HOCL, TGA D 2566/2840/2842/2865/2866/2876, E 2866 Tigril No. DB01.0095 OE No. 51.54105.0007 Description Cylinder sleeve, air compressor Remarks TGA, TGS, TGX, E/F 2000, F/M 90 D 2566/2840, D 2842/2865, D 2866/2876, E 2866 Tigril No. MA12.0006 OE No. 51.54114.6024 Description Cylinder head with gasket, compressor Remarks ZB4275 Tigril No. DB01.0033 OE No. 51.26201.9067 Description Starter 24V 4.0kW Remarks F 2000, F90, HOCL, LION Tigril No. DB01.0036 OE No. 51.26201.7092 Description Starter 24V 5.4kW Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6

MAN E/F 2000, EL, F90, NG/NL/NU/SD/SG/SR/SU/UL, TGA Tigril No. DB01.0037 OE No. 51.26201.7110 Description Starter 24V 6.6kW Remarks Tigril No. VO01.0027 OE No. 81.26201.9029 Description Starter 24V 5.4kW Remarks TGA/TGL/TGM/TGS/TGX. F/E 2000, F/M 90 D 2840,2866, 2876, 0826/2566, 2840, 2842 Tigril No. DB16.0046 OE No. 90.81616.0363 Description Solenoid switch Remarks TGA/TGL/TGM/TGS/TGX. F/E 2000, F/M 90 D 2840,2866, 2876, 0826/2566, 2840, 2842 Tigril No. DB16.0047 OE No. 81.26212.0028 Description Solenoid switch Remarks F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGL, TGM, TGS, TGX Tigril No. VO01.0029 OE No. 81.26225.6003 Description Starter clutch Remarks F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGL, TGM, TGS, TGX D 0824/0826/2566/2840 Tigril No. DB01.0070 OE No. 51.26101.7144 Description Alternator 28V 55AH without pulley Remarks MAN F,M, L 2000, F, M, G 90, F 7, 8, 9 Tigril No. DB01.0183 OE No. 51.26101.9174 Description Alternator 28V 27AH Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 7

MAN E/F/L 2000, M 2000 L/M, NL, TGA Tigril No. MA01.0009 OE No. 51.26101.7232 Description Alternator 28V 80AH without pulley Remarks 0.123.525.501 F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGL, TGM, TGS, TGX Tigril No. VO01.0024 OE No. 81.25601.6035 Description Regulator 28.5 V Remarks TGA/TGL/TGM/TGS/TGX D 0824/0826, D 2565/2566, D 2840/2842, D 2865/2866/76, E 2866 Tigril No. VO01.0026 OE No. 81.26109.0018 Description Rectifier Remarks Tigril No. VO01.0028 OE No. 81.25921.6051 Description Carbon brush set Remarks F 2000, TGA, TGS, TGX, Lions City, Centroliner Tigril No. SC14.0011 OE No. 81.27421.0163 Description Pressure sensor Remarks Tigril No. VO01.0065 OE No. 55.50550.4007 Description Oil filter Remarks M 90, SL/SD/SU D 2566, D 2866, E 2866 Tigril No. DB01.0016 OE No. 51.06500.9387 Description Water pump Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 8

MAN D 2565 Tigril No. DB01.0017 OE No. 51.06500.9228 Description Water pump Remarks D 2840, D 2842, D 2866 Tigril No. DB01.0019 OE No. 51.06500.6283 Description Water pump Remarks F 2000, TGA, D 2866, D 2876 Tigril No. MA01.0004 OE No. 51.06500.7089 Description Water pump Remarks 5520.0112 EM/MN/SM, L 2000, M 2000 L/M, M90, TGA, TGS, TGX, D 2066, D 2676 Tigril No. MA01.0005 OE No. 51.06500.6642 Description Water pump Remarks 5520.0118 F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGM, TGS, TGX Tigril No. MA01.0006 OE No. 51.06500.7130 Description Water pump Remarks TGA, TGL, TGM, TGS, TGX Tigril No. MA01.0007 OE No. 51.06500.7138 Description Water pump Remarks TGA, TGS, TGX D 2066 Tigril No. MA01.0020 OE No. 51.06500.7049 Description Water pump Remarks 5520.0114 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 9

MAN TGA, TGL, TGM D 0836 Tigril No. MA01.0021 OE No. 51.06500.6587 Description Water pump Remarks 5520.0127 TGL, TGA, M 2000 L, SL, SÜ, Lion's City, HOCL Tigril No. MA01.0022 OE No. 51.06500.6673 Description Water pump Remarks 5520.0139 TGL, TGA, M 2000 L, FOCL Tigril No. MA01.0023 OE No. 51.06500.6674 Description Water pump Remarks 5520.0131 E/F 2000, TGA, TGX Tigril No. MA01.0013 OE No. 51.06500.7037S1 Description Repair kit, water pump Remarks 35027 TGA D2876/2866 Tigril No. MA01.0018 OE No. 51.06520.0108 Description Slide ring seal (new type), water pump shaft Remarks Tigril No. DB01.0075 OE No. 51.06402.0065 Description Thermostat 71 °C Remarks Tigril No. DB01.0167 OE No. N1.01100.9483 Description Tensioner pulley, 42 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 10

MAN Tigril No. DB01.0175 OE No. N1.01100.9483 Description Tensioner pulley, 52 mm Remarks GA/TGL/TGM/TGS/TGX Tigril No. DB01.0186 OE No. 51.96820.0355 Description Multiribbed V-belt 8PK1376 Remarks TGA, TGL, TGM, TGS, TGX Tigril No. DB01.0188 OE No. 51.96820.0272 Description Multiribbed V-belt 8PK1635 Remarks Tigril No. DB01.0190 OE No. N1.01107.4209 Description Multiribbed V-belt 9PK1920 Remarks Tigril No. DB01.0195 OE No. 06.58049.0039 Description Multiribbed V-belt 9PK2871 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0199 OE No. 06.58043.0128 Description V-belt AVX10X1175 Remarks Bus / Neoplan, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0200 OE No. 06.58042.2221 Description V-belt AVX13X1000 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 11

MAN MAN Bus / Neoplan, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0201 OE No. 06.58043.0223 Description V-belt AVX13X1050 Remarks Bus / Neoplan, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0202 OE No. 06.58041.0225 Description V-belt AVX13X1100 Remarks Bus / Neoplan, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0203 OE No. 06.58041.0228 Description V-belt AVX13X1175 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0204 OE No. 06.58040.2235 Description V-belt AVX13X1350 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0205 OE No. 06.58043.0237 Description V-belt AVX13X1400 Remarks Tigril No. DB01.0206 OE No. 06.58046.0239 Description V-belt AVX13X1450 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0207 OE No. 06.58041.0240 Description V-belt AVX13X1475 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 12

