Spare Parts Catalogue for Commercial Vehicles Version 01/2024-25 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI DAF Page 1 Index I (Tigril No - OE No) Page 71 Index II (OE No - Tigril No) Page 83
DAF Tigril No. DB16.0031 OE No. 0.231.127 Description Sensor, oil pressure Remarks 75 CF/F/FAG/FAR/FAT/FAV/FT, 85 CF/FA/FAD/FAG/GAT/FT/FTG/FTT, 95 FA/FAC/FAD/FAG, 95 XF Tigril No. DA01.0001 OE No. 1.339.048 Description Fuel feed pump Remarks 0.440.008.089 Tigril No. DB01.0051 OE No. 0.511.756 Description Fuel feed pump Remarks F 45/55, F 65/75/85/95, 65/75/85 CF, 95 XF Tigril No. DB01.0053 OE No. 1.246.869 Description Fuel feed pump Remarks Tigril No. DB01.0057 OE No. 1.519.533S Description Fuel feed pump with plug Remarks Tigril No. DB01.0058 OE No. 1.519.532 Description Fuel feed pump Remarks F 2800 Tigril No. DB01.0061 OE No. 608.932 Description Fuel hand pump Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1
DAF F 2800 Tigril No. DB01.0060 OE No. 194.194 Description Fuel hand pump Remarks 95 XF, 75/85 CF, 75/95 Tigril No. DB01.0063 OE No. 1.311.608 Description Fuel hand pump, with gasket Remarks Tigril No. DB01.0045 OE No. 1.519.488 Description Feed pump, repair kit Remarks Tigril No. DB01.0066 OE No. 697.480 Description Feed pump repair kit Remarks 65/75/85/95, 65/75/85 CF, 95 XF, F 45/55,F 3300/3600, N 2800 Tigril No. DB01.0067 OE No. 1.315.514 Description Feed pump repair kit Remarks Tigril No. DB01.0056 OE No. 1.519.533 Description Fuel feed pump Remarks 95 XF Tigril No. DB01.0068 OE No. 1.438.836 Description Filter repair kit, without filter housing Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2
DAF F 65/85/95 Tigril No. DB01.0041 OE No. 1.228.128 Description Overflow valve Remarks Tigril No. DA01.0015 OE No. 1.638.153 Description Control valve, injection pump Remarks 0.928.400.481 Tigril No. DA16.0003 OE No. 1.705.135 Description Pressure sensor, fuel Remarks 0.281.006.325 DHS 825, DHT 825, DHTD 825 Tigril No. DA01.0004 OE No. 370.870 Description Turbo charger Remarks /250 HP F 75/85/95 Tigril No. DA01.0005 OE No. 0.389.901 Description Turbo charger Remarks 270/367 (KW/HP) 95 XF Tigril No. DA01.0006 OE No. 1.319.281 Description Turbo charger Remarks 480 HP 85 CF , 95 XF , M Tigril No. DA01.0009 OE No. 1.358.390 Description Turbo charger Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3
DAF F 800/1000/1100/1300/1700/1800/1900/2100/2300/2500/2700, Bus Tigril No. DA12.0002 OE No. 537.746 Description Air compressor Remarks 911.505.051.0 95 Tigril No. DA12.0003 OE No. 0.762.788 Description Air compressor Remarks 911.504.052.0 F 75/95, 75/85 CF, 95 XF, CF 75/85, XF 95 Tigril No. DA12.0004 OE No. 1.621.322 Description Air compressor Remarks 911.504.506.0 F 95 Tigril No. DA12.0005 OE No. 1.243.571 Description Air compressor Remarks 911.504.056.0 Tigril No. DB12.0017 OE No. 1.517.931 Description Air compressor Remarks Tigril No. DB12.0030 OE No. 1.517.937 Description Air compressor Remarks Tigril No. VO12.0008 OE No. 1.506.365 Description Air compressor Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4
DAF Tigril No. MA12.0006 OE No. 1.518.589 Description Cylinder head with gasket, compressor Remarks Tigril No. DB01.0033 OE No. 1.516.687R Description Starter 24V 4.0kW Remarks Tigril No. DB01.0034 OE No. 1.516.658R Description Starter 24V 6.2kW Remarks Tigril No. DB01.0035 OE No. 1.519.391R Description Starter 24V 6.2kW Remarks Tigril No. DB01.0036 OE No. 1.516.707R Description Starter 24V 5.4kW Remarks Tigril No. DB01.0037 OE No. 1.516.711R Description Starter 24V 6.6kW Remarks Tigril No. IV01.0003 OE No. 1.516.767R Description Starter 24V 6.6kW Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5
DAF Tigril No. IV01.0004 OE No. 1.516.672R Description Starter 24V 6.6kW Remarks Tigril No. IV01.0008 OE No. 1.516.696 Description Starter 24V 4kW Remarks Tigril No. SC01.0008 OE No. 1.516.677R Description Starter 24V 6.7kw Remarks Tigril No. SC01.0009 OE No. 1.516.656R Description Starter 24V 6.5kw Remarks Tigril No. VO01.0008 OE No. 1.516.670R Description Starter 24V 6.6kW Remarks Tigril No. VO01.0027 OE No. 1.516.770 Description Starter 24V 5.4kW Remarks F 75/85/95, 95 XF, XF 95 Tigril No. DB16.0046 OE No. 607.080 Description Solenoid switch Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6
DAF F 75/85/95, 95 XF, XF 95 Tigril No. DB16.0047 OE No. 252.121 Description Solenoid switch Remarks F 2800/2900/3200, F 3300/3600, N 2800, Bus Tigril No. VO01.0029 OE No. 258.276 Description Starter clutch Remarks F 65/75/85/95, 65/75/85 CF, 95 XF Tigril No. DB01.0070 OE No. 1.357.591 Description Alternator 28V 55AH without pulley Remarks Tigril No. DB01.0183 OE No. 1.516.525 Description Alternator 28V 27AH Remarks Tigril No. MA01.0009 OE No. 1.516.514R Description Alternator 28V 80AH without pulley Remarks Tigril No. SC01.0006 OE No. 1.516.533R Description Alternator 28V 55AH without pulley Remarks Tigril No. SC01.0007 OE No. 1.516.589R Description Alternator 28V 55AH without pulley Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 7
DAF Tigril No. VO01.0022 OE No. 1.516.583R Description Alternator 28V 55A without pulley Remarks Tigril No. VO01.0023 OE No. 0.910.378 Description Alternator 24V 110A with pulley Remarks F 2800/2900/3200, F 3300/3600, N 2800, F 65/75/85/95, 65/75/85 CF, 95 XF, Bus Tigril No. VO01.0024 OE No. 1.676.162 Description Regulator 28.5 V Remarks F 65/75/95, 65/75/85 CF, 95 XF Tigril No. VO01.0026 OE No. 1.311.304 Description Rectifier Remarks Tigril No. VO01.0028 OE No. 697.886 Description Carbon brush set Remarks Tigril No. SC14.0011 OE No. 1.506.009 Description Pressure sensor Remarks Tigril No. VO01.0065 OE No. 1.500.922 Description Oil filter Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 8
