Spare Parts Catalogue for Commercial Vehicles Version 01/2024-25 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI Fruehauf Page 1 Index I (Tigril No - OE No) Page 8 Index II (OE No - Tigril No) Page 9
FRUEHAUF Tigril No. DA03.0003 OE No. CF3515424 Description Repair kit, clutch servo Remarks Tigril No. SF10.0009 OE No. 003615E Description Air spring with metal piston Remarks Tigril No. DB16.0048 OE No. A3A4233 Description Distance sensor, ECAS Remarks Tigril No. DB14.0055 OE No. CF351925 Description Level valve Remarks Tigril No. MA14.0013 OE No. CF351950 Description Level valve Remarks Tigril No. FH09.0003 OE No. AJB0038.001 Description Wheel hub Remarks Front & Rear Trailer Tigril No. FH09.0001 OE No. 0030.001 Description Conical rubber bush, equalizer Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1
FRUEHAUF Trailer Tigril No. FH09.0002 OE No. 0033.001 Description Conical rubber bush, connecting rod Remarks Rear Tigril No. RO09.0006 OE No. CF150580 Description Bolt equalizer 41 mm Remarks Tigril No. RO09.0004 OE No. M021546 Description Torque arm rigid long Remarks Fruehauf Tigril No. RV24.0003 OE No. AJA0495001 Description Wheel nut M22 x 1.5 H-31 wrench size 32mm Remarks Tigril No. FH13.0001 OE No. M069018 Description Brake disc Remarks Rear Tigril No. DB12.0004 OE No. M91.004502 Description Brake pad set with accessories Remarks Tigril No. DB14.0006 OE No. M91.004502 Description Brake pad set with accessories Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2
FRUEHAUF Tigril No. BP12.0002 OE No. ASX0014020 Description Brake cylinder 24 Remarks Tigril No. BP13.0020 OE No. ASX0014021 Description Brake cylinder 30 Remarks Tigril No. DB14.0072 OE No. CF352490 Description Air dryer cartridge Remarks Tigril No. MA14.0020 OE No. K00417301 Description Silencer, compressed-air system Remarks Tigril No. MA14.0022 OE No. CF351897 Description 2-way valve Remarks Tigril No. DB14.0124 OE No. AJY8397 Description 3/2 Directional control valve Remarks Tigril No. VO14.0022 OE No. M059969 Description Adaptor valve, compressed air system Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3
FRUEHAUF Tigril No. DB14.0093 OE No. CF352169 Description Air line filter Remarks Tigril No. BP14.0005 OE No. CF351826 Description Automatic load sensing valve Remarks Tigril No. DA14.0004 OE No. CF352132 Description Load sensing relay emergency valve Remarks 3ESSIEU Semi Trailer LSV Tigril No. DA14.0007 OE No. AJA-0918-001 Description Automatic load sensing valve Remarks Tigril No. VO14.0026 OE No. CF350943 Description Double check valve Remarks Tigril No. BP14.0003 OE No. CF352131 Description Level valve Remarks Tigril No. SC14.0014 OE No. MO58229 Description Lift axle control valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4
FRUEHAUF Tigril No. DB14.0046 OE No. VFA1150001 Description Overflow valve Remarks Tigril No. VO14.0027 OE No. A43178M10A02 Description Overflow valve Remarks Tigril No. MA14.0031 OE No. ASX-0009-002 Description Pressure regulator valve Remarks Tigril No. DB14.0101 OE No. CF350933 Description Quick release valve Remarks Tigril No. RV14.0005 OE No. M059659-01 Description Quick release valve 12 bar Remarks Fruehauf Tigril No. RV14.0006 OE No. F001.424.02 Description Quick release valve 12 bar Remarks Tigril No. DB14.0029 OE No. CF3516517 Description Relay valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5
FRUEHAUF Tigril No. VO14.0015 OE No. CF3520600 Description Relay valve Remarks Tigril No. DB14.0131 OE No. CF3519226 Description Non return valve Remarks Tigril No. DB14.0015 OE No. H03098901 Description Shut off valve Remarks Tigril No. SC14.0013 OE No. M059438 Description Trailer release valve Remarks Tigril No. DA14.0003 OE No. CF351193 Description Trailer control valve Remarks Tigril No. MA14.0014 OE No. CF351054 Description Trailer control valve Remarks Tigril No. MA14.0026 OE No. CF3508486 Description Water drain valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6