MAN F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0208 OE No. 06.58040.2242 Description V-belt AVX13X1525 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0209 OE No. 06.58043.2243 Description V-belt AVX13X1550 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0210 OE No. 06.58043.0244 Description V-belt AVX13X1575 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0211 OE No. 06.58040.0245 Description V-belt AVX13X1600 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB01.0212 OE No. 06.58043.0251 Description V-belt AVX13X1750 Remarks Tigril No. DB01.0213 OE No. 06.58041.2213 Description V-belt AVX13X800 Remarks TGA, TGL, TGM, TGS, TGX Tigril No. MA01.0033 OE No. 51.96820.0273 Description Multiribbed V-belt 8PK1920 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 13

MAN TGA, TGL, TGM, TGS, TGX Tigril No. MA01.0034 OE No. 51.96820.0238 Description Multiribbed V-belt 8PK880 Remarks Bus / Neoplan, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA01.0035 OE No. 51.96820.0273 Description V-belt AVX10X1500 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA01.0036 OE No. 06.58040.2229 Description V-belt AVX13X1200 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA01.0037 OE No. 06.58041.2230 Description V-belt AVX13X1225 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA01.0038 OE No. 06.58040.0231 Description V-belt AVX13X1250 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA01.0039 OE No. 06.58041.0238 Description V-belt AVX13X1425 Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA01.0040 OE No. 06.58043.0241 Description V-belt AVX13X1500 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 14

MAN F 7/8 Tigril No. MA01.0001 OE No. 81.96210.0242 Description Engine mounting Remarks Front SL/SG/SÜ/SR/SD, NL Tigril No. MA01.0002 OE No. 81.96210.0302 Description Engine mounting Remarks Front SL/SR Tigril No. MA01.0003 OE No. 81.96210.0245 Description Engine mounting Remarks Front Tigril No. DB03.0013 OE No. N1.01100.6883 Description Clutch master cylinder, with breather valve Remarks Tigril No. DB03.0014 OE No. N1.01100.6883 Description Clutch master cylinder Remarks Tigril No. DB03.0017 OE No. N1.01100.9929 Description Clutch master cylinder Remarks Tigril No. DA03.0001 OE No. 85.30001.9892 Description Clutch servo Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 15

MAN HOCL Tigril No. DB03.0006 OE No. 81.30725.6104 Description Clutch servo Remarks TGA, TGS, TGX, HOCL, SL/SU Tigril No. MA03.0001 OE No. 81.30725.6084 Description Clutch servo Remarks 970.051.412.0 E/F 2000, F 90 Tigril No. MA03.0003 OE No. 81.30725.6064 Description Clutch servo Remarks 970.051.414.0 II31733 SL II, SÜ Tigril No. MA03.0004 OE No. 81.30725.6026 Description Clutch servo Remarks 970.051.111.0 F 90, F/E 2000 Tigril No. MA03.0006 OE No. 81.30725.6032 Description Clutch servo Remarks 970.051.157.0 625586AM TGA, TGS, TGX Tigril No. MA03.0007 OE No. 81.30725.6116 Description Clutch servo Remarks 970.051.466.0 TGA/TGL/TGM/TGS/TGX Tigril No. MA03.0008 OE No. 81.30716.6102 Description Clutch servo Remarks K013727 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 16

MAN Tigril No. SC03.0006 OE No. 1.6040.0213 Description Clutch servo Remarks F 90, E/F 2000 Tigril No. MA03.0005 OE No. 81.30725.6079 Description Repair kit, clutch servo Remarks 970.051.943.2 TGA, TGS, TGX Tigril No. DB14.0099 OE No. 81.25937.0045 Description Sensor, clutch servo Remarks F 7/8 Tigril No. DB04.0009 OE No. 81.32735.6041 Description Shifting cylinder Remarks TGA, TGX (79X) Tigril No. MA04.0003 OE No. 81.32605.6111 Description Gear lever actuator Remarks 627496AM TGA Tigril No. MA04.0006 OE No. 81.32655.6181 Description Shifting cylinder Remarks 629218AM TGA Tigril No. MA04.0007 OE No. 81.32655.6182 Description Shifting cylinder Remarks 629219AM OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 17

MAN F 9 Tigril No. DB04.0017 OE No. 81.32734.6027 Description Switch, splitter gearbox Remarks F/M/L 2000, F/M/G 90, F 7/8/9, M/F 90 Tigril No. DB16.0002 OE No. 81.25505.0930 Description Switch, starting lock Remarks F/M 90, R/SG/SL/SR/SU Tigril No. DB04.0004 OE No. 91.95301.0045 Description Ball joint, gear shift linkage Remarks E/F/L 2000, F/M 90, M 2000 L/M, TGA, TGL, TGM Tigril No. DB04.0005 OE No. 81.95301.6171 Description Ball joint, gear shift linkage, upper Remarks EL, E/F/L 2000, F 90, M 2000 L, G 90, M 90, TGA, TGL, TGM Tigril No. DB04.0006 OE No. 81.95301.6170 Description Ball joint, gear shift linkage, lower Remarks F 7/8 Tigril No. MA04.0001 OE No. 81.96210.0238 Description Transmission mounting Remarks Front F 7/8 Tigril No. MA04.0002 OE No. 81.96210.0184 Description Transmission mounting Remarks Front OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 18

MAN TGA/TGS/TGX Tigril No. DB04.0030 OE No. 81.32655.6157 Description Repair kit , shift cylinder Remarks TGA, TGS, TGX Tigril No. DB04.0031 OE No. 81.32655.6157S Description Repair kit full, shift cylinder Remarks TGA, TGS, TGX Tigril No. MA04.0004 OE No. 81.32655.6157 Description Repair kit, shift cylinder Remarks 628072AM TGA, TGS, TGX Tigril No. MA04.0005 OE No. 81.32655.6157S Description Repair kit full, shift cylinder Remarks Kit for 628072AM F 8, M/F 90, L/M/F 2000 Tigril No. DB04.0022 OE No. 81.52170.6128 Description Solenoid valve, shift cylinder Remarks F 7/8 Tigril No. DB14.0066 OE No. 81.52185.6046 Description 3/2 Directional control valve Remarks F/M/L/G, F 7/8/9 Tigril No. MA04.0009 OE No. 81.32734.6044 Description Shifting valve Remarks 0501.215.358 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 19