DAF F 2800/2900/3200/3300/3600, N 2800 Tigril No. DA01.0002 OE No. 682.262 Description Water pump Remarks F 95, 85 CF, 95 XF, XF 95 Tigril No. DA01.0003 OE No. 683.225 Description Water pump Remarks CF 75IV Tigril No. DA01.0010 OE No. 1.734.841 Description Water pump Remarks Tigril No. DA01.0011 OE No. 1.942.598 Description Water pump Remarks CF Euro 6, XF Euro 6 Tigril No. DA01.0012 OE No. 1.922.223 Description Water pump Remarks CF Euro 6, XF Euro 6 Tigril No. DA01.0013 OE No. 2.104.577 Description Water pump Remarks CF Euro 6, XF Euro 6 Tigril No. DA01.0014 OE No. 2.104.578 Description Water pump Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 9
DAF 95 Tigril No. VO01.0020 OE No. 1.293.885 Description Thermostat 75 °C Remarks CF 75/85, 75/85 CF Tigril No. VO01.0031 OE No. 1.439.844 Description Thermostat 82 °C Remarks 85 CF, 95 XF, CF 85 /IV, XF 95 Tigril No. DB01.0200 OE No. 1.425.709 Description V-belt AVX13X1000 Remarks Universal Tigril No. DB01.0201 OE No. 0.296.961 Description V-belt AVX13X1050 Remarks Tigril No. DB01.0202 OE No. 13H2659 Description V-belt AVX13X1100 Remarks Tigril No. DB01.0203 OE No. 0.192.144 Description V-belt AVX13X1175 Remarks Universal Tigril No. DB01.0204 OE No. 0.107.561 Description V-belt AVX13X1350 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 10
DAF Universal Tigril No. DB01.0205 OE No. 0.211.244 Description V-belt AVX13X1400 Remarks Universal Tigril No. DB01.0206 OE No. 0.212.253 Description V-belt AVX13X1450 Remarks Universal Tigril No. DB01.0207 OE No. 0.067.677 Description V-belt AVX13X1475 Remarks Universal Tigril No. DB01.0208 OE No. 0.248.761 Description V-belt AVX13X1525 Remarks Tigril No. DB01.0209 OE No. 0.216.736 Description V-belt AVX13X1550 Remarks Universal Tigril No. DB01.0210 OE No. 0.067.680 Description V-belt AVX13X1575 Remarks Universal Tigril No. DB01.0211 OE No. 0.067.681 Description V-belt AVX13X1600 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 11
DAF Universal Tigril No. DB01.0212 OE No. 0.168.923 Description V-belt AVX13X1750 Remarks Universal Tigril No. MA01.0038 OE No. 0.268.448 Description V-belt AVX13X1250 Remarks Universal Tigril No. MA01.0039 OE No. 0.212.269 Description V-belt AVX13X1425 Remarks Universal Tigril No. MA01.0040 OE No. 0.068.229 Description V-belt AVX13X1500 Remarks Tigril No. VO01.0066 OE No. 3.911.573 Description Multiribbed V-belt 8PK1535 Remarks Tigril No. DB03.0016 OE No. 1.278.342 Description Clutch master cylinder Remarks Tigril No. DB03.0001 OE No. 1.506.469 Description Repair kit, clutch cylinder Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 12
DAF Tigril No. DB03.0003 OE No. 1.506.468 Description Clutch servo, complete with sensor Remarks F 2100/2300/2500 Tigril No. DA03.0001 OE No. 0.659.807 Description Clutch servo Remarks 970.051.114.0 F 75/85/95, 85 CF Tigril No. DA03.0002 OE No. 1.443.530 Description Clutch servo Remarks 628275AM Tigril No. DB03.0002 OE No. 1.518.250 Description Clutch servo Remarks F 2900 Tigril No. DB03.0004 OE No. 1.518.252 Description Clutch servo Remarks Tigril No. DB03.0005 OE No. 1.505.139 Description Clutch servo Remarks Tigril No. DB03.0008 OE No. 1.506.456 Description Clutch servo Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 13
DAF Tigril No. DB03.0009 OE No. 1.518.249 Description Clutch servo Remarks Tigril No. MA03.0001 OE No. 1.506.465 Description Clutch servo Remarks Tigril No. MA03.0003 OE No. 1.518.255 Description Clutch servo Remarks Tigril No. MA03.0004 OE No. 1.518.243 Description Clutch servo Remarks Tigril No. MA03.0006 OE No. 1.518.251 Description Clutch servo Remarks CF 75, CF 85 /IV, XF 95/105 Tigril No. MA03.0008 OE No. 1.447.248 Description Clutch servo Remarks F 1000 Tigril No. RV03.0001 OE No. 1.518.244 Description Clutch servo Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 14
DAF Tigril No. RV03.0002 OE No. 1.518.254 Description Clutch servo Remarks Tigril No. SC03.0001 OE No. 1.504.842 Description Clutch servo Remarks Tigril No. SC03.0004 OE No. 1.519.337 Description Clutch servo Remarks Tigril No. SC03.0005 OE No. 1.506.466 Description Clutch servo Remarks Tigril No. SC03.0006 OE No. 1.506.467 Description Clutch servo Remarks Tigril No. VO03.0002 OE No. 1.504.843 Description Clutch servo Remarks Tigril No. VO03.0011 OE No. 1.504.845 Description Clutch servo Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 15
DAF Tigril No. DA03.0003 OE No. 832.865 Description Repair kit, clutch servo Remarks 971.002.003.2 Tigril No. DA03.0004 OE No. 1.347.695 Description Repair kit, clutch servo Remarks 475.010.002.2 Tigril No. DB03.0011 OE No. 1.519.290 Description Repair kit, clutch servo Remarks Tigril No. DB03.0012 OE No. 1.519.292 Description Repair kit, clutch servo Remarks Tigril No. DB14.0040 OE No. 1.505.077 Description Trailer control valve Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DB04.0009 OE No. 1.517.945 Description Shifting cylinder Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700 Tigril No. DB04.0017 OE No. 609.715 Description Switch, splitter gearbox Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 16
