Spare Parts For Commercial Vehicles

Spare Parts Catalogue for Commercial Vehicles Version 01/2024-25 Introduction Page II Basic information Page III Product Group Page IV Catalogue Information Page VI BPW Page 1 Index I (Tigril No - OE No) Page 43 Index II (OE No - Tigril No) Page 49

BPW Tigril No. DB14.0066 OE No. 02.431.12.80.8 Description 3/2 Directional control valve Remarks 3XL Tigril No. BP09.0029 OE No. 02.101.40.62.5 Description Leaf spring 100 x 15 x 1250 Remarks 100 x 15 x 1250 Rear 3XL Tigril No. BP09.0030 OE No. 02.101.40.62.5 Description Leaf spring 100 x 14 x 1250 Remarks 100 x 14 x 1250 Rear 3XL Tigril No. BP09.0033 OE No. 02.101.40.62.6 Description Leaf spring 100 x 14 x 1250 Remarks 100 x 14 x 1250 Rear 3XL Tigril No. BP09.0041 OE No. 02.101.40.62.5 Description Leaf spring 100 x 12 x 1245 Remarks 100x12x1245 Rear VB, VBT Tigril No. BP09.0045 OE No. 05.082.06.01.0 Description Leaf spring 16 T Thickness:12mm, Weight:102.6KG (14 leaves) Remarks Thickness:12mm, Weight:102.6KG (14 leaves) VB, VBT Tigril No. BP09.0046 OE No. 05.082.06.01.0 Description Leaf spring 16 T Thickness:14mm, Weight:120KG (14 leaves) Remarks Thickness:14mm, Weight:120KG (14 leaves) OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 1

BPW 3XL Tigril No. BP09.0071 OE No. Description Leaf spring 1040 x 14 x 100 Plate-4, 3 axle Remarks 1040X14X100 Rear Plate-4 3XL Tigril No. BP09.0072 OE No. Description Leaf spring 990 x 14 x 100 Plate-5, 3 axle Remarks 990X14X100 Rear Plate-5 3XL Tigril No. BP09.0073 OE No. Description Leaf spring 915 x 14 x 100 Plate-6, 3 axle Remarks 915X14X100 Rear Plate-6 3XL Tigril No. BP09.0074 OE No. Description Leaf spring 820 x 14 x 100 Plate-7, 3 axle Remarks 820X14X100 Rear Plate-7 3XL Tigril No. BP09.0075 OE No. Description Leaf spring 750 x 14 x 100 Plate-8, 3 axle Remarks 750X14X100 Rear Plate-8 3XL Tigril No. BP09.0076 OE No. Description Leaf spring 672 x 14 x 100 Plate-9, 3 axle Remarks 672X14X100 Rear Plate-9 3XL Tigril No. BP09.0077 OE No. Description Leaf spring 565 x 14 x 100 Plate-10, 3 axle Remarks 565X14X100 Rear Plate-10 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 2

BPW 3XL Tigril No. BP09.0078 OE No. Description Leaf spring 525 x 14 x 100 Plate-11, 3 axle Remarks 525X14X100 Rear Plate-11 3XL Tigril No. BP09.0079 OE No. Description Leaf spring 450 x 14 x 100 Plate-12, 3 axle Remarks 450X14X100 Rear Plate-12 3XL Tigril No. BP09.0080 OE No. Description Leaf spring 382 x 14 x 100 Plate-13, 3 axle Remarks 382X14X100 Rear Plate-13 3XL Tigril No. BP09.0081 OE No. Description Leaf spring 300 x 14 x 100 Plate-14, 3 axle Remarks 300X14X100 Rear Plate-14 Tigril No. BP09.0142 OE No. PS1500.06.01 Description Leaf spring, air suspension Remarks W/BW/GW suspension Tigril No. BP09.0017 OE No. 03.140.16.01.0 Description Spring cushion for leaf spring 12-20 T axle Remarks Rear W Series Tandem axle suspension Tigril No. BP09.0054 OE No. 03.140.14.01.0 Description Spring cushion for leaf spring 8-12 ton axle Remarks H : 151 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 3

BPW W/BW/GW suspension Tigril No. BP09.0013 OE No. 03.112.99.04.0 Description Bush, leaf spring (suspension) brass 14-16 T Remarks Rear W 8-12 T Tigril No. BP09.0019 OE No. 03.112.99.02.0 Description Bush, leaf spring (suspension) brass 8-12 T Remarks Rear BPW Tigril No. BP09.0059 OE No. 03.224.19.03.1 Description Mounting, leaf spring Remarks HIZW 2/16000 Tigril No. BP09.0035 OE No. 03.138.42.02.4 Description Spring clamp with nut Remarks M24/192 x 413 Rear HIZW 2/16000 Tigril No. BP09.0036 OE No. 03.138.61.17.0 Description Spring clamp with nut Remarks M36/289 x 640 Rear Tigril No. BP09.0083 OE No. Description Spring clamp with nut 24X490 Remarks 24X490 Tigril No. BP09.0085 OE No. Description Spring clamp with nut 24X350 Remarks 24X350 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 4

BPW Tigril No. BP09.0042 OE No. 03.221.89.02.0 Description Bracket Remarks Rear Tigril No. BP09.0065 OE No. Description Spring clamp bracket upper doll Remarks Tigril No. BP09.0066 OE No. Description Spring clamp bracket lower doll Remarks Tigril No. BP09.0092 OE No. 05.032.22.10.0 Description Spring bracket Remarks Tigril No. BP09.0093 OE No. 05.032.22.09.0 Description Spring bracket Remarks W 12-20 t Tigril No. BP09.0131 OE No. 03.310.39.02.0 Description Washer, spring bracket Remarks Tigril No. BP09.0132 OE No. 03.264.19.03.0 Description Nut, spring bracket Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 5

BPW Tigril No. BP09.0133 OE No. 03.264.19.02.0 Description Nut, spring bracket Remarks BPW Tigril No. BP09.0090 OE No. 03.164.35.02.0 Description Plate, spring bracket Remarks BPW Tigril No. BP09.0091 OE No. 03.281.44.25.0 Description Plate, spring bracket Remarks BPW O, SL, AL Tigril No. BP09.0094 OE No. 03.164.35.01.0 Description Plate, spring bracket Remarks Tigril No. BP09.0095 OE No. 03.164.35.03.0 Description Plate, spring bracket Remarks BPW Tigril No. BP09.0096 OE No. 03.281.54.18.0 Description Plate, spring bracket Remarks Tigril No. BP09.0138 OE No. 02.5220.85.26 Description Nut M36 x 3.5 H-29 wrench size-55 mm, 10.9 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 6

BPW Tigril No. BP09.0139 OE No. 03.340.16.04.0 Description Bolt 36 x 185 mm Remarks Tigril No. BP09.0140 OE No. 03.340.16.05.0 Description Bolt 36 x 215 mm Remarks Tigril No. BP09.0141 OE No. 03.340.16.06.0 Description Bolt 36 x 235 mm Remarks O/SL/AL Tigril No. BP10.0001 OE No. 05.429.41.36.1 Description Air spring with metal piston Remarks 3881-01C Front & Rear 30 K Tigril No. BP10.0003 OE No. 05.429.40.93.1 Description Air spring with metal piston Remarks Front & Rear 1 DK 21 K-1, 3940 C O/SL/AL Tigril No. BP10.0005 OE No. 05.429.40.28.1 Description Air spring with metal piston Remarks Front & Rear 3941 C O/SL/AL Tigril No. BP10.0002 OE No. 05.429.40.01.0 Description Air spring without piston with plate Remarks Front & Rear 881 MB, 3881 P OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 7