MAN F/G/M/L Tigril No. MA04.0010 OE No. 81.52131.6015 Description Solenoid valve, shift cylinder Remarks 0501.208.630 F 7 Tigril No. DB14.0018 OE No. 81.32734.6001 Description 4/2-way valve Remarks F 8, F 90 Tigril No. DB04.0018 OE No. 81.52170.6095 Description 5/2-way valve Remarks F 7/8/9, G 90 (L05), F 90 Tigril No. DB04.0019 OE No. 81.32550.0003 Description Gear shift lever valve Remarks M/F 90, L/M/F 2000, TGA Tigril No. MA14.0029 OE No. 81.52131.6017S Description Shut-off valve Remarks 6038.202.043 Tigril No. MA04.0008 OE No. 81.52160.6109 Description Solenoid valve Remarks 472.171.700.0 TGA/TGL/TGM/TGS/TGX Tigril No. MA99.0002 OE No. 85.96210.0019 Description Bush, driver cab suspension Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 20

MAN F 2000 Tigril No. MA09.0009 OE No. 81.96210.5025 Description Bush, parabolic spring (suspension) Remarks Rear F 90, F 2000 Tigril No. MA09.0010 OE No. 81.96210.5021 Description Bush, parabolic spring (suspension) Remarks Rear TGA, TGM, TGS, TGX Tigril No. MA09.0011 OE No. 81.96210.0547 Description Bush, parabolic spring (suspension) Remarks Rear TGA, TGM, TGS, TGX Tigril No. MA09.0012 OE No. 81.96210.0548 Description Bush, parabolic spring (suspension) Remarks Rear TGA, TGS, TGX, TGM, F 2000 Tigril No. MA09.0007 OE No. 81.43600.6036 Description Air spring with metal piston Remarks Rear 4882 N1 P05, 34882 C F2000, TGA, TGM, TGS, TGX Tigril No. MA09.0006 OE No. 81.43601.0151 Description Air spring without piston with plate Remarks Rear 4882 N1 P01, 34882 P F 7/8/9 Tigril No. DB10.0002 OE No. 81.43601.0037 Description Air bellow Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 21

MAN TGA, TGS, TGX Tigril No. MA08.0003 OE No. 81.43601.0163 Description Air bellow Remarks Front 1888 N, 31888 SD, SG, SL, SR, SUE Tigril No. MA10.0001 OE No. 81.43601.0059 Description Air bellow Remarks Lifting axle 715 N, 3715 Tigril No. VO09.0014 OE No. 81.43601.0136 Description Air bellow Remarks Tigril No. VO10.0001 OE No. 81.43601.0017 Description Air bellow Remarks 1O U 210 R12, BS 100 GT SKD, BS 120 N Tigril No. VO10.0002 OE No. 90.83112.0144 Description Air bellow Remarks F 2000, TGA, TGX, TGS Tigril No. MA09.0002 OE No. 81.43270.6087 Description Triangular control arm Remarks Rear TGA, TGX, TGS Tigril No. MA09.0003 OE No. 81.43270.6096 Description Triangular control arm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 22

MAN F 2000, TGA, TGX, TGS Tigril No. MA09.0004 OE No. 81.43270.6116 Description Triangular control arm Remarks Rear TGA, TGS, TGX Tigril No. MA09.0005 OE No. 81.43270.6102 Description Triangular control arm Remarks Rear TGA, TGS, TGX Tigril No. MA09.0008 OE No. 81.43220.6327 Description Track control arm/Reaction rod, four-point Remarks Rear F 2000, TGA, TGS, TGX Tigril No. MA09.0013 OE No. 81.43270.6117 Description Triangular control arm Remarks Rear E/F 2000, F90, TGA Tigril No. MA09.0014 OE No. 81.43270.6030 Description Track control arm Remarks Rear TGA, TGS, TGX D 2066, D 2676 Tigril No. MA09.0015 OE No. 81.43270.6145 Description Track control arm Remarks TGA, TGS, TGX, M 2000 L, Lion Tigril No. DB08.0009 OE No. 81.43270.6109 Description Torsion link repair kit 85 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 23

MAN F/M/L 2000, F/M/G 90, F 7/8/9, TGA/TGL/TGM/TGS/TGX Tigril No. DB09.0002 OE No. 85.43220.6002 Description Torsion link repair kit 75 mm Remarks SL/SG/SÜ/SR Tigril No. DB09.0015 OE No. 81.43270.6045 Description Torsion link repair kit 95 mm Remarks F 2000, TGA/TGM/TGS/TGX Tigril No. DB09.0018 OE No. 81.43270.6110 Description Torsion link repair kit 100 mm Remarks E/F 2000, F 90, NL/SD/SR/UL, TGA, TGX Tigril No. MA09.0001 OE No. 81.43220.6107 Description Torsion link repair kit 85 mm Remarks Ø85 x 30 / Ø19 x 130 Rear TGA/TGL/TGM/TGS/TGX Tigril No. MA09.0016 OE No. 81.43220.6285 Description Torsion link repair kit 85 mm Remarks Ø85 x 24 / Ø25 x 130 Tigril No. MA09.0017 OE No. 81.25937.0036 Description Level sensor Remarks 0.504.002.111 F/M 90, NL/NG/NM Tigril No. DB16.0007 OE No. 81.25937.0015 Description Distance sensor, ECAS Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 24

MAN TGL, TGM, TGA, TGS, TGX Tigril No. DB16.0038 OE No. 81.25937.0040 Description Distance sensor, ECAS Remarks L/M/F 2000 Tigril No. DB16.0048 OE No. 81.25937.0016 Description Distance sensor, ECAS Remarks L/M/F 2000, F 7/8/9 Tigril No. DB14.0055 OE No. 81.43619.6006 Description Level valve Remarks NL/NG Tigril No. MA14.0013 OE No. 81.43610.6116 Description Level valve Remarks 464.006.002.0 F 90, M/F 2000, TGA, TGS, TGX Tigril No. MA14.0028 OE No. 81.43610.6129 Description Levelling valve Remarks 464.007.001.0 Tigril No. SC14.0017 OE No. N2.50999.0136 Description Levelling valve Remarks L 2000 Tigril No. DB14.0052 OE No. 81.25902.6154 Description Solenoid valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 25

MAN L/M/F 2000, TGA, TGS, TGX, SÜ, ND, ÜL/RH, Lion's Classic/Coach/Star, Tourliner Tigril No. MA14.0027 OE No. 81.25902.6158 Description Solenoid valve ECAS Remarks 472.900.057.0 472.880.050.0 Tigril No. SC14.0016 OE No. 79.10058.0415 Description Solenoid valve, ABS Remarks EL, F 2000, F 90, M 2000 L/M, M 90, NG/NL/NM/SD/SG/SU/SL Tigril No. MA08.0001 OE No. 81.44205.6013 Description King pin kit single Remarks Front L/R EL, F 2000, F 90, M 2000 L/M, M 90, NG/NL/NM/SD/SG/SU/SL Tigril No. MA08.0002 OE No. 81.44205.6013 Description King pin kit double Remarks Front L/R F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA08.0004 OE No. 81.44205.6023 Description King pin kit single Remarks Front F 2000, TGA, TGL, TGM, TGS, TGX Tigril No. MA08.0005 OE No. 81.44205.6030 Description King pin kit single Remarks Front EL/NL, F 2000, F/M 90, NG/ND Tigril No. DB09.0001 OE No. 81.35710.0044 Description Wear ring, wheel hub 115 x 145 x 32 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 26