DAF 65/75/85 CF, XF 105, 95 XF, F 1300/1600/1700/1800/1900/2100/2300/2500/2800/3300/3600 Tigril No. DB04.0004 OE No. 386.930 Description Ball joint, gear shift linkage Remarks 75/85/95, 75/85 CF, 95 F Tigril No. DB04.0005 OE No. 1.249.088 Description Ball joint, gear shift linkage, upper Remarks 75/85/95, 75/85 CF, 95 XF Tigril No. DB04.0006 OE No. 1.249.129 Description Ball joint, gear shift linkage, lower Remarks F 75, 65/75/85 CF, CF 75 /IV, CF 85 /IV Tigril No. DB04.0013 OE No. 1.330.985 Description Ball head, gearshift linkage Remarks F 75, 65/75/85 CF, CF 75, CF 85 /IV Tigril No. DB04.0014 OE No. 1.330.986 Description Ball head, gearshift linkage Remarks F 75/85/95, F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700 Tigril No. DB04.0022 OE No. 692.183 Description Solenoid valve, shift cylinder Remarks Tigril No. DB14.0066 OE No. 1.508.080 Description 3/2 Directional control valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 17
DAF 75/85 CF, 95 XF, CF 75/85 Tigril No. MA04.0009 OE No. 1.297.004 Description Shifting valve Remarks 85 CF, 95 XF, CF 75/85, XF 95/105 Tigril No. MA04.0010 OE No. 1.300.662 Description Solenoid valve, shift cylinder Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900 Tigril No. DB14.0018 OE No. 0.262.233 Description 4/2-way valve Remarks Tigril No. DB04.0018 OE No. 1.518.090 Description 5/2-way valve Remarks F 2800/2900/3200, F 3300/3600, N 2800, F 65/75/85/95, 65/75/85 CF, 95 XF, LF 45/55 Tigril No. VO14.0024 OE No. 642.909 Description 3/2 directional control valve Remarks Tigril No. MA14.0029 OE No. 1.154.219S Description Shut-off valve Remarks 65/75/85 CF, 95 XF, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA04.0001 OE No. 1.330.025 Description Solenoid valve Remarks 472.172.626.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 18
DAF 95 XF, CF 75/85, XF 95/105 Tigril No. DA04.0002 OE No. 1.457.276 Description Solenoid valve Remarks F 65/75/85/95 Tigril No. DA04.0003 OE No. 1.457.275 Description Solenoid valve Remarks F 75/95, 75/85 CF, 95 XF, CF 75/85, XF 95 Tigril No. DA04.0004 OE No. 1.395.692 Description Solenoid valve Remarks F 75/95, 65/75/85 CF, 95 XF, CF 65/75, CF 85 /IV, XF 95/105 Tigril No. DA04.0005 OE No. 1.315.507 Description Solenoid valve Remarks 472.172.606.0 Tigril No. MA04.0008 OE No. 0.091.647 Description Solenoid valve Remarks Tigril No. VO04.0005 OE No. 1.402.863 Description Solenoid valve Remarks Tigril No. BP09.0091 OE No. 0.907.524 Description Plate, spring bracket Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 19
DAF Tigril No. SF10.0009 OE No. 1.384.274 Description Air spring with metal piston Remarks Tigril No. DB09.0033 OE No. 1.527.109 Description Air spring without piston with plate Remarks SB 2300/3000 Tigril No. MA10.0001 OE No. 0.659.561 Description Air bellow Remarks Tigril No. VO09.0014 OE No. 0.627.584 Description Air bellow Remarks F 2700 Tigril No. VO10.0001 OE No. 696.229 Description Air bellow Remarks 65 CF, 75/85 CF, 95 XF, CF 65/75/85 85, LF 55, XF 95/105 Tigril No. DA09.0001 OE No. 1.368.270 Description Triangular control arm Remarks Rear 75/85 CF, 95 XF, CF 75/85, XF 95, F 2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DA09.0002 OE No. 1.620.437 Description Triangular control arm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 20
DAF Tigril No. DB08.0012 OE No. 20.264.198 Description Track control arm Remarks F 2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DB09.0016 OE No. 691.703 Description Torsion link repair kit 85 mm Remarks F 2800/2900/3200, F 3300/3600, N 2800, F 95, 95 XF, CF 85 /IV, XF 95/105 Tigril No. DB09.0056 OE No. 693.778 Description Repair Kit, link Remarks DAF 95 Tigril No. MA09.0001 OE No. 689.749 Description Torsion link repair kit 85 mm Remarks F 2100/2300/2500/2700/2800/2900/3200/3300/3600, F 75/85/95, 65/75/85 CF, 95 XF Tigril No. VO09.0003 OE No. 696.321 Description Torsion link repair kit 95 mm Remarks Tigril No. DA16.0001 OE No. 1.505.053 Description Distance sensor, ECAS Remarks 441.050.010.0 F 75/85/95, 65/75/85 CF, 95 XF, LF 45/55, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA16.0002 OE No. 1.365.935 Description Distance sensor, ECAS Remarks 441.050.100.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 21
DAF F 2800/2900/3200, F 3300/3600, N 2800, F 95, Bus Tigril No. DB16.0007 OE No. 1.247.631 Description Distance sensor, ECAS Remarks Tigril No. DB16.0038 OE No. 1.524.843 Description Distance sensor, ECAS Remarks F 2800/2900/3200, F 3300/3600, N 2800, F 65/75/85/95, 75/85 CF, 95 XF, LF 55, CF 75 /I Tigril No. DB16.0048 OE No. 1.505.287 Description Distance sensor, ECAS Remarks F 2800/3300/3600 Tigril No. DB14.0055 OE No. 1.506.100 Description Level valve Remarks Tigril No. DB14.0057 OE No. 1.518.095 Description Air suspension valve Remarks Tigril No. MA14.0013 OE No. 1.325.337 Description Level valve Remarks XF 95, 95 XF, CF 65/75/85, 75/85 CF, F 1600/1800 Tigril No. MA14.0028 OE No. 1.505.081 Description Levelling valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 22
DAF Tigril No. SC14.0017 OE No. 1.504.925 Description Levelling valve Remarks 95 XF, 75/85 CF, CF 75/85, F 1600/1800 Tigril No. VO14.0028 OE No. 1.518.094 Description Levelling valve Remarks Tigril No. DB14.0037 OE No. 1.506.134 Description Solenoid Valve Remarks F 2800/2900/3200, F 3300/3600, N 2800, F 95, Bus Tigril No. DB14.0052 OE No. 1.506.152 Description Solenoid valve Remarks Tigril No. SC14.0016 OE No. 1.257.361 Description Solenoid valve, ABS Remarks F 75/85/95, 75/85 CF, 95 XF, LF 45 /IV, CF 75/85 /IV, XF 95/105 Tigril No. VO09.0026 OE No. 1.343.255 Description Solenoid valve Remarks Tigril No. VO09.0022 OE No. 1.528.269 Description Valve, air suspension Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 23