BPW 30 K O/SL/AL Tigril No. BP10.0004 OE No. 05.429.40.91.0 Description Air spring without piston with plate Remarks Front & Rear 940 MB, 3940 P O/SL/AL Tigril No. BP10.0006 OE No. 05.429.40.03.0 Description Air spring without piston with plate Remarks Front & Rear 941 MB, 3941-P Tigril No. DB10.0002 OE No. 02.200.24.10.0 Description Air bellow Remarks Tigril No. VO10.0001 OE No. 02.200.24.40.0 Description Air bellow Remarks Tigril No. DB14.0055 OE No. 02.431.12.80.0 Description Level valve Remarks Tigril No. MA14.0013 OE No. 02.431.09.02.0 Description Level valve Remarks HS../HZ.. Series Tigril No. BP09.0020 OE No. 03.272.48.46.0 Description Wheel hub 10-12 T Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 8

BPW HS../HZ.. Series Tigril No. BP09.0021 OE No. 03.272.62.27.0 Description Wheel hub 13-14 T Remarks Rear HS…/ HZ... Tigril No. BP09.0022 OE No. 03.272.80.14.0 Description Wheel hub 16-18 T 10 hole Remarks Rear Tigril No. BP09.0032 OE No. 03.272.80.86.0 Description Wheel hub 16 T HD Remarks Rear HS../HZ.. SH../SKHS.. ECO-MAXX Tigril No. BP09.0043 OE No. 03.272.30.97.0 Description Wheel hub 6.5-9 T Remarks Rear EHZ Series Tigril No. BP09.0044 OE No. 03.272.48.32.0 Description Wheel hub Remarks Rear H.. 16-18 T Tigril No. BP09.0027 OE No. 03.212.26.01.0 Description Hub cap for wheel hub M 155x3, outer thread Remarks M155x3 H ( SN 42.. ), K ( SN 36.. ), SH ( SB 4345 ), SKH ( SB 3745 ), H..LL ( SN 42.. ) Tigril No. BP09.0048 OE No. 03.212.25.31.0 Description Hub cap, 8-9-10-12 T, inner thread Remarks M136x2.5 SW110/800Nm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 9

BPW Tigril No. BP09.0049 OE No. 03.212.27.01.0 Description Hub cap, 14-20 T, outer thread Remarks M230x3 SW120 H../K.., NR.. Tigril No. BP09.0050 OE No. 03.212.25.02.0 Description Hub cap, 13-14 T, outer thread Remarks M135x3 SW120/700Nm H ( SN 42.. ), (M)..L ( SN 42.. ) Series Tigril No. BP09.0051 OE No. 03.212.26.14.0 Description Hub cap, 13-14 T, inner thread Remarks M150x2 SW120/800Nm H../R.., KH../KR.., NH../NR.. Tigril No. BP09.0052 OE No. 03.212.24.07.0 Description Hub cap, 10-12 T, outer thread Remarks M125x2 SW110/500Nm H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX Tigril No. BP09.0053 OE No. 03.212.25.08.0 Description Hub cap, 10-12 T, inner thread Remarks M135x2 SW110/800Nm H.., R.. KH.., KR.. NH.., NR.. SH.., SKH.. ECO, ECO-MAXX 6,5-9,0 t Tigril No. BP09.0099 OE No. 03.188.03.06.0 Description Lock ring Remarks KH.. ECO-Plus, SKH.. ECO-Plus /2, 8-9 t Tigril No. BP09.0130 OE No. 03.310.08.51.0 Description ABS Ring Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 10

BPW H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 6,5-9,0 t Tigril No. BP09.0134 OE No. 03.320.73.13.0 Description Washer, shaft seal Remarks H../R.., KH../KR.., NH../NR.., SH../SKH.. ECO/ECO-MAXX, ECO-Plus 8-12 t Tigril No. BP09.0135 OE No. 03.320.64.01.0 Description Washer, shaft seal Remarks H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 6,5-9,0 t Tigril No. BP09.0123 OE No. 03.010.93.33.0 Description Cover plate, dust cover wheel bearing Remarks H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX, H../KH.. SH../SKH.. ECO-Plus 8-12 t Tigril No. BP09.0124 OE No. 03.010.93.34.0 Description Cover plate, dust cover wheel bearing Remarks H../R.., KH../KR.., NH../NR.. 6,4-9,0 t Tigril No. BP09.0125 OE No. 03.010.04.15.0 Description Cover plate, dust cover wheel bearing Remarks H../R.., KH../KR.., NH../NR.. 10-12 t Tigril No. BP09.0126 OE No. 03.010.05.22.0 Description Cover plate, dust cover wheel bearing Remarks H../K.., NR.. 13-14 t Tigril No. BP09.0127 OE No. 03.010.05.21.0 Description Cover plate, dust cover wheel bearing Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 11

BPW H.. 16-18 t Tigril No. BP09.0128 OE No. 03.010.06.12.0 Description Cover plate, dust cover wheel bearing Remarks Tigril No. BP09.0129 OE No. 03.120.45.15.0 Description Cover, wheel hub Remarks H.. Tigril No. BP09.0024 OE No. 05.370.07.04.0 Description Wear ring, wheel hub, 16-18 T Remarks Ø110 x Ø213 x 35 H../R.., KH../KR.. Tigril No. BP09.0055 OE No. 05.370.07.43.0 Description Wear ring, wheel hub, 10-12 T Remarks Ø96 x Ø136 x 22 H../K.. Tigril No. BP09.0056 OE No. 05.370.07.20.0 Description Wear ring, wheel hub, 13-14 T Remarks Ø96 x Ø136 / Ø187 x 34 Tigril No. BP09.0119 OE No. 05.370.07.13.0 Description Wear ring, wheel hub Remarks H../R.., KH../KR.. 6,5-9,0 t Tigril No. BP09.0120 OE No. 05.370.06.48.0 Description Wear ring, wheel hub Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 12

BPW H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 6,5-9,0 t Tigril No. BP09.0121 OE No. 03.370.07.60.0 Description Wear ring, wheel hub Remarks H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 6,5-9,0 t Tigril No. BP09.0122 OE No. 05.370.07.67.0 Description Wear ring, wheel hub Remarks H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX, H../KH.. SH../SKH.. ECO-Plus 10-12 t Tigril No. BP09.0136 OE No. 05.370.07.65.0 Description Wear ring, wheel hub without seal Remarks H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX, H../KH.. SH../SKH.. ECO-Plus 10-12 t Tigril No. BP09.0137 OE No. 03.370.07.62.0 Description Wear ring, wheel hub with seal Remarks H.. 16-18 T Tigril No. BP09.0025 OE No. 03.310.99.02.0 Description Seal ring for wheel hub Remarks Rear axle H.. 16-18 T Tigril No. BP09.0026 OE No. 03.310.99.01.0 Description Seal ring for wheel hub Remarks Rear axle H.. 16-18 T Tigril No. BP09.0082 OE No. 03.310.99.01.0 Description Seal ring for wheel hub, black Remarks Rear axle OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 13

BPW H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 6,5-9,0 t Tigril No. BP09.0107 OE No. 02.566.45.70.0 Description Seal ring for wheel hub Remarks H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX, SH../SKH.. ECO-Plus 10-12 t Tigril No. BP09.0108 OE No. 02.566.45.80.0 Description Seal ring for wheel hub Remarks Tigril No. BP09.0109 OE No. 02.566.47.40.0 Description Seal ring for wheel hub Remarks Tigril No. BP09.0110 OE No. 03.310.89.08.0 Description Seal ring for wheel hub Remarks H../K.. 13-14 t Tigril No. BP09.0111 OE No. 03.310.38.21.0 Description Seal ring for wheel hub Remarks H../R.., KH../KR.. 10-12 t Tigril No. BP09.0112 OE No. 03.310.98.21.0 Description Seal ring for wheel hub Remarks H../K.. 13-14 t Tigril No. BP09.0113 OE No. 03.310.38.20.0 Description Seal ring for wheel hub Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 14