MAN F 2000, F/M 90, SG/SL/SR Tigril No. DB09.0019 OE No. 81.35710.0045 Description Wear ring, wheel hub 110 x 145 x 32 Remarks TGL, TGM, TGA, TGS, TGX, F 7/8/9, G/M/F 90, L/M/F 2000, CLA Tigril No. BP24.0005 OE No. 81.45422.0060 Description Wheel bolt M20 x 2 x 117/115 mm, 10.9 Remarks Tigril No. DB24.0001 OE No. 81.45501.0084 Description Wheel bolt M22 x 1.5 x 130.5/120 mm, 10.9 Remarks E/F 2000, M 2000 L/M, TGA, TGM, TGS Tigril No. DB24.0002 OE No. 81.45501.0083 Description Wheel bolt M22 x 1.5 x 125.5/115 mm, 10.9 Remarks E/F/L 2000, E/F 90, Lions/City classic, M 2000 M, NL/SG/SL, TGA, TGS, TGX Tigril No. DB24.0003 OE No. 81.45501.0067 Description Wheel bolt M22 x 1.5 x 120.5/110 mm, 10.9 Remarks F 7/8/9, F/M 90, NG/SG/SL Tigril No. DB24.0004 OE No. 81.45501.0081 Description Wheel bolt M22 x 1.5 x 115.5/105 mm, 10.9 Remarks F 7/8/9, M/F 90, L/M/F 2000, TGM, TGA/TGS Tigril No. DB24.0005 OE No. 81.45501.0059 Description Wheel bolt M22 x 1.5 x 108.5/98.5 mm, 10.9 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 27

MAN Tigril No. DB24.0006 OE No. 81.45501.0137 Description Wheel bolt M22 x 1.5 x 99/88.5 mm, 10.9 Remarks M/F 90, L 2000, M/F 2000 Tigril No. DB24.0007 OE No. 81.45501.0076 Description Wheel bolt M22 x 1.5 x 91/80.5 mm, 10.9 Remarks F/M 90, M 2000 M Tigril No. MA24.0001 OE No. 81.45501.0137 Description Wheel bolt M22 x 1.5 x 99/89 mm, 10.9 Remarks M 22 x 1.5 x 99/89 mm, 10.9 E/F 90, E/F 2000, SG/SL, TGA, 3/4 Series, P,G,R,T Series Tigril No. BP24.0004 OE No. 81.45422.0060Set Description Wheel bolt set M20 x 2 x 117/115 mm, 10.9 Remarks Tigril No. DB24.0037 OE No. 81.45501.0143S1 Description Wheel bolt set M22 x 1.5 x 130.5/120 mm, 10.9 Remarks E/F 2000, M 2000 L/M, M2000M, TGA, TGM, TGS Tigril No. DB24.0038 OE No. 81.45501.0083S1 Description Wheel bolt set M22 x 1.5 x 125.5/115 mm, 10.9 Remarks E/F/L 2000, E/F 90, Lions City, Lions Classic, M 2000M, NL/SG/SL, TGA, TGS, TGX Tigril No. DB24.0039 OE No. 81.45501.0067S1 Description Wheel bolt set M22 x 1.5 x 120.5/110 mm, 10.9 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 28

MAN E/F/L 2000, E/F 90, Lions City, Lions Classic, M 2000M, NL/ SG/SL, TGA, TGS, TGX Tigril No. DB24.0040 OE No. 81.45501.0067S2 Description Wheel bolt set M22 x 1.5 x 120.5/110 mm, 10.9 Remarks F 7/8/9, F/M 90, NG/SG/SL Tigril No. DB24.0041 OE No. 81.45501.0081S1 Description Wheel bolt set M22 x 1.5 x 115.5/105 mm, 10.9 Remarks F 7/8/9, F/M 90, NG/SG/SL Tigril No. DB24.0042 OE No. 81.45501.0081S2 Description Wheel bolt set M22 x 1.5 x 115.5/105 mm, 10.9 Remarks F 7/8/9, M/F 90, L/M/F 2000, TGM, TGA, TGS Tigril No. DB24.0043 OE No. 81.45501.0059S1 Description Wheel bolt set M22 x 1.5 x 108.5/98.5 mm, 10.9 Remarks Tigril No. DB24.0044 OE No. 81.45501.0137S1 Description Wheel bolt set M22 x 1.5 x 99/88.5 mm, 10.9 Remarks Tigril No. DB24.0045 OE No. 81.45501.0137S2 Description Wheel bolt set M22 x 1.5 x 99/88.5 mm, 10.9 Remarks M/F 90, L 2000, M/F 2000 Tigril No. DB24.0046 OE No. 81.45501.0076S1 Description Wheel bolt set M22 x 1.5 x 91/80.5 mm, 10.9 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 29

MAN M/F 90, L 2000, M/F 2000 Tigril No. DB24.0047 OE No. 81.45501.0076S2 Description Wheel bolt set M22 x 1.5 x 91/80.5 mm, 10.9 Remarks Tigril No. DB24.0055 OE No. 81.45422.0023Set Description Wheel bolt set M20 x 2 x 124 mm, 10.9 Remarks Tigril No. BP24.0002 OE No. 81.44050.0068 Description Wheel nut M22 x 2 H-25 wrench size-32 mm Remarks Tigril No. BP24.0006 OE No. 81.45423.0007 Description Wheel nut M20 x 2 H-20 wrench size-27 mm Remarks F/M 90, SG/SL/SR Tigril No. DB24.0016 OE No. 06.11222.0218 Description Wheel nut M22 x 1.5 H-22 wrench size-30 mm Remarks TGM, TGA/TGS/TGX, F/M 90, SG/SL/SR/SU Tigril No. DB24.0017 OE No. 81.45503.0026 Description Wheel nut M22 x 1.5 H-27 wrench size-32 mm Remarks TGA, EL/EM/NG/NL/NM/NU/R/SD/SG/SL/UL/G, F/L 2000, M 2000 L/M, F/M 90, LION Tigril No. DB24.0018 OE No. 06.11222.0215 Description Wheel nut M20 x 1.5 H-21 wrench size-27 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 30