DAF 75/85 CF, XF 95, CF 65/75/85, L 55 Tigril No. DA08.0001 OE No. 683.499 Description King pin kit single Remarks Front Tigril No. BP09.0121 OE No. 1.359.884 Description Wear ring, wheel hub Remarks Tigril No. BP09.0122 OE No. 0.865.006 Description Wear ring, wheel hub Remarks Tigril No. RO09.0006 OE No. 1.488.353 Description Bolt equalizer 41 mm Remarks 75/85 CF, 95 XF, F 1700/1900/2100/2300/2500/2700/2800 Tigril No. BP24.0002 OE No. 144.922 Description Wheel nut M22 x 2 H-25 wrench size-32 mm Remarks 95 XF, 85 CF Tigril No. BP24.0006 OE No. 678.250 Description Wheel nut M20 x 2 H-20 wrench size-27 mm Remarks XF 95/105, CF 65/75/85/95, LF 55, 75/85 CF, 95 XF, F 2800/2900/3200/3300/3600, N 2800 Tigril No. DB24.0017 OE No. 0.620.652 Description Wheel nut M22 x 1.5 H-27 wrench size-32 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 24
DAF Tigril No. DB24.0019 OE No. 188.055 Description Wheel nut M18 x 1.5 H-18 wrench size-24 mm Remarks F 1600/2100/2200/2300/2800 Tigril No. DB24.0027 OE No. 325.235 Description Washer (retaining ring, wheel rim) 34 x 22.5 x 8 mm Remarks 65/75/85 CF, 95 XF, F 1900/2100/2300/2500/2700/2800/3200/3300/3600 Tigril No. DB24.0028 OE No. 0.260.261 Description Washer (retaining ring, wheel rim) 32 x 22.2 x 5.5 mm Remarks CF 85, F 2300/2500/2700/2800/2900/3200/3300/75/85/95, TB 2100 Tigril No. BP24.0008 OE No. 506.666 Description Safety pin Remarks F 2800/2900/3200/3300/3600, N 2800 Tigril No. DA11.0001 OE No. 609.866 Description Universal joint 48x116.50 mm Remarks Rear F 2300/2800/3300/3600 Tigril No. DA11.0002 OE No. 1.252.350 Description Universal joint 57x144 mm Remarks Rear F 75/85/95, 75/85 CF, 95 XF, CF 75 /IV, CF 85, XF 95/105 CF E6, XF E6 Tigril No. DA11.0009 OE No. 1.288.233 Description Universal joint 57x172 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 25
DAF F 2800/2900/3200, F 3300/3600, N 2800, F 75/85/95, Bus Tigril No. DB11.0005 OE No. 0264.354 Description Universal joint 52 x 133 mm Remarks 75/85/95, 95 XF, F 1900/3200/3300/3600 Tigril No. DB11.0007 OE No. 1.288.229 Description Universal joint 57 x 152 mm Remarks Tigril No. DB11.0016 OE No. 1.288.240 Description Universal joint 65x172 mm Remarks F 65, 65/75/85 CF, 95 XF, CF 65/75/85, XF 95 Tigril No. DA11.0003 OE No. 1.435.557 Description Propellor shaft mounting, bearing 65 mm Remarks Rear F 85/95, 85 CF, 95 XF, F 2800/2900/3200, F 3300/3600, N 2800 Tigril No. DA11.0004 OE No. 1.235.569 Description Propellor shaft mounting, bearing 70 mm Remarks Rear F 65/75/85/95, 65/75/85 CF, 95 XF, CF 75, F 2800/2900/3200, F 3300/3600, N 2800 Tigril No. DA11.0005 OE No. 1.298.157 Description Propellor shaft mounting, bearing 55 mm Remarks Rear 45/55, LF 45/55 Tigril No. DA11.0006 OE No. 1.404.560 Description Propellor shaft mounting, bearing 45 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 26
DAF CF 65, LF 45/55 Tigril No. DA11.0007 OE No. 1.408.525 Description Propellor shaft mounting, bearing 55 mm Remarks CF 65, LF 45/55 Tigril No. DA11.0008 OE No. 1.782.199 Description Propellor shaft mounting, bearing 60 mm Remarks 65 CF, 65/75 Tigril No. RV11.0001 OE No. 1.291.808 Description Propellor shaft mounting, bearing 55 mm Remarks Tigril No. RV11.0003 OE No. 1.700.326 Description Propellor shaft mounting, bearing 50mm Remarks Tigril No. BP13.0011 OE No. 1.962.289 Description Brake disc Remarks Tigril No. BP14.0002 OE No. 1.962.286 Description Brake disc Remarks 85 CF, 95 XF, CF 65/75/85, LF 45/55, XF 95/105 Tigril No. DA14.0001 OE No. 1.726.138 Description Brake disc with kit Remarks Front & Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 27
DAF Tigril No. DB12.0034 OE No. 1.962.312 Description Brake disc Remarks Tigril No. DB12.0035 OE No. 1.962.314 Description Brake disc Remarks Tigril No. DB12.0039 OE No. 1.962.312 Description Brake disc Remarks Tigril No. DB13.0049 OE No. 1.962.313 Description Brake disc Remarks Tigril No. DB13.0050 OE No. 1.962.315 Description Brake disc Remarks Tigril No. DB13.0051 OE No. 1.962.316 Description Brake disc Remarks Tigril No. DB14.0001 OE No. 1.962.322 Description Brake disc Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 28
DAF Tigril No. DB14.0004 OE No. 1.962.318 Description Brake disc Remarks Tigril No. DB14.0039 OE No. 1.962.322 Description Brake disc Remarks Tigril No. DB14.0050 OE No. 1.962.518 Description Brake disc Remarks Tigril No. IV14.0001 OE No. 1.962.300 Description Brake disc with ABS sensor Remarks Tigril No. MA12.0002 OE No. 1.962.305 Description Brake disc Remarks Tigril No. MA12.0004 OE No. 1.962.303 Description Brake disc Remarks Bova futura FHD/FLD Tigril No. SC13.0010 OE No. 1.525.365 Description Brake disc Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 29
DAF Tigril No. SC14.0001 OE No. 1.962.327 Description Brake disc Remarks Tigril No. SF13.0001 OE No. 1.962.330 Description Brake disc Remarks Tigril No. SF13.0002 OE No. 1.962.332 Description Brake disc Remarks Tigril No. SF13.0003 OE No. 1.962.331 Description Brake disc Remarks Tigril No. SF13.0005 OE No. 1.962.334 Description Brake disc Remarks Tigril No. DA14.0020 OE No. 1.393.560 Description Repair kit, brake disc Remarks Tigril No. VO14.0037 OE No. 1.962.341 Description Repair kit, brake disc Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 30
DAF 65/75/85 CF, LF 55, CF 65 /II /IV, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB12.0004 OE No. 1.617.343 Description Brake pad set with accessories Remarks Tigril No. DB12.0012 OE No. 1.962.434 Description Brake pad set with accessories Remarks Tigril No. DB12.0037 OE No. 1.501.994 Description Brake pad set with accessories Remarks Tigril No. DB13.0016 OE No. 1.962.433 Description Brake pad set Remarks Tigril No. DB14.0002 OE No. 1.529.337 Description Brake pad set with accessories Remarks Tigril No. DB14.0003 OE No. 1.962.595 Description Brake pad set with accessories Remarks 65/75/85 CF, LF 55, CF 65 /II /IV, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB14.0006 OE No. 1.617.343 Description Brake pad set with accessories Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 31