BPW H../R.., KH../KR.. 10-12 t Tigril No. BP09.0114 OE No. 03.310.97.30.0 Description Seal ring for wheel hub Remarks Tigril No. BP09.0115 OE No. 03.310.98.14.0 Description Seal ring for wheel hub Remarks Tigril No. BP09.0116 OE No. 03.310.97.15.0 Description Seal ring for wheel hub Remarks H../R.., KH../KR.. 6,5-9,0 t Tigril No. BP09.0117 OE No. 03.310.97.31.0 Description Seal ring for wheel hub Remarks H../R.., KH../KR.. 6,5-9,0 t Tigril No. BP09.0118 OE No. 03.310.97.32.0 Description Seal ring for wheel hub Remarks HZ… 24" Tigril No. BP24.0012 OE No. 03.328.86.05.0 Description Wheel spider 16T Remarks 604.202.224 Rear BPW Tigril No. BP24.0015 OE No. 03.328.76.47.0 Description Wheel spider 12T Remarks 604.202.158 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 15

BPW BPW Tigril No. BP24.0016 OE No. 03.328.83.04.0 Description Wheel spider 14T Remarks 604.202.198 Rear VB-HDE 14-20 ton Tigril No. BP09.0001 OE No. 05.291.01.14.0 Description Equalizing beam bearing, bronze bushes 70 mm Remarks Rear VB-HD 14-20 ton Tigril No. BP09.0002 OE No. 05.291.01.11.0 Description Equalizing beam bearing, rubber steel bush 60mm Remarks Rear Trailer Tigril No. BP09.0003 OE No. Description Equalizing beam bearing, bronze bushes doll type 70 mm Remarks Rear Tigril No. BP09.0008 OE No. Description Equalizing beam bearing, bronze bushes doll type 60mm Remarks VB suspension Tigril No. BP09.0018 OE No. Description Equalizing beam bearing, rubber steel bush doll type 60 mm Remarks Rear Tigril No. BP09.0057 OE No. Description Equalizing Beam Bearing, bronze bushes 60mm 2 bolt Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 16

BPW Tigril No. BP09.0058 OE No. Description Equalizing Beam Bearing, bronze bushes 60mm 4 bolt Remarks Rear VB-HDE 14-20 ton Tigril No. BP09.0011 OE No. 03.112.76.13.0 Description Brass bush, equalizing beam 70 mm Remarks Rear VB-HDE 14-20 ton Tigril No. BP09.0012 OE No. 03.112.76.14.0 Description Brass bush, equalizing beam 60 mm Remarks Rear VB suspension Tigril No. BP09.0010 OE No. 05.113.97.10.0 Description Bush, leaf spring (suspension) rubber 60mm Remarks Rear EL-VB Tigril No. BP09.0034 OE No. 03.177.16.17.0 Description Equalizer bolt kit 70x285 mm (heavy version) Remarks Rear EL-VB Tigril No. BP09.0037 OE No. 03.177.17.04.0 Description Equalizer bolt kit 70x313 mm Remarks Rear EL-VB Tigril No. BP09.0038 OE No. 03.177.16.17.0 Description Equalizer bolt kit 70x281 mm Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 17

BPW EL-VB Tigril No. BP09.0039 OE No. 03.177.16.20.0 Description Equalizer bolt kit 60x285 mm Remarks Rear EL-VB Tigril No. BP09.0040 OE No. 03.177.17.05.0 Description Equalizer bolt kit 60x313 mm Remarks Rear EL-VB Tigril No. BP09.0060 OE No. 03.177.17.04.0 Description Equalizer bolt kit 70x315 mm (heavy version) Remarks Rear EL-VB Tigril No. BP09.0061 OE No. 03.177.16.20.0 Description Equalizer bolt kit 60x285 mm (heavy version) Remarks Rear EL-VB Tigril No. BP09.0062 OE No. 03.177.17.05.0 Description Equalizer bolt kit 60x313 mm (heavy version) Remarks Rear Tigril No. BP09.0067 OE No. Description Center hanger right, equalizing beam 60 mm Remarks Tigril No. BP09.0068 OE No. Description Rear hanger right & left, equalizing beam 60 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 18

BPW Tigril No. BP09.0069 OE No. Description Front hanger right, equalizing beam 60 mm Remarks Tigril No. BP09.0084 OE No. Description Center hanger left, equalizing beam 60 mm Remarks Tigril No. BP09.0086 OE No. Description Front hanger left, equalizing beam 60 mm Remarks Tigril No. BP09.0087 OE No. Description Center hanger right, equalizing beam 70 mm Remarks Tigril No. BP09.0088 OE No. Description Center hanger left, equalizing beam 70 mm Remarks Tigril No. BP09.0070 OE No. Description Side plate, D block Remarks VB suspension Tigril No. BP09.0004 OE No. 05.443.71.55.0 Description Connecting rod, adjustable short (36 mm) Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 19

BPW VB suspension Tigril No. BP09.0005 OE No. 05.443.70.77.0 Description Connecting rod, adjustable (30 mm) Remarks Rear VB suspension Tigril No. BP09.0006 OE No. 05.443.48.35.0 Description Connecting rod, fixed long (36 mm) Remarks Rear VB suspension Tigril No. BP09.0007 OE No. 05.443.46.03.0 Description Connecting rod, fixed short (36 mm) Remarks Rear VB suspension Tigril No. BP09.0031 OE No. 05.443.71.02.0 Description Connecting Rod, adjustable (36mm) long Remarks Rear Tigril No. BP09.0063 OE No. Description Connecting rod with PU bush, fixed long (435 mm) Remarks Tigril No. BP09.0064 OE No. Description Connecting rod with PU bush, fixed short (390 mm) Remarks VB suspension Tigril No. BP09.0009 OE No. 05.113.93.03.0 Description Bush, connecting rod (36 mm) Remarks Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 20

BPW Tigril No. BP09.0028 OE No. 05.113.93.03.0PU Description Bush (PU), connecting rod (36 mm) Remarks Rear axle VB suspension Tigril No. BP09.0047 OE No. 05.113.93.03.0 Description Bush (PU), connecting rod 36 mm Remarks H../K.., NR.. Tigril No. BP09.0014 OE No. 03.262.17.11.0 Description Axle nut 13-18 T Remarks Rear EH suspension Tigril No. BP09.0015 OE No. 03.262.17.08.0 Description Axle nut 14 T Remarks Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP09.0016 OE No. 03.262.17.12.0 Description Axle nut 12 T Remarks Rear Tigril No. BP09.0101 OE No. 03.262.16.08.0 Description Axle nut M42 x 2 wrench size-65 mm Remarks M42 x 2 Wrench size-65 mm H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 6,5-9,0 t Tigril No. BP09.0102 OE No. 03.266.46.02.0 Description Axle nut M42 x 2 wrench size-65 mm Remarks M42 x 2 Wrench size-65 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 21

BPW H../R.. KH../KR.. NH../NR.. SH../SKH.. ECO/ECO-MAXX 10-12 t Tigril No. BP09.0103 OE No. 03.266.47.03.0 Description Axle nut M52 x 2 wrench size-80 mm Remarks M52 x 2 Wrench size-80 mm Tigril No. BP09.0104 OE No. 03.262.16.15.0 Description Axle nut M42 x 2 wrench size-65 mm Remarks M42 x 2 Wrench size-65 mm Tigril No. BP09.0105 OE No. 03.262.17.18.0 Description Axle nut M52 x 2 wrench size-80 mm Remarks M52 x 2 Wrench size-80 mm Tigril No. BP09.0106 OE No. 03.262.17.19.0 Description Axle nut M60 x 2 wrench size-85 mm Remarks M60 x 2 Wrench size-85 mm BPW Tigril No. BP09.0089 OE No. 02.031.42.40.0 Description Bushing Remarks 60X72 BPW O, SL, AL Tigril No. BP09.0097 OE No. 02.031.59.80.0 Description Bushing Remarks BPW O, SL, AL Tigril No. BP09.0098 OE No. 02.031.69.00.0 Description Bushing Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 22