MAN TGA, EL/EM/NG/NL/NM/NU/R/SD/SG/SL/UL Tigril No. DB24.0019 OE No. 06.11222.0213 Description Wheel nut M18 x 1.5 H-18 wrench size-24 mm Remarks Tigril No. DB24.0020 OE No. 06.11222.6309 Description Wheel nut M14 x 1.5 H-16 wrench size-19 mm Remarks TGA, TGL, TGM, TGS, TGX, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB24.0057 OE No. 81.45503.0058 Description Wheel nut M22 x 1.5 H-62 wrench size-32 mm Remarks TGM, TGA/TGS/TGX, F 9, G/M/F 90, L/M/F 2000, SR, NL/NM Tigril No. IV24.0001 OE No. 81.45503.0030 Description Wheel nut Remarks TGA, EL/EM/NG/NL/NM/NU/R/SD/SG/SL/UL/G, F/L 2000, M 2000 L/M, F/M 90, LION Tigril No. DB24.0021 OE No. 81.45502.0000 Description Washer (retaining ring, wheel rim) 24 x 20.5 x 8 mm Remarks TGA, F 2000, F/M 90, SL Tigril No. DB24.0027 OE No. 81.45502.0001 Description Washer (retaining ring, wheel rim) 34 x 22.5 x 8 mm Remarks TGA/TGS, F 8/9, M/F 90, L/M/F 2000 Tigril No. DB24.0028 OE No. 81.45504.0008 Description Washer (retaining ring, wheel rim) 32 x 22.2 x 5.5 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 31

MAN E 90/2000, F 90/2000, M 2000 L, TGA, SD/SG/SL/SUE Tigril No. BP24.0008 OE No. 81.91320.0048 Description Safety pin Remarks TGL, TGM, TGA, TGS, TGX, F 7/8/9, G/M/F 90, L/M/F 2000, CLA Tigril No. BP24.0011 OE No. 81.45421.0033 Description Wheel clamp Remarks Tigril No. DA11.0001 OE No. 85.30002.0399 Description Universal joint 48x116.50 mm Remarks F 90, L 2000 Tigril No. DA11.0002 OE No. 81.39200.6015 Description Universal joint 57x144 mm Remarks F 7/8, M/F 90 Tigril No. DB11.0005 OE No. 81.39200.6016 Description Universal joint 52 x 133 mm Remarks TGM/TGA/TGS/TGX, F 7/8, M/F 90, F 2000 Tigril No. DB11.0007 OE No. 81.39108.6048 Description Universal joint 57 x 152 mm Remarks TGA, TGL, TGM, TGS, TGX, M/F 90, L/M/F 2000 Tigril No. MA11.0001 OE No. 81.39410.6019 Description Propellor shaft mounting, bearing 65 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 32

MAN EL, EM, L 2000, M 2000 L/M, M/G90, NM/SD/SG/SR/SU/SM, TGA, TGL, TGM, TGS, TGX Tigril No. MA11.0002 OE No. 81.39410.6031 Description Propellor shaft mounting, bearing 85 mm Remarks Rear E/F/L 2000, M 2000 L/M, TGA, TGM, TGS Tigril No. MA12.0002 OE No. 81.50803.0040 Description Brake disc Remarks Front M 2000 L/M, TGM, TGS, TGX Tigril No. MA12.0004 OE No. 81.50803.0057 Description Brake disc Remarks Front E/F/L 2000, M 2000 L, M 2000 M, TGA, TGM, TGS Tigril No. MA13.0002 OE No. 81.50803.0041 Description Brake disc Remarks Rear NL/NG/NÜ/ND/NM, Lion's City Centroliner, Skyliner, Trolley Tigril No. SC13.0010 OE No. N1.01101.5508 Description Brake disc Remarks F 2000 Tigril No. DB12.0004 OE No. 81.50820.6032 Description Brake pad set with accessories Remarks Tigril No. DB12.0037 OE No. 81.50820.8085 Description Brake pad set with accessories Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 33

MAN M 2000 L, M 2000 M Tigril No. DB14.0002 OE No. 81.50820.6059 Description Brake pad set with accessories Remarks L2000, TGL Tigril No. DB14.0003 OE No. 81.50820.6043 Description Brake pad set with accessories Remarks F 2000 Tigril No. DB14.0006 OE No. 81.50820.6032 Description Brake pad set with accessories Remarks F 2000, M 2000 L/M, TGA Tigril No. MA12.0003 OE No. 81.50820.6051 Description Brake pad set with accessories Remarks 29131 29156 Front EL/EM/NG/NL/NM/NU/SU, F/M 2000, F 90, LION, TGA Tigril No. MA14.0001 OE No. 81.50820.5006 Description Brake pad set with accessories Remarks 29030 29113 29210 Front & Rear TGA/TGL/TGM/TGS/TGX Tigril No. MA14.0037 OE No. 81.50820.6066 Description Brake pad set with accessories Remarks WVA 29279 WVA 29223 WVA 29337 Front & Rear F 7/8, F 9 (498), M/F 90, L 2000 (L67), M/F 2000, TGA, TGS, TGX, SL/SG/SÜ, ÜL, Lion's Tigril No. MA12.0001 OE No. 81.50110.0232 Description Brake drum Remarks 410 x 180 Front OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 34

MAN F 7/8/9, M/F 90, L/M/F 2000, TGM, TGA/TGS Tigril No. MA12.0007 OE No. 81.50110.0118 Description Brake drum Remarks 410 x 172 Front F 7/8, F 90, L/M/F 2000, TGA, TGS, TGX, SL/SG/SÜ/SR, NL/NG/ND, EL/ÜL/RH, Lion's Tigril No. MA13.0001 OE No. 81.50110.0144 Description Brake drum Remarks 410 x 220 Rear F 2000, F 90, M 2000 L, M 2000 M, M 90, SD/SG/SL/SR/SU/UL Tigril No. DB13.0012 OE No. 81.50221.6093 Description Brake lining with rivets, std Remarks F 2000, F 90, M 2000 L, M 2000 M, M 90, SD/SG/SL/SR/SU/UL Tigril No. DB13.0013 OE No. 81.50221.6097 Description Brake lining with rivets, std Remarks EL/EM, F 2000 L,F 90, M 2000 L, M 2000 M, M 90, SD/SL/SR, TGA Tigril No. DB13.0014 OE No. 81.50221.6118 Description Brake lining with rivets, std Remarks F 2000, F 90, M 2000 L, M 2000 M, M 90, SD/SG/SL/SR/SU/UL Tigril No. DB13.0055 OE No. 81.50221.6097 Description Brake lining with rivets, 18 mm Remarks F 2000, F 90, M 2000 L, M 2000 M, M 90, SD/SG/SL/SR/SU/UL Tigril No. DB13.0056 OE No. 81.50221.6097 Description Brake lining with rivets, 19 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 35