DAF Tigril No. MA14.0037 OE No. 1.962.594 Description Brake pad set with accessories Remarks Tigril No. SF14.0002 OE No. 1.962.437 Description Brake pad set with accessories Remarks F 65/75/85/95, 65/75/85 CF, 95 XF, XF 95 Tigril No. DA12.0001 OE No. 284.620 Description Brake drum Remarks 420 x 160 Front F 75/85/95, 75/85 CF, 95 XF Tigril No. DA13.0001 OE No. 365.579 Description Brake drum Remarks 420 x 200 Rear Tigril No. RO13.0007 OE No. 1.488.338 Description Brake drum Remarks Tigril No. BP13.0002 OE No. 702.971 Description Brake lining with rivets, std Remarks Tigril No. BP13.0003 OE No. 303.910 Description Brake lining with rivets, std Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 32
DAF Tigril No. BP13.0048 OE No. 702.971 Description Brake lining with rivets, 18 mm Remarks Tigril No. BP13.0049 OE No. 702.971 Description Brake lining with rivets, 19 mm Remarks Tigril No. BP13.0050 OE No. 702.971 Description Brake lining with rivets, 20 mm Remarks 65/75/85/95, 65/75/85 CF, 85/95 CF, 95 XF, F 2300/2700/2900 Tigril No. DA13.0002 OE No. 683.278 Description Brake lining with rivets, std Remarks 19063 & 19064 Rear Tigril No. DB12.0006 OE No. 4.731.303 Description Slack adjuster automatic Remarks Tigril No. DB12.0014 OE No. 4.731.303S Description Slack adjuster AT with sensor hole Remarks Tigril No. DB13.0008 OE No. 4.731.113 Description Slack adjuster automatic Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 33
DAF Tigril No. DB13.0009 OE No. 4731.121 Description Slack adjuster automatic Remarks XF 95/105, 95 XF, CF 85, 85 CF Tigril No. BP14.0001 OE No. 1.602.394 Description Bush, brake camshaft Remarks Tigril No. BP12.0001 OE No. 1.517.956 Description Brake chamber 24 M16 x 1.5 Remarks F2500, LF 45/55 Tigril No. BP12.0002 OE No. 834.483 Description Brake cylinder 24 Remarks Tigril No. BP12.0003 OE No. 1.517.956 Description Brake cylinder 24 M22 x 1.5 Remarks L 45/55 Tigril No. BP13.0020 OE No. 705.707 Description Brake cylinder 30 Remarks Tigril No. DB12.0031 OE No. 1.505.026 Description Brake cylinder 20 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 34
DAF Tigril No. BP13.0004 OE No. 1.325.351 Description Spring brake cylinder 30/30 Remarks Tigril No. DA13.0003 OE No. 1.519.443 Description Spring brake cylinder 20/24 Remarks 925.420.005.0 925.490.925.0 Rear Tigril No. DB12.0018 OE No. 1.518.146 Description Spring brake cylinder 24/24 Remarks Tigril No. DB12.0019 OE No. 1.518.145 Description Spring brake cylinder 24/24 Remarks Tigril No. DB12.0020 OE No. 1.518.144 Description Spring brake cylinder 20/30 Remarks Tigril No. DB12.0021 OE No. 1.518.148 Description Spring brake cylinder 24X24 Remarks Tigril No. DB12.0022 OE No. 1.519.131 Description Spring brake cylinder 16/24 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 35
DAF Tigril No. DB12.0023 OE No. 1.506.681 Description Spring brake cylinder 20/24 IBV Remarks Tigril No. DB12.0027 OE No. 1.519.165 Description Spring brake cylinder 30/30 Remarks Tigril No. DB12.0028 OE No. 1.519.378 Description Spring brake cylinder 24/24 Remarks Tigril No. DB12.0029 OE No. 1.518.146 Description Spring brake cylinder 24/24, full thread push rod Remarks Tigril No. DB13.0040 OE No. 1.519.442 Description Spring brake cylinder 20/24 right Remarks Tigril No. DB13.0042 OE No. 1.505.448 Description Spring brake cylinder 16/24 Remarks Tigril No. DB13.0043 OE No. 1.518.153 Description Spring brake cylinder 16/24 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 36
DAF 95, LF 45/55, F 2100/2300/2500/2900/3200/3300/3600 Tigril No. MA13.0011 OE No. 1.506.372 Description Spring brake cylinder 24X24 Remarks Tigril No. MA13.0012 OE No. 1.519.158 Description Spring brake cylinder, left 24/24 (push rod full thread) Remarks Tigril No. SF12.0001 OE No. 0.907.655 Description Spring brake cylinder 16/24 Remarks Tigril No. DB14.0071 OE No. 1.506.410 Description Air dryer, with heating unit Remarks 95 XF, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0017 OE No. 1.443.153 Description Air dryer complete, with safety valve Remarks ZB4578 95 XF, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0018 OE No. 1.607.424 Description Air dryer, complete with valve Remarks K000390 / LA8130 CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0005 OE No. 1.681.570 Description Air dryer Remarks ZB4706 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 37
DAF CF 75 /IV, CF 85 /IV, XF 95/106 Tigril No. DA14.0006 OE No. 1.681.571 Description Air dryer Remarks ZB4708 Tigril No. DB14.0075 OE No. 1.517.978 Description Air dryer Remarks Tigril No. DB14.0076 OE No. 1.517.975 Description Air dryer Remarks Tigril No. DB14.0078 OE No. 1.517.973 Description Air dryer Remarks Tigril No. DB14.0079 OE No. 1.505.230 Description Air dryer Remarks Tigril No. DB14.0116 OE No. 1.517.966 Description Air dryer Remarks Tigril No. IV14.0003 OE No. 1.517.964 Description Air dryer Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 38
DAF Tigril No. IV14.0006 OE No. 1.517.963 Description Air dryer Remarks 95 Tigril No. MA14.0011 OE No. 1.505.967 Description Air dryer Remarks Tigril No. MA14.0012 OE No. 1.517.967 Description Air dryer Remarks Tigril No. MA14.0030 OE No. 1.517.969 Description Air dryer Remarks Tigril No. SC14.0005 OE No. 1.505.965 Description Air dryer Remarks Tigril No. VO14.0033 OE No. 882.965 Description Air dryer Remarks F 45/55, F 65/75/85/95, 65/75/85 CF, 95 XF, XF 95 Tigril No. DB14.0072 OE No. 699.387 Description Air dryer cartridge Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 39