BPW BPW, VA, VB Tigril No. BP09.0100 OE No. 02.031.66.50.0 Description Bushing Remarks Tigril No. BP24.0001 OE No. 03.296.23.17.0 Description Bolt for wheel M22 x 2, M22 x 1.5 112-61/48 mm, 10.9 Remarks M22 x 2, M22 x 1.5 112-61/48 mm, 10.9 Tigril No. BP24.0005 OE No. 02.507.03.20.0 Description Wheel bolt M20 x 2 x 117/115 mm, 10.9 Remarks M20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. BP24.0010 OE No. 02.507.08.70.0 Description Wheel bolt M20 x 2 x 132/130 mm, 10.9 Remarks M20 x 2 x 132/130 mm, 10.9 659112613 Tigril No. BP24.0014 OE No. 03.296.33.11.1 Description Wheel bolt M22 x 1.5 x 90 Remarks 22 x 1.5 x 90 Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 23

BPW Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks Tigril No. BP24.0017 OE No. 09.806.33.11.0 Description Wheel bolt M22 x 1.5 x 89/47 mm, 10.9 Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 24

BPW Tigril No. DB24.0030 OE No. 02.507.08.90.0 Description Wheel bolt M20 x 2 x 57/55 mm, 10.9 Remarks Tigril No. BP24.0004 OE No. 02.507.03.20.0Set Description Wheel bolt set M20 x 2 x 117/115 mm, 10.9 Remarks M20 x 2 x 117/115 mm, 10.9 659112612 Tigril No. BP24.0009 OE No. 02.507.08.70.0Set Description Wheel bolt set M20 x 2 x 132/130 mm, 10.9 Remarks M20 x 2 x 132/130 mm, 10.9 659112613 Tigril No. BP24.0013 OE No. 05.806.23.22.0 Description Wheel bolt set M22 x 2, M22 x 1.5 112-61/48 mm, 10.9 Remarks M22 x 2, M 22 x1.5 112-61/48 mm, 10.9 Tigril No. DB24.0029 OE No. 02.507.08.90.0Set Description Wheel bolt set M20 x 2 x 57/55 mm, 10.9 Remarks Tigril No. DB24.0055 OE No. 02.507.02.20.0Set Description Wheel bolt set M20 x 2 x 124 mm, 10.9 Remarks Tigril No. BP24.0002 OE No. 03.260.04.01.0 Description Wheel nut M22 x 2 H-25 wrench size-32 mm Remarks M22 x 2 H-25 wrench size-32 mm OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 26

BPW EH, EHZ Tigril No. BP24.0003 OE No. 03.260.04.06.0 Description Wheel nut M22 x 2 H-17 wrench size-32 mm Remarks M22 x 2 H-17 wrench size-32 mm Tigril No. BP24.0006 OE No. 02.527.00.40.0 Description Wheel nut M20 x 2 H-20 wrench size-27 mm Remarks M20 x 2 H-20 wrench size-27 mm Tigril No. BP24.0018 OE No. 09.266.47.11.0 Description Wheel nut M22 x 2 wrench size-95 mm Remarks Tigril No. DB24.0016 OE No. 03.260.54.03.0 Description Wheel nut M22 x 1.5 H-22 wrench size-30 mm Remarks H/KH/NH/NR/R, RBH Tigril No. DB24.0017 OE No. 05.260.54.09.0 Description Wheel nut M22 x 1.5 H-27 wrench size-32 mm Remarks Tigril No. DB24.0018 OE No. 02.5213.14.62 Description Wheel nut M20 x 1.5 H-21 wrench size-27 mm Remarks Tigril No. DB24.0019 OE No. 02.5213.12.10 Description Wheel nut M18 x 1.5 H-18 wrench size-24 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 27

BPW Trailer Tigril No. DB24.0057 OE No. 05.260.54.14.0 Description Wheel nut M22 x 1.5 H-62 wrench size-32 mm Remarks H Series Tigril No. IV24.0001 OE No. 02.521.92.01.0 Description Wheel nut Remarks Tigril No. BP24.0007 OE No. 02.545.02.20.0 Description Washer Remarks 36.9 x 21.2 x 2.75 mm Tigril No. DB24.0021 OE No. 02.5615.20.90 Description Washer (retaining ring, wheel rim) 24 x 20.5 x 8 mm Remarks Tigril No. DB24.0022 OE No. 03.310.10.02.0 Description Washer (centering ring, wheel rim) 32 x 20.2 x 6 mm Remarks Tigril No. DB24.0023 OE No. 02.561.51.89.0 Description Washer (retaining ring, wheel rim) 29 x 18.5 x 7 mm Remarks Tigril No. DB24.0025 OE No. 02.561.51.49.0 Description Washer (retaining ring, wheel rim) 23 x 14.5 x 5 mm Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 28

BPW Tigril No. DB24.0027 OE No. 02.561.52.29.0 Description Washer (retaining ring, wheel rim) 34 x 22.5 x 8 mm Remarks Tigril No. BP24.0008 OE No. 02.181.81.00.0 Description Safety pin Remarks 41/30 x 2 mm Tigril No. BP24.0011 OE No. 02.181.61.40.0 Description Wheel clamp Remarks 659.002.171 ID 21 mm, 10.9 zinc coated SKH Tigril No. BP13.0010 OE No. 03.088.34.02.0 Description Brake disc Remarks Rear SHSF, SDSF, SHSM, SHSMA, SHZF, SHZM, SHZMA, SHBF Tigril No. BP13.0011 OE No. 03.088.35.03.0 Description Brake disc Remarks Rear SHSF, SHSFA, SHSM, SHZ, SHZF, SHZM, SHZMA Tigril No. BP14.0002 OE No. 03.088.34.08.0 Description Brake disc Remarks Front & Rear SH Series Tigril No. DB12.0004 OE No. 09.801.02.57.0 Description Brake pad set with accessories Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 29

BPW Tigril No. DB14.0002 OE No. 02.031.21.60.0 Description Brake pad set with accessories Remarks Tigril No. DB14.0003 OE No. 09.801.07.07.0 Description Brake pad set with accessories Remarks SH Series Tigril No. DB14.0006 OE No. 09.801.02.57.0 Description Brake pad set with accessories Remarks Trailer Tigril No. BP13.0001 OE No. 03.106.67.29.0 Description Brake drum Remarks 420 x 200 Rear BPW Tigril No. BP13.0005 OE No. 03.109.77.17.0 Description Brake drum Remarks Rear EHZ Series Tigril No. BP13.0012 OE No. 03.106.77.04.0 Description Brake drum Remarks 420 x 200 Rear HZ.. 14010-1 Tigril No. BP13.0013 OE No. 03.106.77.59.0 Description Brake drum Remarks 420 x 217 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 30

BPW HS.. / HZ.. Tigril No. BP13.0018 OE No. 03.109.77.72.0 Description Brake drum Remarks 420 x 217 Rear HS.. Tigril No. BP13.0027 OE No. 03.106.77.57.0 Description Brake drum Remarks 420 x 200 Rear H series Tigril No. BP13.0028 OE No. 03.106.77.56.0 Description Brake drum Remarks 420 x 200 Rear N.. ECO-MAXX, N.. MAXX Tigril No. BP13.0029 OE No. 03.109.46.06.0 Description Brake drum Remarks 300 x 200 Rear Tigril No. BP13.0044 OE No. 03.106.77.63.0 Description Brake drum Remarks Rear HS.., ECO MAXX / MAXX / ECO plus Tigril No. BP13.0045 OE No. 03.109.67.19.0 Description Brake drum lock type Remarks 420 X 180 Rear HS.. Tigril No. BP13.0046 OE No. 03.109.67.13.0 Description Brake drum Remarks 420 X 180 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 31