MAN EL/EM, F 2000 L,F 90, M 2000 L, M 2000 M, M 90, SD/SL/SR, TGA Tigril No. DB13.0057 OE No. 81.50221.6118 Description Brake lining with rivets, 18 mm Remarks EL/EM, F 2000 L,F 90, M 2000 L, M 2000 M, M 90, SD/SL/SR, TGA Tigril No. DB13.0058 OE No. 81.50221.6118 Description Brake lining with rivets, 19 mm Remarks TGL, TGA, TGS, TGX, SL/ SG/SÜ/SR/SD/NL/NG/ND/EL/ÜL, RH Lion's City, Classic Tigril No. DB13.0046 OE No. 81.50202.0127 Description Brake carrier Remarks E/F 2000, F/M 90, M 2000 L/M Tigril No. DB13.0019 OE No. 81.50201.6190 Description Brake shoe with steel roller, 160 mm Remarks TGA, TGL, TGM, TGS, TGX, E/F 2000, M 2000 L/M, F/M 90 Tigril No. DB13.0020 OE No. 81.50201.6184 Description Brake shoe with roller, casting, 180 mm Remarks Tigril No. DB13.0021 OE No. 81.50201.6233 Description Brake shoe with roller, casting, 220 mm Remarks TGA, TGL, TGM, TGS, TGX, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB13.0031 OE No. 81.50201.6185 Description Brake shoe, steel, with complete kit 220 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 36

MAN TGA, TGL, TGM, TGS, TGX, E/F 2000, M 2000 L/M, F/M 90 Tigril No. DB13.0032 OE No. 81.50201.6184 Description Brake shoe, steel, with complete kit 180 mm Remarks F 90 Tigril No. DB13.0026 OE No. 81.97610.0210 Description Brake shoe spring Remarks E/F 2000, F/M 90, M 2000 L/M, SU Tigril No. DB13.0027 OE No. 81.97610.0118 Description Brake shoe spring Remarks TGA, M 2000 L, F 2000, F/M 90, EL/EM/NG/NL/NM/SG/SL/SM/SU/UL Tigril No. DB13.0029 OE No. 81.97610.0123 Description Brake shoe spring Remarks L/M/F 2000, TGA, TGS, TGX Tigril No. DB12.0033 OE No. 81.50201.6177 Description Repair kit, brake shoe Remarks F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB14.0091 OE No. 81.50212.0036S Description Repair kit, brake shoe mounting Remarks Tigril No. DB13.0006 OE No. 81.50610.6051 Description Slack adjuster manual Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 37

MAN TGA, TGS, TGX, TGM, F 2000 Tigril No. MA13.0003 OE No. 81.50610.6262 Description Slack adjuster, automatic, right Remarks 80181C Rear TGA, TGS, TGX, TGM, F 2000 Tigril No. MA13.0004 OE No. 81.50610.6261 Description Slack adjuster, automatic, left Remarks 80180C Rear TGA, F 7/8, F 9 (499), M/F 90, L/M/F 2000 Tigril No. MA13.0005 OE No. 81.50610.6212 Description Slack adjuster, automatic, right Remarks 79211C Rear TGA , F 7/8, F 9 (499), M/F 90, L/M/F 2000 Tigril No. MA13.0006 OE No. 81.50610.6211 Description Slack adjuster, automatic, left Remarks 79208C Rear TGA, F 8, M 90 (M05), F 90, L 2000 (L67), M/F 2000 Tigril No. MA13.0007 OE No. 81.50610.6214 Description Slack adjuster, automatic, right Remarks 79205C Rear F 8, M 90 (M05), F 90, L 2000 (L67), M/F 2000, TGA Tigril No. MA13.0008 OE No. 81.50610.6215 Description Slack adjuster, automatic, left Remarks 79206C Rear M 90, L/M 2000 Tigril No. MA13.0009 OE No. 81.50610.6216 Description Slack adjuster, automatic, left Remarks 79227C Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 38

MAN Tigril No. BP13.0025 OE No. 81.44050.0045 Description Return spring for slack adjuster Remarks TGM, TGA, TGS, TGX, F 7/8/9, M/F 90, L/M/F 2000 Tigril No. DB13.0047 OE No. 81.50301.0113 Description Brake camshaft, left Remarks TGM, TGA, TGS, TGX, F 7/8/9, M/F 90, L/M/F 2000 Tigril No. DB13.0048 OE No. 81.50301.0112 Description Brake camshaft, right Remarks TGA, E/F/L 2000, F/G/M 90, M 2000 L/M, SU/SL/SD Tigril No. BP12.0002 OE No. 81.51101.6083 Description Brake cylinder 24 Remarks Tigril No. DB12.0031 OE No. 81.51101.9196 Description Brake cylinder 20 Remarks Tigril No. DB12.0027 OE No. 81.50410.6680 Description Spring brake cylinder 30/30 Remarks TGA, TGL, TGM, TGS, TGX, F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. DB13.0039 OE No. 81.50201.6185 Description Spring brake cylinder 24X24 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 39

MAN L/M/F 2000, TGA, TGS, TGX Tigril No. MA13.0010 OE No. 81.50410.6610 Description Spring brake cylinder, 24x24 Remarks 925.421.750.0 TGA, E/F 2000, M 2000 L/M, L 2000, F/M/G 90 Tigril No. MA13.0011 OE No. 85.50001.4460 Description Spring brake cylinder 24X24 Remarks 925.321.300.0 TGA, TGS, TGX, M/F 2000, CLA Tigril No. MA13.0012 OE No. 81.50410.6609 Description Spring brake cylinder, left 24/24 (push rod full thread) Remarks 925.421.751.0 925.491.755.0 TGA, TGS, TGX, M/F 2000, CLA Tigril No. MA13.0013 OE No. 81.50410.6608 Description Spring brake cylinder, right 24/24 (push rod full thread) Remarks 925.421.75.20 L/F/M 2000 Tigril No. MA14.0011 OE No. 81.52102.6027 Description Air dryer Remarks 432.410.102.0 TGA, TGL, TGM, TGS, TGX F 2000, M 2000 L/M, F/M 90, FOCL Tigril No. MA14.0012 OE No. 81.52102.6097 Description Air dryer Remarks 432.410.113.0 TGL, TGM, TGA, TGS, TGX Tigril No. MA14.0015 OE No. 81.52102.6209 Description Air dryer Remarks 432.410.720.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 40