DAF 95, F 2500 Tigril No. DB14.0073 OE No. 1.504.900 Description Air dryer cartridge Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900/3200 Tigril No. DB14.0117 OE No. 1.506.635 Description Air dryer cartridge Remarks Tigril No. SC14.0004 OE No. 1.527.759 Description Air dryer cartridge Remarks F 95 Tigril No. DA14.0014 OE No. 187.917 Description Repair kit, air dryer valve Remarks LA6210 Tigril No. DB14.0090 OE No. 1.519.201 Description Repair kit, air dryer Remarks Tigril No. DB14.0118 OE No. 1.518.670 Description Repair kit, air dryer Remarks Tigril No. VO14.0035 OE No. 1.505.978 Description Repair kit, air dryer Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 40
DAF F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900 Tigril No. DB14.0080 OE No. 285.768 Description Pressure regulator Remarks F 2800/2900/3200, F 3300/3600, N 2800, Bus Tigril No. DB14.0081 OE No. 1.506.504 Description Pressure regulator, open port M12x1.5-6H Remarks Tigril No. DB14.0082 OE No. 1.505.157 Description Pressure regulator, Max Operating pressure 15.0 bar Remarks F 2800/2900/3200, F 3300/3600, N 2800, Bus Tigril No. DB14.0083 OE No. 1.518.284 Description Pressure regulator Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/ 2300/2500/2700/ 2800/2900 Tigril No. DB14.0120 OE No. 698.276 Description Repair kit, pressure regulator Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900 Tigril No. DB14.0127 OE No. 1.519.340 Description Repair kit, pressure regulator Remarks F 95, 65/75/85 CF, 95 XF, LF 45/55, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105, Bus Tigril No. IV14.0004 OE No. 1.504.939 Description Silencer, compressed-air system Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 41
DAF F 65/75/85/95, 65/75/85 CF, 95 XF, CF 65/75/85, XF 95/105 Tigril No. MA14.0020 OE No. 1.193.486 Description Silencer, compressed-air system Remarks F 95, 65/75/85 CF, 95 XF, LF 45/55, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105, Bus Tigril No. SC14.0010 OE No. 1.504.937 Description Silencer, compressed-air system Remarks F 2800/2900/3200/3300/3600, N 2800, F 75/85/95, 65/75/85 CF, 95 XF, Bus Tigril No. DB04.0023 OE No. 1.506.514 Description 2-way valve Remarks Tigril No. MA14.0022 OE No. 1.517.988 Description 2-way valve Remarks Tigril No. DB01.0096 OE No. 1.505.078 Description 3/2 directional control valve Remarks Tigril No. DB14.0119 OE No. 1.506.104 Description 3/2 Directional control valve Remarks Tigril No. DB14.0124 OE No. 1.304.639 Description 3/2 Directional control valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 42
DAF Tigril No. VO01.0048 OE No. 1.518.851 Description 3/2 directional control valve Remarks Tigril No. DB14.0027 OE No. 1.505.128 Description 4-circuit protection valve Remarks Tigril No. DB14.0031 OE No. 1.518.181 Description 4-circuit protection valve Remarks Tigril No. DB14.0041 OE No. 1.518.178 Description 4-circuit protection valve 10 bar Remarks Tigril No. DB14.0042 OE No. 1.518.178 Description 4-circuit protection valve 20 bar Remarks F 65/75, 65/75 CF, F 1300/1600/1700/1800/1900/2100/2300/2500/2700 Tigril No. DB14.0062 OE No. 1.506.418 Description 4-circuit protection valve Remarks Tigril No. DB14.0111 OE No. 1.518.182 Description 4-circuit protection valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 43
DAF Tigril No. DB14.0139 OE No. 1.505.128 Description 4-circuit protection valve, normal sensor Remarks Tigril No. MA14.0018 OE No. 1.524.857 Description 4-circuit protection valve Remarks Tigril No. MA14.0019 OE No. 1.518.183 Description 4-circuit protection valve Remarks Tigril No. MA14.0025 OE No. 1.518.174 Description 4-circuit protection valve Remarks Tigril No. DB13.0030 OE No. 102.941 Description Adaptor valve Remarks Tigril No. VO14.0022 OE No. 1.518.277 Description Adaptor valve, compressed air system Remarks F 45/55, F 95, F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700 Tigril No. DB14.0093 OE No. 1.238.508 Description Air line filter Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 44
DAF MB 200 Tigril No. BP14.0005 OE No. 1.325.325 Description Automatic load sensing valve Remarks Tigril No. DA14.0002 OE No. 1.518.127 Description Automatic load sensing valve Remarks 475.712.004.0 Tigril No. DA14.0004 OE No. 1.506.232 Description Load sensing relay emergency valve Remarks 475.715.500.0 Bus Tigril No. DA14.0007 OE No. 1.325.324 Description Automatic load sensing valve Remarks 475.712.000.0 K037590 Tigril No. DB14.0014 OE No. 1.518.124 Description Automatic load sensing valve Remarks Tigril No. DB14.0043 OE No. 1.518.121 Description Automatic load sensing valve Remarks Tigril No. VO14.0011 OE No. 1.518.995 Description Load sensing valve automatic Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 45
DAF Tigril No. DB14.0092 OE No. 1.518.960 Description Brake power regulator Remarks Tigril No. MA14.0002 OE No. 700.125 Description Brake power regulator Remarks CF 75/85 IV, XF 95/105 Tigril No. DA14.0010 OE No. 1.455.027 Description Brake valve Remarks 480.001.500.0 F 65/75/85/95, 65/75/85 CF, 95 XF Tigril No. DA14.0016 OE No. 1.337.184 Description Brake valve Remarks MB4694 Tigril No. DB14.0077 OE No. 1.518.130 Description Brake valve Remarks Tigril No. MA14.0036 OE No. 1.518.233 Description Brake Valve, parking brake Remarks Tigril No. VO14.0040 OE No. 1.506.783 Description Brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 46