FRUEHAUF Tigril No. DA14.0012 OE No. CF3519828 Description Repair kit, trailer control valve Remarks Tigril No. RV14.0007 OE No. CF3512812 Description Repair kit, load sensitive valve Remarks Fruehauf Tigril No. DA14.0019 OE No. CF102959 Description ABS sensor with bush and grease, 410 mm Remarks Tigril No. SC14.0007 OE No. AJB0050001 Description Clamping bushing, wheel speed sensor Remarks Tigril No. SC14.0008 OE No. M059318 Description Cable with connector plug/ socket ABS Remarks Tigril No. SC14.0009 OE No. CF371494 Description Cable with connector plug/ socket ABS Remarks Tigril No. DI14.0069 OE No. A3292.000 Description Test connector Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 7
Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 8 BP12.0002 ASX0014020 3 BP13.0020 ASX0014021 3 BP13.0020 M02027203 3 BP14.0003 CF352131 4 BP14.0003 F005268 4 BP14.0005 CF351826 4 BP14.0005 F001165 4 DA03.0003 CF3515424 1 DA14.0003 CF351193 6 DA14.0003 AJC0070001 6 DA14.0003 AJA0313-1 6 DA14.0003 AJC0070-1 6 DA14.0004 CF352132 4 DA14.0004 F004997 4 DA14.0007 AJA-0918-001 4 DA14.0007 CF350908 4 DA14.0012 CF3519828 7 DA14.0019 CF102959 7 DB12.0004 M91.004502 2 DB14.0006 M91.004502 2 DB14.0015 H03098901 6 DB14.0015 VSY981801 6 DB14.0029 CF3516517 5 DB14.0029 A2131600 5 DB14.0046 VFA1150001 5 DB14.0055 CF351925 1 DB14.0055 UFA14490001 1 DB14.0072 CF352490 3 DB14.0093 CF352169 4 DB14.0093 AJU6678 4 DB14.0093 F001084-03 4 DB14.0101 CF350933 5 DB14.0101 F001971 5 DB14.0124 AJY8397 3 DB14.0124 CF351271 3 DB14.0124 A16608M80A01 3 DB14.0124 H0319.7101 3 DB14.0131 CF3519226 6 DB14.0131 AJX1009 6 DB14.0131 A78860M10A02 6 DB16.0048 A3A4233 1 DI14.0069 A3292.000 7 FH09.0001 0030.001 1 FH09.0002 0033.001 2 FH09.0003 AJB0038.001 1 FH09.0003 CF1014.228 1 FH13.0001 M069018 2 FH13.0001 M200135 2 MA14.0013 CF351950 1 MA14.0013 F001572 1 MA14.0014 CF351054 6 MA14.0014 AJU7602 6 MA14.0014 H031402-01 6 MA14.0020 K00417301 3 MA14.0022 CF351897 3 MA14.0022 H03210101 3 MA14.0022 TSU03721 3 MA14.0026 CF3508486 6 MA14.0026 F001513 6 MA14.0031 ASX-0009-002 5 RO09.0004 M021546 2 RO09.0006 CF150580 2 RV14.0005 M059659-01 5 RV14.0005 CF352679 5 RV14.0006 F001.424.02 5 RV14.0007 CF3512812 7 RV24.0003 AJA0495001 2 RV24.0003 M-003141 2 SC14.0007 AJB0050001 7 SC14.0008 M059318 7 SC14.0009 CF371494 7 SC14.0009 MO58296 7 SC14.0013 M059438 6 SC14.0014 MO58229 4 SF10.0009 003615E 1 VO14.0015 CF3520600 6 VO14.0015 A21316000003047B 6 VO14.0022 M059969 3 VO14.0022 D13263 3 VO14.0026 CF350943 4 VO14.0026 F00125402 4 VO14.0027 A43178M10A02 5
Index II (OE No - Tigril No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 9 0030.001 FH09.0001 1 0033.001 FH09.0002 2 003615E SF10.0009 1 A16608M80A01 DB14.0124 3 A2131600 DB14.0029 5 A21316000003047B VO14.0015 6 A3292.000 DI14.0069 7 A3A4233 DB16.0048 1 A43178M10A02 VO14.0027 5 A78860M10A02 DB14.0131 6 AJA0313-1 DA14.0003 6 AJA0495001 RV24.0003 2 AJA-0918-001 DA14.0007 4 AJB0038.001 FH09.0003 1 AJB0050001 SC14.0007 7 AJC0070001 DA14.0003 6 AJC0070-1 DA14.0003 6 AJU6678 DB14.0093 4 AJU7602 MA14.0014 6 AJX1009 DB14.0131 6 AJY8397 DB14.0124 3 ASX-0009-002 MA14.0031 5 ASX0014020 BP12.0002 3 ASX0014021 BP13.0020 3 CF1014.228 FH09.0003 1 CF102959 DA14.0019 7 CF150580 RO09.0006 2 CF3508486 MA14.0026 6 CF350908 DA14.0007 4 CF350933 DB14.0101 5 CF350943 VO14.0026 4 CF351054 MA14.0014 6 CF351193 DA14.0003 6 CF351271 DB14.0124 3 CF3512812 RV14.0007 7 CF3515424 DA03.0003 1 CF3516517 DB14.0029 5 CF351826 BP14.0005 4 CF351897 MA14.0022 3 CF3519226 DB14.0131 6 CF351925 DB14.0055 1 CF351950 MA14.0013 1 CF3519828 DA14.0012 7 CF3520600 VO14.0015 6 CF352131 BP14.0003 4 CF352132 DA14.0004 4 CF352169 DB14.0093 4 CF352490 DB14.0072 3 CF352679 RV14.0005 5 CF371494 SC14.0009 7 D13263 VO14.0022 3 F001.424.02 RV14.0006 5 F001084-03 DB14.0093 4 F001165 BP14.0005 4 F00125402 VO14.0026 4 F001513 MA14.0026 6 F001572 MA14.0013 1 F001971 DB14.0101 5 F004997 DA14.0004 4 F005268 BP14.0003 4 H03098901 DB14.0015 6 H031402-01 MA14.0014 6 H0319.7101 DB14.0124 3 H03210101 MA14.0022 3 K00417301 MA14.0020 3 M-003141 RV24.0003 2 M02027203 BP13.0020 3 M021546 RO09.0004 2 M059318 SC14.0008 7 M059438 SC14.0013 6 M059659-01 RV14.0005 5 M059969 VO14.0022 3 M069018 FH13.0001 2 M200135 FH13.0001 2 M91.004502 DB12.0004 2 M91.004502 DB14.0006 2 MO58229 SC14.0014 4 MO58296 SC14.0009 7 TSU03721 MA14.0022 3 UFA14490001 DB14.0055 1 VFA1150001 DB14.0046 5 VSY981801 DB14.0015 6