MAN TGL, TGM, TGA, TGS, TGX, L/M/F 2000 Tigril No. MA14.0016 OE No. 81.52102.6102 Description Air dryer Remarks 432.410.112.0 L/M/F 2000 Tigril No. MA14.0030 OE No. 81.52102.6098 Description Air dryer Remarks 432.410.117.0 TGL, TGM, TGA, TGS, TGX Tigril No. DB14.0072 OE No. 81.52102.0008 Description Air dryer cartridge Remarks L/M 2000 Tigril No. DB14.0073 OE No. 81.52102.0016 Description Air dryer cartridge Remarks F/M/L 2000, F/M/G 90, F 7/8/9, TGA/TGL/TGM/TGS/TGX Tigril No. DB14.0117 OE No. 81.52108.6025 Description Air dryer cartridge Remarks Tigril No. SC14.0004 OE No. N2.50999.0182 Description Air dryer cartridge Remarks TGL, TGM, TGA, TGS, TGX, G/M/F 90, L/M/F 2000 Tigril No. DB14.0118 OE No. 81.52102.6032 Description Repair kit, air dryer Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 41

MAN MAN Bus Tigril No. DB14.0080 OE No. 84.52101.6017 Description Pressure regulator Remarks F 7/8 Tigril No. DB14.0081 OE No. 81.52101.9132 Description Pressure regulator, open port M12x1.5-6H Remarks Tigril No. DB14.0082 OE No. 81.51201.9083 Description Pressure regulator, Max Operating pressure 15.0 bar Remarks F 7, G 90, SL/SR, NL/NG, ÜL/RH, Lion's City Centroliner Tigril No. DB14.0120 OE No. 82.52101.6019 Description Repair kit, pressure regulator Remarks F 7/8, SR Tigril No. DB14.0127 OE No. 81.52101.6118 Description Repair kit, pressure regulator Remarks G 90 (L05), M 90, F 90 (F12), L/M/F 2000, TGL, TGM, TGA, TGS, TGX Tigril No. IV14.0004 OE No. 81.52101.6264 Description Silencer, compressed-air system Remarks G/M/F 90, L/M/F 2000, TGL, TGM, TGA, TGS, TGX Tigril No. MA14.0020 OE No. 81.52101.6240 Description Silencer, compressed-air system Remarks 432.407.060.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 42

MAN TGL, TGM, TGA, TGS, TGX, G 90 (L05), M 90, F 90 (F12), L/M/F 2000 Tigril No. SC14.0010 OE No. 81.52101.6226 Description Silencer, compressed-air system Remarks F 7/8/9, G/M/F 90, F 2000, TGA (H69) Tigril No. MA14.0022 OE No. 81.52130.6043 Description 2-way valve Remarks 434.208.000.0 I40405 Tigril No. DB14.0124 OE No. 90.81011.5183 Description 3/2 Directional control valve Remarks Tigril No. VO01.0048 OE No. N2.52170.6021 Description 3/2 directional control valve Remarks Tigril No. DB14.0027 OE No. ZG.04643.0002 Description 4-circuit protection valve Remarks F 7/8/9, G/M/F 90 Tigril No. DB14.0041 OE No. 81.52151.6063 Description 4-circuit protection valve 10 bar Remarks F 7/8/9, G/M/F 90 Tigril No. DB14.0042 OE No. 81.52151.6063 Description 4-circuit protection valve 20 bar Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 43

MAN Tigril No. DB14.0139 OE No. ZG.04643.0002 Description 4-circuit protection valve, normal sensor Remarks L/M 2000, TGA, TGS, TGX, NL, Lion's City Tigril No. MA14.0004 OE No. 81.52151.6098 Description 4-circuit protection valve Remarks 934.714.400.0 E/F/L 2000, F 90, M 2000 L/M, SL/SÜ/SR, NL/NG/NÜ/ND/NM, ÜL/RH Tigril No. MA14.0018 OE No. 81.52151.6092 Description 4-circuit protection valve Remarks 934.714.010.0 F/M/L 2000, F/M/G 90, F 7/8/9 Tigril No. MA14.0019 OE No. 81.52151.6045 Description 4-circuit protection valve Remarks 934.702.300.0 934.702.340.0 AE 4185 F 2000, TGA, TGS, TGX, Lion's Classic Tigril No. MA14.0024 OE No. 81.52151.6094 Description 4-circuit protection valve Remarks 934.714.110.0 F 90 Tigril No. MA14.0025 OE No. 81.52151.6013 Description 4-circuit protection valve Remarks 934.702.041.0 Tigril No. DB13.0030 OE No. 88.52120.6001 Description Adaptor valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 44

MAN NL Tigril No. VO14.0022 OE No. 88.52180.6211 Description Adaptor valve, compressed air system Remarks TGL,TGM, TGA, TGS, G/M 90, G/M 90, L/M/F 2000 Tigril No. DB14.0093 OE No. 81.51270.6026 Description Air line filter Remarks Tigril No. DA14.0004 OE No. N2.50999.9119 Description Load sensing relay emergency valve Remarks Tigril No. MA14.0002 OE No. 82.52161.6002 Description Brake power regulator Remarks 475.604.011.0 M/F 2000 Tigril No. MA14.0017 OE No. 81.52130.6143 Description Brake valve Remarks MB4815 F/M 90 Tigril No. MA14.0036 OE No. 81.52315.9113 Description Brake Valve, parking brake Remarks 961.723.100.0 Tigril No. VO14.0026 OE No. N2.50999.0130 Description Double check valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 45

MAN SÜ Tigril No. DA14.0008 OE No. 81.52130.6048 Description Foot brake valve Remarks Tigril No. DB14.0028 OE No. 85.50001.4354 Description Foot brake valve Remarks Tigril No. DB14.0088 OE No. 82.52130.6014 Description Foot brake valve Remarks Tigril No. DB14.0019 OE No. 81.52315.6054 Description Hand brake valve Remarks Tigril No. DB14.0036 OE No. 81.52315.6053 Description Hand brake valve Remarks Tigril No. DB14.0067 OE No. 81.52315.6211 Description Hand brake valve Remarks TGA, TGL, TGM, TGS, TGX, E/F/L 2000, M 2000 L/M, FOCL Tigril No. MA14.0009 OE No. 81.52315.6156 Description Hand brake valve Remarks 961.723.118.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 46

MAN Tigril No. MA14.0039 OE No. 99.10036.0497 Description Hand brake valve Remarks 961.723.111.0 SL/SU/SR, UL Tigril No. DB14.0046 OE No. 81.52110.6021 Description Overflow valve Remarks Tigril No. DB14.0137 OE No. 81.52110.6099 Description Overflow valve Remarks Tigril No. DB14.0138 OE No. 81.52110.7011 Description Overflow valve Remarks SL/SÜ, NL/NG/NÜ/ND/NM, ÜL/RH, Lion's City/Classic/Coach, Regio/Star Centroliner Tigril No. MA14.0021 OE No. 81.52110.6040 Description Overflow valve Remarks 434.100.126.0 K000644 Tigril No. VO14.0027 OE No. 81.52110.6013 Description Overflow valve Remarks TGS/TGX Tigril No. DB14.0025 OE No. 81.52101.6284 Description Pressure limiting valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 47