DAF Tigril No. VO14.0026 OE No. 1.517.989 Description Double check valve Remarks F 320/800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900 Tigril No. DA14.0008 OE No. 503.366 Description Foot brake valve Remarks 461.307.479.0 Tigril No. DA14.0011 OE No. 1.506.077 Description Foot brake valve Remarks 461.106.100.0 Tigril No. DB14.0021 OE No. 1.506.093 Description Foot brake valve Remarks F 2500 Tigril No. DB14.0028 OE No. 1.518.060 Description Foot brake valve Remarks Tigril No. DB14.0033 OE No. 1.518.073 Description Foot brake valve Remarks Tigril No. DB14.0038 OE No. 1.518.609 Description Foot brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 47
DAF Tigril No. DB14.0047 OE No. 1.518.099 Description Foot brake valve Remarks Tigril No. DB14.0051 OE No. 1.518.070 Description Foot brake valve Remarks Tigril No. DB14.0064 OE No. 1.505.037 Description Foot brake valve Remarks Tigril No. DB14.0088 OE No. 1.518.067 Description Foot brake valve Remarks Tigril No. DB14.0100 OE No. 1.518.065 Description Foot brake valve Remarks Tigril No. DB14.0105 OE No. 1.518.057 Description Foot brake valve Remarks Tigril No. DB14.0112 OE No. 1.517.495 Description Foot brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 48
DAF Tigril No. RV14.0001 OE No. 1.518.075 Description Foot brake valve Remarks Tigril No. SC14.0022 OE No. 1.504.971 Description Foot brake valve Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900 Tigril No. DB14.0017 OE No. 0.374.642 Description Hand brake valve Remarks Tigril No. DB14.0019 OE No. 1.518.214 Description Hand brake valve Remarks Tigril No. DB14.0030 OE No. 1.518.235 Description Hand brake valve Remarks Tigril No. DB14.0032 OE No. 1.518.217 Description Hand brake valve Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900/3200/3300/3600 Tigril No. DB14.0036 OE No. 1.518.812 Description Hand brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 49
DAF Tigril No. DB14.0048 OE No. 1.518.221 Description Hand brake valve Remarks Tigril No. DB14.0049 OE No. 1.519.266 Description Hand brake valve Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/F 2800/2900/3200/3300 Tigril No. DB14.0056 OE No. 1.519.239 Description Hand brake valve Remarks Tigril No. DB14.0060 OE No. 1.518.229 Description Hand brake valve Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900 Tigril No. DB14.0067 OE No. 0.176.628 Description Hand brake valve Remarks Tigril No. MA14.0009 OE No. 1.518.237 Description Hand brake valve Remarks Tigril No. MA14.0039 OE No. 1.518.236 Description Hand brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 50
DAF Tigril No. SC14.0015 OE No. 1.523.989 Description Hand brake valve Remarks Tigril No. VO14.0031 OE No. 1.505.340 Description Hand brake valve Remarks Tigril No. BP14.0003 OE No. 1.325.336 Description Level valve Remarks Tigril No. VO14.0010 OE No. 1.506.114 Description Level valve Remarks Tigril No. SC14.0014 OE No. 867.872 Description Lift axle control valve Remarks Tigril No. DB14.0046 OE No. 1.505.992 Description Overflow valve Remarks Tigril No. DB14.0138 OE No. 0.110.444 Description Overflow valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 51
DAF Bus Tigril No. MA14.0021 OE No. 1.505.994 Description Overflow valve Remarks F 2500 Tigril No. VO14.0027 OE No. 584.333 Description Overflow valve Remarks Tigril No. DB14.0025 OE No. 1.518.116 Description Pressure limiting valve Remarks Tigril No. DB14.0045 OE No. 1.505.095 Description Pressure limiting valve Remarks Tigril No. DB14.0069 OE No. 1.517.993 Description Pressure limiting valve Remarks Tigril No. IV14.0005 OE No. 1.505.097 Description Pressure limiting valve Remarks Tigril No. MA14.0008 OE No. 1.505.392 Description Pressure limiting valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 52
DAF Tigril No. MA14.0033 OE No. 1.505.094 Description Pressure limiting valve Remarks Tigril No. MA14.0034 OE No. 1.518.115 Description Pressure limiting valve Remarks Tigril No. MA14.0035 OE No. 1.518.113 Description Pressure limiting valve Remarks Tigril No. SC14.0019 OE No. 1.506.190 Description Pressure limiting valve Remarks Tigril No. VO14.0034 OE No. 1.524.015 Description Pressure limiting valve Remarks Tigril No. IV14.0007 OE No. 1.518.279 Description Pressure control valve Remarks F 2800/2900/3200/3300/3600, N 2800, Bus Tigril No. MA14.0031 OE No. 1.506.490 Description Pressure regulator valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 53
DAF Tigril No. MA14.0032 OE No. 1.503.133 Description Pressure regulator valve Remarks F 2800/2900/3200/3300/3600, N 2800, F 95, 85 CF, CF 65/75, Bus Tigril No. DB14.0101 OE No. 711.960 Description Quick release valve Remarks Tigril No. RV14.0005 OE No. 1.505.155 Description Quick release valve 12 bar Remarks Tigril No. RV14.0006 OE No. 1.504.911 Description Quick release valve 12 bar Remarks F 65/75/85/95, 65/75/85 CF, 95 XF, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DA14.0009 OE No. 1.302.104 Description Relay valve Remarks 973.011.106.0 Tigril No. DB14.0026 OE No. 1.315.816 Description Relay valve Remarks Tigril No. DB14.0029 OE No. 522.545 Description Relay valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 54
DAF CF 85 Tigril No. DB14.0054 OE No. 1.518.267 Description Relay valve Remarks Tigril No. DB14.0061 OE No. 1.518.271 Description Relay valve Remarks Tigril No. DB14.0068 OE No. 1.505.154 Description Relay valve Remarks Tigril No. DB14.0087 OE No. 1.505.410 Description Relay valve Remarks F 65/75/85/95, 65/75/85 CF, 95 XF, CF 75/85, XF 95 Tigril No. DB14.0102 OE No. 1.506.488 Description Relay valve Remarks Tigril No. DB14.0107 OE No. 1.506.485 Description Relay valve Remarks F 75/85/95, 75/85 CF, 95 XF, CF 85, XF 95 Tigril No. DB14.0108 OE No. 1.525.397 Description Relay valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 55