BPW Tigril No. BP13.0047 OE No. 03.106.67.29.0 Description Brake drum (Heavy duty) Remarks 420 x 200 Rear H Series 10/12T SN 4220 2XL/3XL Tigril No. BP14.0006 OE No. 99.000.00.12.6 Description Cover plate with repair kit, brake drum Remarks H Series 8/9 T, SN 4218-2 Tigril No. BP14.0007 OE No. 99.000.00.07.1 Description Cover plate with repair kit, brake drum Remarks SN.4218-2 H Series 10/12T SN 4220-2 Tigril No. BP14.0008 OE No. 99.000.00.07.3 Description Cover plate with repair kit, brake drum Remarks SN.4220-2 H Series 8/9 T, SN 4218-2 Tigril No. BP14.0009 OE No. 99.000.00.08.8 Description Cover plate with repair kit, brake drum Remarks SN.4218-2 H Series 8/9 T, SN 4218, SN 4220 Tigril No. BP14.0010 OE No. 99.000.00.09.8 Description Cover plate with repair kit, brake drum Remarks SN.4218 / SN.4220 Tigril No. BP14.0020 OE No. 99.000.00.09.3 Description Cover plate with repair kit, brake drum Remarks H 8.000, H 9.000 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 32

BPW EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HSF/HZFH/HZM Tigril No. BP13.0002 OE No. 03.092.27.77.0 Description Brake lining with rivets, std Remarks 19094 EH EHF/E/EHI/EHIZ/EHIZVB/EHS/EHXZ/EHZ/EHZDO,H,HZMD/HZMDH/HZMDHOM/HZMDHOT/HZMDO/HXZH Tigril No. BP13.0003 OE No. 03.092.26.01.0 Description Brake lining with rivets, std Remarks 19032 Rear EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0048 OE No. 03.092.27.77.0 Description Brake lining with rivets, 18 mm Remarks 19094 Rear EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0049 OE No. 03.092.27.77.0 Description Brake lining with rivets, 19 mm Remarks 19094 Rear EH/EHF/EHI/EHS/EHXZ/EHZ, EHZDO, H, HZMD/HZMDH/HXZH/HXZ/HZ/HZF/HXZ/HSF/HZFH/HZM Tigril No. BP13.0050 OE No. 03.092.27.77.0 Description Brake lining with rivets, 20 mm Remarks 19094 Rear EH, H Tigril No. BP13.0014 OE No. 05.091.27.54.2 Description Brake shoe with steel roller, 200 mm Remarks 420 x 200 Rear H../R.. Tigril No. BP13.0015 OE No. 05.091.27.83.0 Description Brake shoe with steel roller, 200 mm Remarks 420 x 200 Rear OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 33

BPW EH, H Tigril No. BP13.0016 OE No. 05.091.26.64.2 Description Brake shoe with steel roller, 180 mm Remarks 420 x 180 Rear H../R.. Tigril No. BP13.0017 OE No. 05.091.46.17.0 Description Brake shoe with steel roller, 180 mm Remarks 420 x 180 Rear H../R.. Tigril No. BP13.0021 OE No. 05.397.58.03.0 Description Brake shoe spring Remarks Rear EH.., H.., M.., R.. Tigril No. BP13.0022 OE No. 03.397.34.11.0 Description Brake shoe spring Remarks Rear H.., R.. Tigril No. BP13.0023 OE No. 03.397.33.07.0 Description Brake shoe spring Remarks Rear H../R.. Tigril No. BP13.0024 OE No. 03.397.33.06.0 Description Brake shoe spring Remarks Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP13.0030 OE No. 03.397.44.06.0 Description Brake shoe spring Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 34

BPW H../R.. Tigril No. BP13.0031 OE No. 05.397.46.06.0 Description Brake shoe spring Remarks BPW H../R.., KH../KR.., NH../NR.. Tigril No. BP14.0013 OE No. 09.801.02.91.0 Description Repair kit, brake shoe Remarks Tigril No. BP14.0016 OE No. 09.801.02.11.0S Description Repair kit, brake shoe Remarks Tigril No. BP14.0017 OE No. 09.801.02.12.0S Description Repair kit, brake shoe Remarks Tigril No. BP14.0018 OE No. 09.801.02.10.0S Description Repair kit, brake shoe Remarks Tigril No. BP14.0019 OE No. 09.801.02.09.0 Description Repair kit, brake shoe Remarks Tigril No. BP14.0011 OE No. 03.084.46.23.0 Description Brake shoe pin Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 35

BPW BPW H../R.., KH../KR../KM.., NH../NR.. Tigril No. BP14.0014 OE No. 03.112.33.08.0 Description Brake shoe bushing Remarks BPW H.., R.., KH.., KR.., NH.., NR.. Tigril No. BP14.0015 OE No. 03.188.02.02.0 Description Lock ring Remarks Tigril No. BP14.0012 OE No. 03.084.46.23.0S Description Brake shoe pin plate Remarks H../R.., KH../KR.. Tigril No. BP13.0008 OE No. 05.174.52.61.0 Description Slack adjuster manual 5 holes Remarks 100.001.721 Rear H../R.., KH../KR.., NH../NR.. Tigril No. BP13.0009 OE No. 05.174.65.13.0 Description Slack adjuster manual 7 holes Remarks 100.001.760 Rear H../R.., KH../KR.., NH../NR.., ECO-Master Tigril No. BP14.0004 OE No. 05.574.82.87.3 Description Slack adjuster AT with sensor hole Remarks 80019 Front & Rear Tigril No. DB12.0006 OE No. 05.174.90.20.0 Description Slack adjuster automatic Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 36

BPW Tigril No. DB12.0014 OE No. 05.174.90.20.0S Description Slack adjuster AT with sensor hole Remarks Tigril No. DB13.0006 OE No. 05.174.54.69.0 Description Slack adjuster manual Remarks Tigril No. DB13.0007 OE No. 05.174.54.70.0 Description Slack adjuster manual Remarks H../R.., KH../KR.., NH../NR.., ECO-Master Tigril No. BP13.0025 OE No. 05.397.26.03.0 Description Return spring for slack adjuster Remarks Rear H../R.., NH../NR.. Tigril No. BP13.0032 OE No. 05.397.26.02.0 Description Spring, slack adjuster Remarks 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0033 OE No. 05.097.05.37.4 Description Brake camshaft, left Remarks 755,0 / 634.5mm, Ø 42 mm, 10 teeth 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0034 OE No. 05.097.05.38.4 Description Brake camshaft, right Remarks 755,0 / 634.5mm, Ø 42 mm, 10 teeth OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 37

BPW 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0035 OE No. 05.097.05.23.4 Description Brake camshaft, left Remarks 643,0 / 522.5mm, Ø 42 mm, 10 teeth 2XL/3XL, H../R.., KH../KR.. Tigril No. BP13.0036 OE No. 05.097.05.24.4 Description Brake camshaft, right Remarks 643,0 / 522.5mm, Ø 42 mm, 10 teeth H../R.., KH../KR.. Tigril No. BP13.0037 OE No. 05.097.05.21.4 Description Brake camshaft, left Remarks 630,0 / 509.5mm, Ø 42 mm, 10 teeth H../R.., KH../KR.. Tigril No. BP13.0038 OE No. 05.097.05.22.4 Description Brake camshaft, right Remarks 630,0 / 509.5mm, Ø 42 mm, 10 teeth H.., KH.., KM.., KR.., NH.., NM..,NR..,NRD.. Tigril No. BP13.0026 OE No. 09.801.02.22.0 Description Repair kit for brake camshaft Remarks Rear H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP13.0039 OE No. 09.801.00.14.1 Description Repair kit, brake camshaft Remarks H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP13.0040 OE No. 03.112.44.30.0S1 Description Repair kit, brake camshaft Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 38