MAN Tigril No. DB14.0045 OE No. 82.52101.6036 Description Pressure limiting valve Remarks G 90 Tigril No. DB14.0069 OE No. 82.00030.1334 Description Pressure limiting valve Remarks TGA, TGL, TGM, TGS, TGX, E/F/L 2000, M 2000 L/M, FOCL Tigril No. MA14.0008 OE No. 81.52101.6269 Description Pressure limiting valve Remarks 475.010.300.0 E 2000 Tigril No. MA14.0033 OE No. 81.52101.6150 Description Pressure limiting valve Remarks 475.015.001.0 TGA, TGX, SL/SG/SÜ/SR, NL/NG/NÜ/ND/NM, ÜL/RH, Lion's City/Classic/Coach Tigril No. MA14.0034 OE No. 81.52101.6283 Description Pressure limiting valve Remarks 475.010.314.0 L/M/F 2000, TGA, TGM, TGS, TGX Tigril No. MA14.0035 OE No. 81.52101.6270 Description Pressure limiting valve Remarks 475.010.301.0 HOCL, SR Tigril No. IV14.0007 OE No. 81.52101.6132 Description Pressure control valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 48

MAN MAN Bus Tigril No. MA14.0031 OE No. 81.52120.6021 Description Pressure regulator valve Remarks 975.001.000.0 I50402 Tigril No. MA14.0032 OE No. 84.52101.6040 Description Pressure regulator valve Remarks 475.010.307.0 L/M/F 2000, TGA, TGL, TGS, TGX, F 7/8/9, G/F 90 Tigril No. DB14.0101 OE No. 81.52115.6009 Description Quick release valve Remarks TGA, TGM, TGS, TGX, E/F 2000, M 2000 L/M, F/M/G 90, Lionstar, HOCL Tigril No. MA14.0005 OE No. 81.52115.6023 Description Quick release valve 10 bar Remarks 473.501.203.0 Tigril No. RV14.0005 OE No. N2.52116.0028 Description Quick release valve 12 bar Remarks Neoplan Tigril No. RV14.0006 OE No. N2.50999.0170 Description Quick release valve 12 bar Remarks Tigril No. DB14.0026 OE No. N1.01106.3689 Description Relay valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 49

MAN Tigril No. DB14.0029 OE No. 81.43609.6008 Description Relay valve Remarks TGA, TGL, TGM, TGS, TGX F 2000, M 2000 L/M, FOCL, HOCL Tigril No. DB14.0054 OE No. 81.52116.6075 Description Relay valve Remarks Tigril No. DB14.0061 OE No. 81.52116.6089 Description Relay valve Remarks F 7/8/9, G/F 90, L/M/F 2000, TGA, TGS (96S), SL/SG/SÜ/SR, NL/NG/NÜ/NM, EL/ÜL/RH Tigril No. DB14.0107 OE No. 81.52116.6070 Description Relay valve Remarks G/F/M 90 Tigril No. MA14.0006 OE No. 81.52116.9045 Description Relay valve Remarks 973.001.020.0 L/M/F 2000, F 7/8/9, G/F 90 Tigril No. MA14.0007 OE No. 81.52116.6068 Description Relay valve Remarks 973.006.001.0 L/M/F 2000, TGA, TGS, TGX, SR, NL/NG, EL/ÜL/RH, Lion's City/Coach Tigril No. MA14.0023 OE No. 81.52116.6071 Description Relay valve Remarks 973.011.200.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 50

MAN F/M/L 2000, F/M/G 90, F 7/8/9, TGA, TGL, TGM, TGS, TGX Tigril No. VO14.0015 OE No. 81.52116.6049 Description Relay valve Remarks TGA, TGM, TGS, TGL, TGX, E/F/L 2000, F 90, HOCL, M 2000 L/M Tigril No. DB14.0131 OE No. 88.52120.6200 Description Non return valve Remarks F 2000 Tigril No. DB14.0015 OE No. 88.51230.6200 Description Shut off valve Remarks Tigril No. DB14.0023 OE No. 99.11471.0043 Description Solenoid valve Remarks Tigril No. DB14.0024 OE No. 79.10071.0104 Description Solenoid valve Remarks L/M/F 2000,TGL/TGM, TGA/TGS/TGX Tigril No. DB14.0034 OE No. 81.25902.9239 Description Solenoid valve, ECAS Remarks L/F 2000 Tigril No. DB14.0065 OE No. 81.52452.6019 Description Solenoid valve, ABS Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 51

MAN Tigril No. DB14.0085 OE No. 81.52160.6072 Description Solenoid valve Remarks L/M/F 2000, TGA, TGM, TGS, TGX Tigril No. DB14.0097 OE No. 81.25902.9147 Description Solenoid valve, ECAS Remarks SL/SÜ/SD, NL/NG/ND/NM, ÜL, Lion's City/Classic/Coach, Regio/Star Centroliner, Jetliner Tigril No. DB14.0106 OE No. 81.52120.6020 Description Solenoid valve Remarks TGA Tigril No. MA14.0010 OE No. 81.25902.6145 Description Solenoid valve Remarks 472.900.055.0 F/M/L 2000, F/M/G 90, F 7/8/9, TGL/TGM, TGA/TGS/TGX Tigril No. MA14.0038 OE No. 81.52160.6116 Description Solenoid valve Remarks 472.072.628.0 Tigril No. RV14.0004 OE No. N2.50999.0158 Description Trailer release valve Remarks Tigril No. DA14.0003 OE No. N2.52116.0023 Description Trailer control valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 52

MAN TGA, TGL, TGM, TGS, TGX, L/M/F 2000, NG, Lion City Tigril No. DB14.0012 OE No. 81.52301.9189 Description Trailer control valve Remarks TGL, TGM Tigril No. MA14.0003 OE No. 81.52301.6208 Description Trailer control valve Remarks 480.204.002.0 Tigril No. MA14.0014 OE No. 81.52301.6148 Description Trailer control valve Remarks 971.002.150.0 F 8/9 Tigril No. SC14.0012 OE No. 81.52301.6031 Description Trailer control valve Remarks F 8/9, F 90 Tigril No. VO14.0023 OE No. 81.52301.6120 Description Trailer control valve Remarks Tigril No. RV14.0003 OE No. N2.50999.0166 Description Trailer brake valve Remarks F 7/8, G/M/F 90, L/M/F 2000, TGA, TGS, TGX Tigril No. MA14.0026 OE No. 81.51260.6002 Description Water drain valve Remarks 934.300.003.0 I94095 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 53