DAF F 65 Tigril No. MA14.0006 OE No. 1.325.332 Description Relay valve Remarks F 2800/2900/3200, F 3300/3600, N 2800, F 95, 85 CF, CF 65/75 Tigril No. MA14.0007 OE No. 1.505.150 Description Relay valve Remarks F 65/75/85, 65/75/85 CF, 95 XF Tigril No. MA14.0023 OE No. 1.504.965 Description Relay valve Remarks Tigril No. VO14.0013 OE No. 1.518.270 Description Relay valve, overload protection Remarks F 65/75/85/95, 85 CF, 95 XF Tigril No. VO14.0015 OE No. 1.238.501 Description Relay valve Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700/2800/2900/3200 Tigril No. DB14.0131 OE No. 1.194.016 Description Non return valve Remarks LF 45/55 Tigril No. DB14.0015 OE No. 1.229.423 Description Shut off valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 56
DAF Tigril No. DB14.0022 OE No. 1.327.108 Description Solenoid valve Remarks Tigril No. DB14.0023 OE No. 1.639.096 Description Solenoid valve Remarks Tigril No. DB14.0024 OE No. 1.505.087 Description Solenoid valve Remarks F 65/75/85/95, 65/75/85 CF, 95 XF, LF 55, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB14.0034 OE No. 1.506.180 Description Solenoid valve, ECAS Remarks F 75/95, 65/75/85 CF, 95 XF, LF 45/55, CF 65, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB14.0065 OE No. 1.505.210 Description Solenoid valve, ABS Remarks Tigril No. DB14.0085 OE No. 1.518.101 Description Solenoid valve Remarks F 75/85/95, 75/85 CF, 95 XF, LF 55, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB14.0097 OE No. 1.305.452 Description Solenoid valve, ECAS Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 57
DAF F 95 Tigril No. DB14.0104 OE No. 527.487 Description Solenoid valve, ECAS Remarks CF E4/E5/E6/F7, LF E4/E5/E6, XF E4/E5/E6/F7 Tigril No. DB14.0106 OE No. 1.385.440 Description Solenoid valve Remarks 95 XF Tigril No. MA14.0010 OE No. 1.304.587 Description Solenoid valve Remarks Tigril No. MA14.0038 OE No. 1.518.898 Description Solenoid valve Remarks Tigril No. RV14.0004 OE No. 1.506.449 Description Trailer release valve Remarks Tigril No. SC14.0013 OE No. 0.867.882 Description Trailer release valve Remarks Bus Tigril No. DA14.0003 OE No. 1.325.335 Description Trailer control valve Remarks 971.002.152.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 58
DAF Tigril No. DB14.0010 OE No. 1.518.263 Description Trailer control valve Remarks Tigril No. DB14.0012 OE No. 1.506.483 Description Trailer control valve Remarks 75/85 CF Tigril No. MA14.0003 OE No. 1.601.034 Description Trailer control valve Remarks Tigril No. MA14.0014 OE No. 1.506.643 Description Trailer control valve Remarks Tigril No. SC14.0006 OE No. 1.504.970 Description Trailer control valve Remarks F 2100/2300/2500/2800/2900/3200/3300/3600, F 95 Tigril No. SC14.0012 OE No. 1.506.636 Description Trailer control valve Remarks Tigril No. RV14.0003 OE No. 1.664.345 Description Trailer brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 59
DAF F 2800/2900/3200/3300/3600, N 2800, 75/85 CF, 95 XF, CF 65, CF 75 /IV, CF 85 /IV, X Tigril No. MA14.0026 OE No. 1.504.917 Description Water drain valve Remarks Tigril No. DB14.0123 OE No. 1.519.548 Description Repair kit, 4-circuit-protection valve Remarks F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900 Tigril No. DB14.0122 OE No. 0.691.051 Description Repair kit, brake power regulator Remarks Tigril No. RV14.0008 OE No. 1.518.977 Description Repair kit, brake power regulator Remarks Tigril No. DB14.0128 OE No. 689.405 Description Repair kit, brake valve Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 2800/2900 Tigril No. DB14.0053 OE No. 112.305 Description Repair kit, foot brake valve Remarks F 2800/2900/3200, F 3300/3600, N 2800, Bus Tigril No. DB14.0059 OE No. 0.697.422 Description Repair kit, foot brake valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 60
DAF F 2800/2900/3200/3300/3600, N 2800, F 65/75/85/95, 75/85 CF, 95 XF Tigril No. VO14.0036 OE No. 0.513.798 Description Repair kit, hand brake valve Remarks F 65/75/85/95, 65/75/85 CF, 95 XF, XF 95 Tigril No. DA14.0015 OE No. 1.337.535 Description Repair kit, relay valve Remarks F 75/85/95, 75/85 CF, 95 XF, CF 75 /IV, CF 85 /IV, XF 95/105 Tigril No. DB14.0020 OE No. 802.144 Description Repair kit, relay valve Remarks Tigril No. DA14.0012 OE No. 1.506.474 Description Repair kit, trailer control valve Remarks 971.002.004.2 F 65/75/85/95, 65/75/85 CF, 95 XF Tigril No. DA14.0013 OE No. 1.337.535 Description Repair kit, trailer control valve Remarks 973.009.001.2 F 95, F 800/1000/1100/1300/1600/1700/1800/1900/2100/2300/2500/2700/2800/2900/3200 Tigril No. DB14.0084 OE No. 609.986 Description Repair kit, trailer control valve Remarks Tigril No. DB14.0095 OE No. 1.519.330 Description Repair kit, trailer control valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 61
DAF Tigril No. DB14.0126 OE No. 692.465 Description Repair kit, trailer control valve Remarks Tigril No. RV14.0007 OE No. 1.518.974 Description Repair kit, load sensitive valve Remarks F 2800/2900/3200, F 3300/3600, N 2800, Bus Tigril No. DB01.0069 OE No. 1.505.074 Description 3/2 Directional control valve Remarks Tigril No. DB14.0035 OE No. 1.132.041 Description Three way valve Remarks F 2800/2900/3200/3300/3600, N 2800, Bus Tigril No. IV01.0007 OE No. 1.505.073 Description 3/2 directional control valve Remarks F 800/1000/1100, F 1300/1600/1700, F 1800/1900/2100, F 2300/2500/2700, F 75/85/95 Tigril No. DA14.0019 OE No. 1.518.724 Description ABS sensor with bush and grease, 410 mm Remarks 441.032.807.0 441.032.921.2 441.032.960.2 CF 75 IV, XF Euro 6, CF Euro 6 Tigril No. DA14.0021 OE No. 1.862.602 Description ABS sensor Remarks 441.035.144.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 62