BPW H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP13.0041 OE No. 03.112.44.30.0S2 Description Repair kit, brake camshaft Remarks H../K../N.. Series Tigril No. BP13.0042 OE No. 03.229.02.18.0 Description Retainer, brake camshaft Remarks 50 x 110 / 4 x Ø10 H../K../N.. Series Tigril No. BP13.0043 OE No. 03.229.02.19.0 Description Retainer, brake camshaft Remarks 50 x 110 / 6 x Ø10 H../R.., K../N.., KH../KR../KM.., NH../NR.. Tigril No. BP14.0001 OE No. 03.112.44.34.0 Description Bush, brake camshaft Remarks Front & Rear SH../SKH…, S../LL Tigril No. BP12.0001 OE No. 02.032.77.80.0 Description Brake chamber 24 M16 x 1.5 Remarks 423.506.001.0 H.. /R.., KH../KR.., NH../NR.. Tigril No. BP12.0002 OE No. 05.444.15.01.0 Description Brake cylinder 24 Remarks 423.106.900.0 423.106.091.0 295555 Front SH../SKH…, S../LL Tigril No. BP12.0003 OE No. 02.032.77.80.0 Description Brake cylinder 24 M22 x 1.5 Remarks 423.506.001.0 M22 x 1.5 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 39

BPW Tigril No. BP13.0020 OE No. 05.444.16.01.0 Description Brake cylinder 30 Remarks 423.107.900.0 Tigril No. BP13.0004 OE No. 05.444.21.01.0 Description Spring brake cylinder 30/30 Remarks Tigril No. DB13.0042 OE No. 02.032.78.80.0 Description Spring brake cylinder 16/24 Remarks Tigril No. MA14.0022 OE No. 02.431.00.90.0 Description 2-way valve Remarks Tigril No. DB14.0124 OE No. 02.431.09.10.0 Description 3/2 Directional control valve Remarks Tigril No. DB14.0093 OE No. 02.102.41.00.0 Description Air line filter Remarks Tigril No. BP14.0005 OE No. 02.033.21.30.0 Description Automatic load sensing valve Remarks 475.714.500.0 OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 40

BPW Tigril No. BP14.0003 OE No. 02.431.13.50.0 Description Level valve Remarks 464.006.100.0, I98289 Tigril No. SC14.0014 OE No. 02.431.14.10.0 Description Lift axle control valve Remarks Tigril No. MA14.0031 OE No. 02.431.15.00.0 Description Pressure regulator valve Remarks Tigril No. MA14.0032 OE No. 02.431.09.60.0 Description Pressure regulator valve Remarks Universal Tigril No. DB14.0101 OE No. 02.431.07.20.0 Description Quick release valve Remarks Tigril No. MA14.0014 OE No. 02.431.07.70.0 Description Trailer control valve Remarks Tigril No. MA14.0026 OE No. 02.431.03.00.0 Description Water drain valve Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 41

BPW H Series Tigril No. DA14.0019 OE No. 02.331.70.50.0 Description ABS sensor with bush and grease, 410 mm Remarks SH../SKH.. 8-12 t Tigril No. SC14.0007 OE No. 02.031.65.90.0 Description Clamping bushing, wheel speed sensor Remarks Tigril No. SC14.0009 OE No. 02.181.91.50.0 Description Cable with connector plug/ socket ABS Remarks Tigril No. DI14.0069 OE No. 02.2801.02.00 Description Test connector Remarks O, SL, AL Tigril No. BP80.0001 OE No. 02.507.09.50.0 Description Screw Remarks OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 42

Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 43 BP09.0001 05.291.01.14.0 16 BP09.0002 05.291.01.11.0 16 BP09.0003 16 BP09.0004 05.443.71.55.0 19 BP09.0005 05.443.70.77.0 20 BP09.0005 05.443.70.11.0 20 BP09.0005 05.443.70.15.1 20 BP09.0005 05.443.70.16.1 20 BP09.0005 05.443.70.26.0 20 BP09.0005 05.443.70.31.0 20 BP09.0005 05.443.70.61.0 20 BP09.0005 05.443.70.66.0 20 BP09.0005 05.443.70.70.0 20 BP09.0005 05.443.70.79.0 20 BP09.0006 05.443.48.35.0 20 BP09.0007 05.443.46.03.0 20 BP09.0008 16 BP09.0009 05.113.93.03.0 20 BP09.0009 02.031.33.05.0 20 BP09.0010 05.113.97.10.0 17 BP09.0011 03.112.76.13.0 17 BP09.0012 03.112.76.14.0 17 BP09.0013 03.112.99.04.0 4 BP09.0014 03.262.17.11.0 21 BP09.0014 03.26217.03.0 21 BP09.0015 03.262.17.08.0 21 BP09.0016 03.262.17.12.0 21 BP09.0017 03.140.16.01.0 3 BP09.0018 16 BP09.0019 03.112.99.02.0 4 BP09.0020 03.272.48.46.0 8 BP09.0020 03.272.48.40.0 8 BP09.0021 03.272.62.27.0 9 BP09.0021 03.272.62.06.0 9 BP09.0021 03.272.62.19.0 9 BP09.0021 03.272.62.20.0 9 BP09.0022 03.272.80.14.0 9 BP09.0022 03.272.80.07.0 9 BP09.0022 03.272.80.10.0 9 BP09.0022 03.272.80.18.0 9 BP09.0022 03.272.80.19.0 9 BP09.0024 05.370.07.04.0 12 BP09.0025 03.310.99.02.0 13 BP09.0025 03.310.99.15.0 13 BP09.0026 03.310.99.01.0 13 BP09.0026 03.310.99.16.0 13 BP09.0027 03.212.26.01.0 9 BP09.0028 05.113.93.03.0PU 21 BP09.0029 02.101.40.62.5 1 BP09.0030 02.101.40.62.5 1 BP09.0031 05.443.71.02.0 20 BP09.0032 03.272.80.86.0 9 BP09.0032 03.272.80.18.0 9 BP09.0032 03.272.80.06.0 9 BP09.0032 03.272.80.07.0 9 BP09.0032 03.272.86.10.0 9 BP09.0033 02.101.40.62.6 1 BP09.0034 03.177.16.17.0 17 BP09.0035 03.138.42.02.4 4 BP09.0036 03.138.61.17.0 4 BP09.0037 03.177.17.04.0 17 BP09.0038 03.177.16.17.0 17 BP09.0039 03.177.16.20.0 18 BP09.0040 03.177.17.05.0 18 BP09.0041 02.101.40.62.5 1 BP09.0042 03.221.89.02.0 5 BP09.0043 03.272.30.97.0 9 BP09.0043 03.272.30.95.0 9 BP09.0044 03.272.48.32.0 9 BP09.0044 03.272.48.07.0 9 BP09.0044 03.272.48.10.0 9 BP09.0044 03.272.48.12.0 9 BP09.0044 03.272.48.35.0 9 BP09.0045 05.082.06.01.0 1 BP09.0046 05.082.06.01.0 1 BP09.0047 05.113.93.03.0 21 BP09.0047 02.031.33.50.0 21 BP09.0048 03.212.25.31.0 9 BP09.0048 03.212.25.33.0 9 BP09.0048 05.212.25.31.0 9 BP09.0049 03.212.27.01.0 10 BP09.0049 03.212.07.01.0 10 BP09.0050 03.212.25.02.0 10 BP09.0050 03.212.05.01.0 10 BP09.0051 03.212.26.14.0 10 BP09.0051 03.212.26.20.0 10 BP09.0052 03.212.24.07.0 10 BP09.0053 03.212.25.08.0 10 BP09.0053 03.212.25.23.0 10 BP09.0054 03.140.14.01.0 3 BP09.0054 03.140.04.02.0 3 BP09.0055 05.370.07.43.0 12 BP09.0056 05.370.07.20.0 12 BP09.0057 16 BP09.0058 17 BP09.0059 03.224.19.03.1 4 BP09.0060 03.177.17.04.0 18 BP09.0061 03.177.16.20.0 18 BP09.0062 03.177.17.05.0 18 BP09.0063 20 BP09.0064 20 BP09.0065 5 BP09.0066 5 BP09.0067 18 BP09.0068 18 BP09.0069 19 BP09.0070 19 BP09.0071 2 BP09.0072 2 BP09.0073 2 BP09.0074 2 BP09.0075 2 BP09.0076 2 BP09.0077 2

Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 44 BP09.0078 3 BP09.0079 3 BP09.0080 3 BP09.0081 3 BP09.0082 03.310.99.01.0 13 BP09.0082 03.310.99.16.0 13 BP09.0083 4 BP09.0084 19 BP09.0085 4 BP09.0086 19 BP09.0087 19 BP09.0088 19 BP09.0089 02.031.42.40.0 22 BP09.0090 03.164.35.02.0 6 BP09.0091 03.281.44.25.0 6 BP09.0092 05.032.22.10.0 5 BP09.0093 05.032.22.09.0 5 BP09.0094 03.164.35.01.0 6 BP09.0095 03.164.35.03.0 6 BP09.0096 03.281.54.18.0 6 BP09.0097 02.031.59.80.0 22 BP09.0097 02.031.69.80.0 22 BP09.0098 02.031.69.00.0 22 BP09.0099 03.188.03.06.0 10 BP09.0100 02.031.66.50.0 23 BP09.0100 02.031.60.50.0 23 BP09.0101 03.262.16.08.0 21 BP09.0102 03.266.46.02.0 21 BP09.0103 03.266.47.03.0 22 BP09.0104 03.262.16.15.0 22 BP09.0105 03.262.17.18.0 22 BP09.0106 03.262.17.19.0 22 BP09.0107 02.566.45.70.0 14 BP09.0107 02.566.45.56.4 14 BP09.0108 02.566.45.80.0 14 BP09.0108 02.566.45.66.4 14 BP09.0109 02.566.47.40.0 14 BP09.0110 03.310.89.08.0 14 BP09.0111 03.310.38.21.0 14 BP09.0112 03.310.98.21.0 14 BP09.0112 03.310.98.22.0 14 BP09.0113 03.310.38.20.0 14 BP09.0114 03.310.97.30.0 15 BP09.0115 03.310.98.14.0 15 BP09.0115 03.310.98.19.0 15 BP09.0116 03.310.97.15.0 15 BP09.0116 03.310.97.27.0 15 BP09.0117 03.310.97.31.0 15 BP09.0118 03.310.97.32.0 15 BP09.0119 05.370.07.13.0 12 BP09.0120 05.370.06.48.0 12 BP09.0121 03.370.07.60.0 13 BP09.0122 05.370.07.67.0 13 BP09.0123 03.010.93.33.0 11 BP09.0124 03.010.93.34.0 11 BP09.0125 03.010.04.15.0 11 BP09.0126 03.010.05.22.0 11 BP09.0127 03.010.05.21.0 11 BP09.0128 03.010.06.12.0 12 BP09.0129 03.120.45.15.0 12 BP09.0130 03.310.08.51.0 10 BP09.0131 03.310.39.02.0 5 BP09.0132 03.264.19.03.0 5 BP09.0133 03.264.19.02.0 6 BP09.0134 03.320.73.13.0 11 BP09.0135 03.320.64.01.0 11 BP09.0136 05.370.07.65.0 13 BP09.0137 03.370.07.62.0 13 BP09.0138 02.5220.85.26 6 BP09.0138 02.5220.84.82 6 BP09.0138 02.5207.29.04 6 BP09.0139 03.340.16.04.0 7 BP09.0140 03.340.16.05.0 7 BP09.0141 03.340.16.06.0 7 BP09.0142 PS1500.06.01 3 BP10.0001 05.429.41.36.1 7 BP10.0001 05.429.04.07.1 7 BP10.0001 05.429.40.14.1 7 BP10.0001 05.429.40.24.1 7 BP10.0001 05.429.40.39.1 7 BP10.0001 05.429.40.61.1 7 BP10.0001 05.429.40.43.1 7 BP10.0001 05.429.40.47.1 7 BP10.0001 05.429.40.48.1 7 BP10.0001 05.429.40.50.1 7 BP10.0001 05.429.40.61.1 7 BP10.0001 05.429.41.21.1 7 BP10.0001 05.429.41.35.1 7 BP10.0001 05.429.41.42.1 7 BP10.0001 05.429.43.51.0 7 BP10.0002 05.429.40.01.0 7 BP10.0002 05.429.41.36.1 7 BP10.0002 05.429.41.661 7 BP10.0003 05.429.40.93.1 7 BP10.0003 05.429.42.19.1 7 BP10.0003 05.429.42.41.1 7 BP10.0003 05.429.43.21.0 7 BP10.0004 05.429.40.91.0 8 BP10.0004 05.429.41.51.0 8 BP10.0004 05.429.42.56.0 8 BP10.0005 05.429.40.28.1 7 BP10.0006 05.429.40.03.0 8 BP12.0001 02.032.77.80.0 39 BP12.0001 02.032.77.90.0 39 BP12.0001 05.444.36.01.0 39 BP12.0001 05.444.36.02.0 39 BP12.0002 05.444.15.01.0 39 BP12.0002 02.032.73.10.0 39 BP12.0002 05.444.15.10.0 39 BP12.0002 05.444.15.11.0 39 BP12.0003 02.032.77.80.0 39 BP12.0003 02.032.77.90.0 39 BP12.0003 05.444.36.01.0 39 BP12.0003 05.444.36.02.0 39

Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 45 BP13.0001 03.106.67.29.0 30 BP13.0001 -03.106.67.44.0 30 BP13.0001 -03.106.67.45.0 30 BP13.0002 03.092.27.77.0 33 BP13.0002 03.092.27.01.0 33 BP13.0002 03.092.27.02.0 33 BP13.0002 03.092.27.03.0 33 BP13.0002 03.092.27.06.0 33 BP13.0002 03.092.27.15.0 33 BP13.0002 03.092.27.19.0 33 BP13.0002 03.092.27.22.0 33 BP13.0002 03.092.27.24.0 33 BP13.0002 03.092.27.43.0 33 BP13.0002 03.092.27.45.0 33 BP13.0002 03.092.27.53.0 33 BP13.0002 03.092.27.54.0 33 BP13.0002 03.092.27.63.0 33 BP13.0002 03.292.27.64.0 33 BP13.0002 03.292.27.65.0 33 BP13.0002 03.092.27.71.0 33 BP13.0002 03.092.27.72.0 33 BP13.0002 03.092.27.74.0 33 BP13.0002 03.092.27.75.0 33 BP13.0002 03.092.27.76.0 33 BP13.0002 03.092.27.81.0 33 BP13.0002 05.091.27.79.0 33 BP13.0002 19094 33 BP13.0003 03.092.26.01.0 33 BP13.0003 03.092.26.06.0 33 BP13.0003 03.092.26.10.0 33 BP13.0003 03.092.26.11.0 33 BP13.0003 03.092.26.21.0 33 BP13.0003 03.092.26.25.0 33 BP13.0003 03.092.26.26.0 33 BP13.0003 03.092.26.32.0 33 BP13.0003 03.092.26.45.0 33 BP13.0003 03.092.26.48.0 33 BP13.0003 03.092.26.56.0 33 BP13.0003 03.092.26.66.0 33 BP13.0003 03.092.26.76.0 33 BP13.0003 03.092.26.85.0 33 BP13.0003 05.091.26.90.0 33 BP13.0003 05.091.26.95.0 33 BP13.0003 05.091.46.09.0 33 BP13.0003 19032 33 BP13.0004 05.444.21.01.0 40 BP13.0004 05.444.21.01.1 40 BP13.0004 05.444.21.11.0 40 BP13.0004 05.444.21.04.0 40 BP13.0005 03.109.77.17.0 30 BP13.0008 05.174.52.61.0 36 BP13.0009 05.174.65.13.0 36 BP13.0010 03.088.34.02.0 29 BP13.0010 03.088.34.02.7 29 BP13.0010 03.088.34.06.0 29 BP13.0010 03.088.34.06.7 29 BP13.0010 03.002.24.09.3 29 BP13.0011 03.088.35.03.0 29 BP13.0011 03.088.35.03.7 29 BP13.0011 03.088.35.05.0 29 BP13.0011 03.088.35.05.7 29 BP13.0011 03.088.35.12.7 29 BP13.0012 03.106.77.04.0 30 BP13.0012 03.106.77.12.0 30 BP13.0012 03.106.77.19.0 30 BP13.0012 03.106.77.21.0 30 BP13.0012 03.106.77.41.0 30 BP13.0013 03.106.77.59.0 30 BP13.0014 05.091.27.54.2 33 BP13.0014 05.091.27.54.0 33 BP13.0014 05.091.27.54.1 33 BP13.0015 05.091.27.83.0 33 BP13.0015 05.090.27.06.0 33 BP13.0016 05.091.26.64.2 34 BP13.0016 05.091.26.64.0 34 BP13.0016 05.091.26.64.1 34 BP13.0016 05.090.26.06.2 34 BP13.0017 05.091.46.17.0 34 BP13.0017 05.090.26.14.0 34 BP13.0018 03.109.77.72.0 31 BP13.0018 03.106.77.52.0 31 BP13.0018 03.109.77.30.0 31 BP13.0018 03.106.77.72.0 31 BP13.0020 05.444.16.01.0 40 BP13.0020 02.032.72.90.0 40 BP13.0020 05.444.16.10.0 40 BP13.0020 05.444.16.11.0 40 BP13.0021 05.397.58.03.0 34 BP13.0022 03.397.34.11.0 34 BP13.0022 03.397.34.10.0 34 BP13.0023 03.397.33.07.0 34 BP13.0023 03.285.22.05.0 34 BP13.0023 03.397.33.13.0 34 BP13.0023 03.397.45.10.0 34 BP13.0023 05.397.45.10.0 34 BP13.0023 09.825.00.84.0 34 BP13.0024 03.397.33.06.0 34 BP13.0024 03.285.22.05.0 34 BP13.0024 03.397.33.12.0 34 BP13.0024 03.397.45.10.0 34 BP13.0024 05.397.45.10.0 34 BP13.0025 05.397.26.03.0 37 BP13.0025 03.397.26.03.0 37 BP13.0025 05.397.27.01.0 37 BP13.0025 05.397.36.05.0 37 BP13.0026 09.801.02.22.0 38 BP13.0026 04.801.06.09.1 38 BP13.0026 09.801.06.09.0 38 BP13.0026 09.801.06.09.1 38 BP13.0027 03.106.77.57.0 31 BP13.0027 03.109.77.16.0 31 BP13.0027 03.109.77.77.0 31 BP13.0028 03.106.77.56.0 31 BP13.0028 08.106.77.56.0 31

Index I (Tigril No - OE No) Please visit our online catalogue at www.tigril.de for more info. OE/Reference numbers and names, other than Tigril, serve for comparison purpose only and must not be mentioned on invoices to the vehicle owners. 46 BP13.0029 03.109.46.06.0 31 BP13.0030 03.397.44.06.0 34 BP13.0031 05.397.46.06.0 35 BP13.0031 05.397.45.01.0 35 BP13.0031 05.397.45.03.0 35 BP13.0031 05.397.46.07.0 35 BP13.0032 05.397.26.02.0 37 BP13.0033 05.097.05.37.4 37 BP13.0033 05.097.05.37.0 37 BP13.0033 05.097.05.37.1 37 BP13.0033 05.097.05.37.2 37 BP13.0033 05.097.05.37.3 37 BP13.0034 05.097.05.38.4 37 BP13.0034 05.097.05.38.0 37 BP13.0034 05.097.05.38.1 37 BP13.0034 05.097.05.38.2 37 BP13.0034 05.097.05.38.3 37 BP13.0035 05.097.05.23.4 38 BP13.0035 05.097.05.23.0 38 BP13.0035 05.097.05.23.1 38 BP13.0035 05.097.05.23.2 38 BP13.0035 05.097.05.23.3 38 BP13.0036 05.097.05.24.4 38 BP13.0036 05.097.05.24.0 38 BP13.0036 05.097.05.24.1 38 BP13.0036 05.097.05.24.2 38 BP13.0036 05.097.05.24.3 38 BP13.0037 05.097.05.21.4 38 BP13.0037 05.097.05.21.0 38 BP13.0037 05.097.05.21.1 38 BP13.0037 05.097.05.21.2 38 BP13.0037 05.097.05.21.3 38 BP13.0038 05.097.05.22.4 38 BP13.0038 05.097.05.22.0 38 BP13.0038 05.097.05.22.1 38 BP13.0038 05.097.05.22.2 38 BP13.0038 05.097.05.22.3 38 BP13.0039 09.801.00.14.1 38 BP13.0039 09.801.00.14.0 38 BP13.0040 03.112.44.30.0S1 38 BP13.0041 03.112.44.30.0S2 39 BP13.0042 03.229.02.18.0 39 BP13.0043 03.229.02.19.0 39 BP13.0044 03.106.77.63.0 31 BP13.0044 03.109.77.34.0 31 BP13.0044 03.106.77.45.0 31 BP13.0044 03.109.77.46.0 31 BP13.0045 03.109.67.19.0 31 BP13.0045 03.109.67.29.0 31 BP13.0045 03.109.67.79.0 31 BP13.0045 03.109.67.32.0 31 BP13.0045 09.109.67.79.0 31 BP13.0045 09.109.67.19.0 31 BP13.0046 03.109.67.13.0 31 BP13.0046 03.106.67.62.0 31 BP13.0046 03.109.67.82.0 31 BP13.0047 03.106.67.29.0 32 BP13.0047 03.106.67.44.0 32 BP13.0047 03.106.67.45.0 32 BP13.0048 03.092.27.77.0 33 BP13.0048 03.092.27.01.0 33 BP13.0048 03.092.27.02.0 33 BP13.0048 03.092.27.03.0 33 BP13.0048 03.092.27.06.0 33 BP13.0048 03.092.27.15.0 33 BP13.0048 03.092.27.19.0 33 BP13.0048 03.092.27.22.0 33 BP13.0048 03.092.27.24.0 33 BP13.0048 03.092.27.43.0 33 BP13.0048 03.092.27.45.0 33 BP13.0048 03.092.27.53.0 33 BP13.0048 03.092.27.54.0 33 BP13.0048 03.092.27.63.0 33 BP13.0048 03.292.27.64.0 33 BP13.0048 03.292.27.65.0 33 BP13.0048 03.092.27.71.0 33 BP13.0048 03.092.27.72.0 33 BP13.0048 03.092.27.74.0 33 BP13.0048 03.092.27.75.0 33 BP13.0048 03.092.27.76.0 33 BP13.0048 03.092.27.81.0 33 BP13.0048 05.091.27.79.0 33 BP13.0048 19094 33 BP13.0049 03.092.27.77.0 33 BP13.0049 03.092.27.01.0 33 BP13.0049 03.092.27.02.0 33 BP13.0049 03.092.27.03.0 33 BP13.0049 03.092.27.06.0 33 BP13.0049 03.092.27.15.0 33 BP13.0049 03.092.27.19.0 33 BP13.0049 03.092.27.22.0 33 BP13.0049 03.092.27.24.0 33 BP13.0049 03.092.27.43.0 33 BP13.0049 03.092.27.45.0 33 BP13.0049 03.092.27.53.0 33 BP13.0049 03.092.27.54.0 33 BP13.0049 03.092.27.63.0 33 BP13.0049 03.292.27.64.0 33 BP13.0049 03.292.27.65.0 33 BP13.0049 03.092.27.71.0 33 BP13.0049 03.092.27.72.0 33 BP13.0049 03.092.27.74.0 33 BP13.0049 03.092.27.75.0 33 BP13.0049 03.092.27.76.0 33 BP13.0049 03.092.27.81.0 33 BP13.0049 05.091.27.79.0 33 BP13.0049 19094 33 BP13.0050 03.092.27.77.0 33 BP13.0050 03.092.27.01.0 33 BP13.0050 03.092.27.02.0 33 BP13.0050 03.092.27.03.0 33 BP13.0050 03.092.27.06.0 33 BP13.0050 03.092.27.15.0 33 BP13.0050 03.092.27.19.0 33
